GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 165 of 251
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
spool. A setting of zero indicates that all spooled
messages should be sent. Refer to the description of
S6F23 in the "SECS Message Detail" section for
further information.
1002038 SV U4 SPOOLCOUNTACTUAL.
A count of the number of messages actually present
on the spool disk, adjusted for any messages which
have been overwritten or otherwise discarded.
1002039 SV U4 SPOOLCOUNTTOTAL.
A count of the number of messages the equipment
attempted to write to the spool disk. This number
includes messages actually present on the spool disk,
and also any messages which may have been
overwritten or otherwise discarded.
1002040 SV A[16] SPOOLFULLTIME.
The date and time at which the spool file became full.
Format is: YYYYMMDDhhmmsscc. See description
of CLOCK variable above for format details.
1002041 SV U1 SPOOLLOADSUBSTATE.
The current state within the SPOOL LOAD super-
state.
6 = Spool Not Full
7 = Spool Full
1002042 SV A[16] SPOOLSTARTTIME.
The date and time at which the first message was
written to the current spool file. Format is:
YYYYMMDDhhmmsscc.
See description of CLOCK variable above for format
details.
1002043 SV U1 SPOOLSTATE.
The current spool state within the POWER ON super-
state.
2 = Spool Active
1 = Spool Inactive
1002044 SV U1 SPOOLUNLOADSUBSTATE.
The current spool state within the SPOOL UNLOAD
super-state.
3 = Purge Spool
4 = Transmit Spool
5 = No Spool
1002045 EC U1 CONFIGSPOOL.
This EC determines whether spooling is enabled or
disabled for this Equipment.
GEM for SIPLACE V7.01
Page 166 of 251 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
0 = Disabled
1 = Enabled
1002046 EC BOOL OVERWRITESPOOL.
This EC determines the action to be taken by the
Equipment when the Spool file reaches its capacity.
TRUE = Overwrite Spool
FALSE = Do Not Overwrite Spool
Limit Monitoring
1002047 DV U4 GEMLIMITSVID.
The VID relating to the most recent Limits Monitoring
transition event which occurred.
1002048 DV B[1] GEMEVENTLIMIT.
The LIMITID relating to the most recent Limits
Monitoring transition event which occurred.
1002049 DV B[1] GEMTRANSTYPE.
Transition type relating to the most recent Limits
Monitoring transition which occurred.
0x00 = Lower -> Upper
0x01 = Upper -> Lower
1002050 EC U2 GEMLIMITSTIMER.
The time in seconds this equipment will pauses
between checking for Limits Monitoring transitions
On-Line Identification
1002051 SV A[6] MDLN.
Model number. Ä6ÄorÄ)Ä
1002052 SV A[6] SOFTREV.
Software revision number. [[
1002053 SV A SOFTWAREREVWPC
Software revision of the waffle pack changer
A value of 0 indicates an error.
1002054 SV A SOFTWAREREVTABLE
Revision of feeder table software
Valid after the loading of the cluster and setup data
and the reference run.
1002055 EC U2 HEARTBEAT.
The time in seconds that the Equipment will pause
before sending S1F1 to test the link. Units are
seconds. Valid values are 0-3200 (a setting of zero
will disable the heartbeat).
1002065 EC U1 GEMTIMEFORMAT
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 167 of 251
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
Format of TIME (VID 1002023)
0: 12 digits
1: 16 digits (Year 2000 compliant)
1002068 EC A[10] NICKNAME
Default value is "SIPLACE"
Can be overwritten with an invidual name for each
machine.
1002069 SV I8 LASTERRORCODE
Errorcode of last specific Error Event FM_...
If the General Error Event FM_GENERAL is used, this
Variable contains the Error Code. The Error Code is
identical to the CEID of the specific Error Event.
Example:
A barcode reading error can be reported with the
Event
CEID 920001 FM_LP_BC_NOK
or with the General Error Event
CEID 1001024 FM_GENERAL and the Variables
VID 1002069 LASTERRORCODE = 920001 and
VID 1002070 LASTFMTEXT = "FM_LP_BC_NOK"
1002070 SV A LASTFMTEXT
Error Text of the last specific Error Event.
Valid for Event FM_General
GUI
1122001 SV A GUIACTIONTEXT
Last „Action text“ sent to GUI
An empty text indicates an error
1122002 SV A GUISTATETEXT
Last „State text“ sent to GUI
An empty text indicates an error
1122003 SV I2 GUISEGMENTNR
Segment number sent by GUI
A value of -1 indicates an error
1122004 SV I2 GUIGANTRYNR
Gantry number sent by GUI
A value of -1 indicates an error
1122005 SV I2 GUITRACKNR
Track sent by GUI
A value of -1 indicates an error
