PREVENTIVE MAINTENANCE DAILY MAINTENANCE Chapter Issue 3 Jan 08 Technical Reference Manu al 35.9 Summary/Remarks Signed: Date:
PREVENTIVE MAINTENANCE
DAILY MAINTENANCE
35.8 Technical Reference Manual Chapter Issue 3 Jan 08
NOTE
Any items heavily contaminated requiring thorough cleaning must be re-lubri-
cated in accordance with the appropriate monthly maintenance task.
5 Adjustable Screen Mount (ASM):
a. ASM Assembly
b. Pulley Assemblies
c. Stencil Guide Strips
Remove any debris and clean.
Spatula,
IPA Impregnated
Wipes
Adjustable Screen Mount
(ASM)
6 Camera:
a. Up and down camera lens
b. Board at stop opto
Remove any debris and clean.
Spatula,
IPA Impregnated
Wipes
Board Opto Locations
7 Underscreen Cleaner:
a. Linear Bearings
b. Magnet Assemblies
Remove any debris and clean.
Spatula,
IPA Impregnated
Wipes
Underscreen Cleaner
8 Vortex Plus Underscreen Cleaner (only):
Remove any debris and clean the filter housing.
Spatula,
IPA Impregnated
Wipes
Vortex Plus Underscreen
Cleaner
9 Board Optos:
Clean the top of the board at left and board at
right sensors.
Spatula,
IPA Impregnated
Wipes
Board Opto Locations
10 Tooling:
Remove any debris and clean.
Spatula,
IPA Impregnated
Wipes
Rising Table
11 Grid-Look Tooling Modules:
Remove any debris and clean.
Spatula,
IPA Impregnated
Wipes
Rising Table
12 Rising Table:
a. Manual tooling plate of the rising table
b. Clatter bars
c. Splash guard (Dual Lane only)
Remove any debris and clean.
Spatula,
IPA Impregnated
Wipes
Rising Table
Rail System
Dual Lane
13 Machine Covers:
Remove any debris and clean.
NOTE
Use only soap and water on the machine view-
ing panels.
Spatula,
IPA Impregnated
Wipes
Machine Covers
Estimated time required for daily tasks 15.0 mins
No Task Tools Completed Reference Figure
PREVENTIVE MAINTENANCE
DAILY MAINTENANCE
Chapter Issue 3 Jan 08 Technical Reference Manual 35.9
Summary/Remarks
Signed: Date:
PREVENTIVE MAINTENANCE
DESCRIPTION OF THE MONTHLY MAINTENANCE SCHEDULE
35.10 Technical Reference Manual Chapter Issue 3 Jan 08
DESCRIPTION OF THE MONTHLY MAINTENANCE SCHEDULE
Introduction Two modules form the basis of the monthly schedule. The process requires that
each month a machine repeatability check is performed on Squeegee Pressure
and the X, Y and Theta axes. This is done using the Statistical Process Control
(SPC) data collection program (where available).
Module 1 The first module comprises the following elements:
• SPC Alignment Check - used to set a benchmark each month, the hard-
ware is checked to give a snapshot of the machine condition, performance
is monitored to predict failure before it has an affect on production.
• Machine Cycle Count - machine usage is logged in the table.
• A Software Check is carried out, if a newer version is available this may
contain known defect fixes or equipment enhancements. The service
engineer can recommend an upgrade for the equipment in service. In
addition, the machine event log is checked to identify any re-occurring
errors which if not inspected/diagnosed may lead to unplanned downtime.
• A standard Monthly Maintenance Check consists of a series of mainte-
nance tasks which are performed every month.
Machine safety checks are carried out on a basis as laid down in the monthly
schedule.
In addition, the engineer performs maintenance on set machine modules,
checks software version and records the cycle count.
Module 2 In this module, over the course of a year, the following assemblies are checked.
• Printhead
• All Electrical Enclosures
• Camera System
• Squeegee Mechanism
• Rising Table
• Paste Dispenser
• ProFlow (if fitted)
• Temperature Control Module (TCM)
• Screen Alignment
• DC Supplies
• Vacuum Filtration Unit
• Pneumatic System
• Safety System
• Rail System
• Print Carriage
• Machine Level
• Screen Change
• Adjustable Screen Mount (ASM)
