N67xx DUT Power Supply Installation 1-7
Connecting Output Cables for N6751
The DUT power supply connections are J4 and J9 on the ASRU Card. The ASRU
Card end of the cable can be either a 34-pin connector or a 20-pin connector.
The 34-pin connector is for ASRU channels 1–4, and the 20-pin connector is for
channels 5–6. Refer to the Connector Wiring Charts and connect the output cables
as described in Connecting to the ASRU Card.
Connector Wiring Charts
• Connector A to J4 on ASRU Card
• Connector B to J9 on ASRU Card
Table 1-2 Connector A to J4 on ASRU Card
Pin Wire Color Wire Size Con/Terminal Pin Wire Color Wire Size Con/Terminal
1 VIO 24 F NC 19 NC
2 WHT 24 F NC 20 NC
3NC 21RED 24 H1
4 NC 22 WHT 24 H4
5 GRN 24 F1 23 WHT/GRN 24 G3
6 WHT 24 F4 24 WHT/GRN 24 G3
7 WHT/BRN 20 J3 25 WHT/BLU 20 G2
8 WHT/BRN 20 J3 26 WHT/BLU 20 G2
9 WHT/BLK 20 J2 27 NC
10 WHT/BLK 20 J2 28 NC
11 NC 29 BLK 24 J1
12 NC 30 WHT 24 J4
13 BLU 24 G1 31 BLK 20 F3
14 WHT 24 G4 32 BLK/WHT 20 F3
15 WHT/ORN 20 H3 33 RED 20 F2
16 WHT/ORN 20 H3 34 RED/WHT 20 F2
17 WHT/RED 20 H2
18 WHT/RED 20 H2
1-8 N67xx DUT Power Supply Installation
Table 1-3 Connector B to J9 on ASRU Card
Pin Wire Color Wire Size Con/Terminal
1NC
2NC
3NC
4NC
5GRN 24 K1
6WHT 24 K4
7WHT/BRN20
8WHT/BRN20
9WHT/BLK 20
10 WHT/BLK 20
11 NC
12 NC
13 BLU 24 L1
14 WHT 24 L4
15 WHT/ORN 20
16 WHT/ORN 20
17 WHT/RED 20
18 WHT/RED 20
19 NC
20 NC
K3
K2
L3
L2
N67xx DUT Power Supply Installation 1-9
Connecting to the ASRU Card
Connecting to Channels 1 through 4
The N6751 is a 4-output DUT power supply. One ASRU channel is required for each
output.
1 Locate the highest numbered module with channels 1 through 4 available on
the ASRU Card.
If channels 1 through 4 are not available, see Connecting to Channels 5 and 6
on page 1-10.
2 Connect the DUT Power Supply cable to the ASRU Card and to the N6751
power supply, as illustrated in Figure 1-5.
Figure 1-5 N6751 output connections – Channels 1 through 4
Channel 4 Channel 3 Channel 2 Channel 1
P/S Label on
cable
Cable color P/S Label on
cable
Cable color P/S Label on
cable
Cable color P/S Label on
cable
Cable color
+S F1 GRN +S G1 BLU +S H1 RED +S J1 BLK
+ F2 RED
RED/WHT
+ G2 BLU/WHT + H2 RED/WHT + J2 BLK/WHT
– G3 GRN/WHT – H3 ORN/WHT – J3 BRN/WHT
– F3 BLK
BLK/WHT
–S G4 WHT –S H4 WHT –S J4 WHT
–S F4 WHT
F1 F2 F3 F4
G1 G2 G3 G4
H1 H2 H3 H4
J1 J2 J3 J4
