GEM for SIPLACE V7.01
Page 166 of 251 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
0 = Disabled
1 = Enabled
1002046 EC BOOL OVERWRITESPOOL.
This EC determines the action to be taken by the
Equipment when the Spool file reaches its capacity.
TRUE = Overwrite Spool
FALSE = Do Not Overwrite Spool
Limit Monitoring
1002047 DV U4 GEMLIMITSVID.
The VID relating to the most recent Limits Monitoring
transition event which occurred.
1002048 DV B[1] GEMEVENTLIMIT.
The LIMITID relating to the most recent Limits
Monitoring transition event which occurred.
1002049 DV B[1] GEMTRANSTYPE.
Transition type relating to the most recent Limits
Monitoring transition which occurred.
0x00 = Lower -> Upper
0x01 = Upper -> Lower
1002050 EC U2 GEMLIMITSTIMER.
The time in seconds this equipment will pauses
between checking for Limits Monitoring transitions
On-Line Identification
1002051 SV A[6] MDLN.
Model number. Ä6ÄorÄ)Ä
1002052 SV A[6] SOFTREV.
Software revision number. [[
1002053 SV A SOFTWAREREVWPC
Software revision of the waffle pack changer
A value of 0 indicates an error.
1002054 SV A SOFTWAREREVTABLE
Revision of feeder table software
Valid after the loading of the cluster and setup data
and the reference run.
1002055 EC U2 HEARTBEAT.
The time in seconds that the Equipment will pause
before sending S1F1 to test the link. Units are
seconds. Valid values are 0-3200 (a setting of zero
will disable the heartbeat).
1002065 EC U1 GEMTIMEFORMAT
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 167 of 251
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
Format of TIME (VID 1002023)
0: 12 digits
1: 16 digits (Year 2000 compliant)
1002068 EC A[10] NICKNAME
Default value is "SIPLACE"
Can be overwritten with an invidual name for each
machine.
1002069 SV I8 LASTERRORCODE
Errorcode of last specific Error Event FM_...
If the General Error Event FM_GENERAL is used, this
Variable contains the Error Code. The Error Code is
identical to the CEID of the specific Error Event.
Example:
A barcode reading error can be reported with the
Event
CEID 920001 FM_LP_BC_NOK
or with the General Error Event
CEID 1001024 FM_GENERAL and the Variables
VID 1002069 LASTERRORCODE = 920001 and
VID 1002070 LASTFMTEXT = "FM_LP_BC_NOK"
1002070 SV A LASTFMTEXT
Error Text of the last specific Error Event.
Valid for Event FM_General
GUI
1122001 SV A GUIACTIONTEXT
Last „Action text“ sent to GUI
An empty text indicates an error
1122002 SV A GUISTATETEXT
Last „State text“ sent to GUI
An empty text indicates an error
1122003 SV I2 GUISEGMENTNR
Segment number sent by GUI
A value of -1 indicates an error
1122004 SV I2 GUIGANTRYNR
Gantry number sent by GUI
A value of -1 indicates an error
1122005 SV I2 GUITRACKNR
Track sent by GUI
A value of -1 indicates an error
GEM for SIPLACE V7.01
Page 168 of 251 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
1122006 SV I2 GUINOZZLETYPE
Nozzle type sent by GUI
A value of -1 indicates an error.
SIPLACE Revolver Head 1
1312001 SV I4 HEIGHTREV1
Height of revolver head 1. Only valid after reference
run. Units are 1/1000 mm
During the reference run the SIPLACE measures the
distance between the upper edge of the conveyor belt
and the nozzle on segment 1. The
HEIGHTREVOLVER1 is then calculated by subtracting
the length of the nozzle on segment 1 from the
measured value. The nozzle length is defined in the
machine data. So HEIGHTREVOLOR1 is a relative
not an absolute value.
A value of 0 indicates an error
1312002 SV L GANTRYINFOREV1
Gantry information for revolver head 1. The data is
automatically reseted when a PCB reaches the center
conveyor.
/
,&RPS3LFNHG8S!
,&RPS3ODFHG!
,&RPS/HIW3ODFH!
!
CompPickedUp Number of components which
were picked up successfully since
the last PCB reached the center
conveyor
CompPlaced Number of components which
were placed since the last PCB
reached the center conveyor
CompLeft2Place Number of components which
were not placed on the actual
PCB
An empty list indicates an error.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
1312003 SV L PLACEINFOREV1
Placement information for revolver head 1.
/
/
