GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 149 of 251
 (UURU0HVVDJHV
 8QUHFRJQL]HG'HYLFH,'
Step SECS Message Description
1. H -> E SnFn [W] Host sends a message with a bad Device ID in
the header. The W-bit can be either 0 or 1.
2. H <- E S9F1 Equipment replies with „Unrecognized Device
ID“.
 8QUHFRJQL]HG6WUHDP
Step SECS Message Description
1. H -> E SnFn [W] Host sends a primary message with a stream
number that the Equipment does not support.
The W-bit can be either 0 or 1.
2. H <- E S9F3 Equipment replies with „Unrecognized Stream“.
 8QUHFRJQL]HG)XQFWLRQ
Step SECS Message Description
1. H -> E SnFn [W] Host sends a primary message with a stream
number for which the Equipment recognizes
some messages, but with a function number that
the Equipment does not support for that stream.
The W-bit can be either 0 or 1.
2. H <- E S9F5 Equipment replies with „Unrecognized Function“.
 ,OOHJDO'DWD)RUPDW
Step SECS Message Description
1. H -> E SnFn [W] Host sends a message with a stream and
function that the Equipment recognizes, but with
a data format that is incorrect. The W-bit can be
either 0 or 1.
2. H <- E S9F7
GEM for SIPLACE V7.01
Page 150 of 251 ©Siemens AG, all rights reserved
 'DWD7RR/RQJ
Step SECS Message Description
1. H -> E SnFn [W] Host sends a message with a stream and
function that the Equipment recognizes, but
contains more data than expected. The W-bit
can be either 0 or 1.
2. H <- E S9F11 Equipment replies with „Data Too Long“. If the
erroneous message is a primary with the W-bit
set to 1, then in come cases the Equipment will
reply with the usual secondary response with an
appropriate error code, instead of S9F11. If the
erroneous message is a secondary, the
Equipment makes no reply at all.
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 151 of 251
 &ORFN
 +RVW6HWV'DWHDQG7LPH
Step SECS Message Description
1. H -> E S2F31 W Date and Time Send. The Host sends a new
Date and Time to the Equipment.
2. H <- E S2F32 The Equipment sets its Clock/Calendar
hardware and acknowledges the command.
 +RVW5HTXHVWV'DWHDQG7LPH
Step SECS Message Description
1. H -> E S2F17 W Date and Time Request. The Host requests
Date and Time from the Equipment.
2. H <- E S2F18 The Equipment sends its Date and Time.
 (TXLSPHQW5HTXHVWV'DWHDQG7LPH
Step SECS Message Description
1. H <- E S2F17 W Date and Time Request. The Equipment
requests Date and Time from the Host.
2. H -> E S2F18 The Host sends its Date and Time. The
Equipment sets its Clock/Calendar hardware
according to the contents of this message.
