GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 121 of 251
6WUHDP
not used
GEM for SIPLACE V7.01
Page 122 of 251 ©Siemens AG, all rights reserved
6WUHDP
6)8QUHFRJQL]HG'HYLFH,'
S9F1 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
6)8QUHFRJQL]HG
S9F3 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
6)8QUHFRJQL]HG
S9F5 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
6),QYDOLG'DWD
S9F7 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
6)7UDQVDFWLRQ7LPHU
S9F9 * H<-E
<B [10] SHEAD> . * SHEAD - Stored Header
6)'DWD7RR/RQJ
S9F11 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 123 of 251
6WUHDP
6)7HUPLQDO5HTXHVW
S10F1 [W] * H<-E
<L [2]
<B [1] TID> * Terminal ID
<A [160] TEXT> * Message Text
> .
The Equipment sends text to the Host. This Equipment may send the following values for
TID:
TID Description
0x00 Always sent.
Equipment Constant "WBitS10" controls whether the Equipment sends S10F1 with W-Bit
"1" (Reply Expected) or "0" (No Reply Expected).
6)7HUPLQDO5HTXHVW$FNQRZOHGJH
S10F2 * H->E
<B [1] ACKC10> . * Acknowledge Code
The Host may send the following values for ACKC10:
ACKC10 Description
0x00 Normal. Host accepts the S10F1.
Other Host rejects the S10F1.
6)7HUPLQDO'LVSOD\
S10F3 [W] * H->E
<L [2]
<B [1] TID> * Terminal ID
<A [160] TEXT> * Message Text
> .
The Host sends to the Equipment. The Equipment interprets TID as follows:
TID Description
Any Equipment displays the text on its CRT.
The Host may optionally set the W-Bit to "1" in S10F3. If so, the Equipment replies with
S10F4.
6)7HUPLQDO'LVSOD\6LQJOH$FNQRZOHGJH
S10F4 * H<-E
<B [1] ACKC10> . * Acknowledge Code
