GEM for SIPLACE V7.01
Page 106 of 251 ©Siemens AG, all rights reserved
6WUHDP
6)7UDFH'DWD6HQG
S6F1 [W] * H<-E
<L [4]
<U4 TRID> * Trace ID
<U4 SMPLN> * Sample Number
<A 'yyyymmddhhmmss'> * STIME - Sample Date and Time
<L
<V> * Variable Value
...
>
> .
The Equipment sends time driven trace data, as previously requested by the Host using
S2F23.
TRID is the Trace ID as initiated by the Host.
SMPLN is the sample number. The first sample is "1", the next "2", and so on. If
REPGSZ is greater than 1, SMPLN is the number of the last sample contained in this
S6F1.
STIME is the date and time at which this sample was taken. If REPGSZ is greater than 1,
STIME is the date and time of the last sample contained in this S6F1.
The V's appear in the same order they were specified in S2F23.
S6F1 is normally single block. However, if the Host erroneously initiates a multiblock
trace using an incorrect S2F23, S6F1 may be multi-block. The Equipment never sends
an Inquire/Grant message preceding S6F1.
Equipment Constant "WBitS6" controls whether the Equipment sends S6F1 with W-Bit "1"
(Reply Expected) or "0" (No Reply Expected).
6)7UDFH'DWD$FNQRZOHGJH
S6F2 * H->E
<B [1] 00> . * ACKC6
The Host acknowledges the data. The Equipment ignores ACKC6.
6)$QQRWDWHG(YHQW5HSRUW
S6F3 [W] * H<-E, Multiblock
<L [3]
<U4 DATAID> * DATAID
<U4 CEID> * Collection Event ID
<L
<L [2]
<U4 DSID> * DSID=RPTID Report ID
<L
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 107 of 251
<U4 VID> * Variable ID
<V> * Variable Value
>
...
>
>
...
>
> .
1RWH7KLVPHVVDJHLVSURYLGHGRQO\IRUFRPSDWLELOLW\ZLWKROGHU+RVWFRPSXWHUVZKLFKGR
QRWVXSSRUW*(0
If the Equipment Constant "ConfigEvents" is set to "0", the Equipment sends S6F3 instead
of the normal S6F13 Annotated Event Report.
A Collection Event has occurred at the Equipment. The Host has enabled event reporting
for this CEID (see S2F37). The Host has set the Equipment constant RpType to "True"
(Annotated report format desired). The SIPLACE sends one or more Event Reports
which the Host has previously linked to that CEID (see S2F35). Each report contains
specific Variables which the Host has previously defined for that Report (See S2F33).
The Equipment generates a value for DATAID to uniquely identify this Conversation. If
S6F3 is multiblock, the Equipment first sends the S6F5/S6F6 Inquire/Grant transaction,
and DATAID in S6F3 will match DATAID in S6F5.
If the CEID is enabled, but no Reports are linked to this CEID, S6F3 has the following
special format:
S6F3 [W] * H<-E
<L [3]
<U4 DATAID> * DATAID
<U4 CEID> * Collection Event ID
<L>
> .
Equipment Constant "Wbits6" controls whether the Equipment sends S6F3 with W-Bit "1"
(Reply Expected) or "0" (No Reply Expected).
6)$QQRWDWHG(YHQW5HSRUW$FNQRZOHGJH
S6F4 * H->E
<B [1] 00> . * ACKC6
The Host acknowledges the Event Report. The Equipment ignores ACKC6.
S6F5 - Multi-Block Data Send Inquire
GEM for SIPLACE V7.01
Page 108 of 251 ©Siemens AG, all rights reserved
S6F5 W * H<-E
<L [2]
<U4 DATAID> * DATAID
<U4 DATALENGTH>
> .
The Equipment sends this Inquire/Grant transaction preceding any multiblock S6F3,
S6F9, S6F11, or S6F13.
The DATAID specified here will appear in the following S6F3, S6F9, S6F11, S6F13.
DATALENGTH value is the total number of text bytes (excluding SECS block headers) in
the following S6F3, S6F9, S6F11, or S6F13 message.
6)0XOWL%ORFN*UDQW
S6F6 * H->E
<B [1] GRANT6> . * GRANT6
The Host grants permission for the Equipment to send a multi-block event report..
GRANT6 Description
0x00 Normal. Permission granted.
Other Permission not granted. The Equipment will not
send the following S6F3, S6F9, S6F11, or
S6F13, and will discard the data.
6)(YHQW5HSRUW
S6F9 [W] * H<-E, Multiblock
<L [4]
<B [1] 00> * PFCD
<U4 DATAID> * DATAID
<U4 CEID> * Collection Event ID
<L
<L [2]
<U4 DSID> * DSID=RPTID Report ID
<L
<V> * Variable Value
...
>
>
...
>
> .
