PREVENTIVE MAINTENANCE CLEANING, LUBRICATION A ND MAINTENANCE DIAGRAMS Chapter Issue 3 Jan 08 Technical Reference Manu al 35.57 Figure 35-10 Screen Actuators Y Actuator X Rear Actuator X Front Actuator Plan View on Machi…
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
35.56 Technical Reference Manual Chapter Issue 3 Jan 08
Figure 35-9 Adjustable Screen Mount (ASM)
Stencil Guide Strips
Pulleys
(in 3 positions)
View on Flap Assembly (cover removed)
Screen At Centre Sensor
Stencil Guide Strip
(in 13 positions)
Stencil Location Leaf Spring
(in 3 positions)
Flap Assembly
(in 8 positions)
ASM (isometric view)
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 3 Jan 08 Technical Reference Manual 35.57
Figure 35-10 Screen Actuators
Y Actuator
X Rear Actuator
X Front Actuator
Plan View on Machine
Fixed Ball Striker Plate
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
35.58 Technical Reference Manual Chapter Issue 3 Jan 08
Figure 35-11 Screen Change Mechanism
Screen at Stop Sensor
Auto Drip Tray
Actuator Piston
Auto Drip Tray
Screen Stop
Actuator Arm Lever
