GEM for SIPLACE V7.01
Page 170 of 251 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
1312004 SV L PICKUPINFOREV1
Pick-up information for revolver head 1
/
/
$&RPSRQHQW1DPH!
,7UDFN1XPEHU!
8)HHGHU7\SH!
,/HYHO!
,'LYLVLRQ!
80DFKLQH6LGH!
83LFN8S5HVXOW!
,3LFN8S9DFXXP!>PEDU@
L9DFXXP!
!

!
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
in use in the last pick up cycle the list for that segment
is left empty.
If the component was picked up from a feeder /HYHO
will contain -1. In the case that the component was
picked up from a tray in the waffle pack changer
7UDFN1XPEHU is set to -1. If both values are not equal
to -1 the component was picked up from a „manual
tray“.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1312005 SV L NOZZLECONF1
Nozzle configuration on revolver head 1. Only valid
after reference run.
/
/
812==/(B7<3(!
,5($/B12==/(B/(1*7+!>PP@
!

!
The nozzle length is measured during the reference
run. It depends on the HEIGHTREVOLVER1 value. So
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 171 of 251
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
REAL_NOZZLE_LENGTH is not a absolute but a
relative value.
It is calculated by subtracting the measured distance
between the nozzle and the upper edge of the
transport conveyor from the HEIGHTREVOLVER1
value.
An empty list indicates an error.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
1312006 SV L VACUUMDATAREV1
Vacuum measurements from the last reference run on
revolver head 1. Valid only after reference run.
/
/
,RSHQBQR]]OH!>PEDU@
,FORVHGBQR]]OH!>PEDU@
,FXELFBQR]]OH!>PEDU@
,QRWBFXELFBQR]]OH!>PEDU@
,WROBGLUW\BQR]]OH!>PEDU@
,WROBOHDN\BQR]]OH!>PEDU@
!

!
The first element in this list refers to segment 1, the
second to segment 2, and so on.
tol_dirty_nozzle and tol_leaky_nozzle are currently not
used.
An empty list indicates an error.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
1312007 SV L SEGMENTINFOREV1
/
/
,&RPS3LFNHG8S!
,3LFN(UURUV!
,&RPS3ODFHG!
,3LFN8S3ODFH(UURUV!
!

GEM for SIPLACE V7.01
Page 172 of 251 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
!
The first element in this list refers to segment 1, the
second to segment 2, and so on.
The variable can be linked e.g. to event PCBReady. It
is reseted when a PCB reaches the center conveyor.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
1312008 SV L PLACEINFOREV1SUB1
Subset of PLACEINFOREVx variable. Detailed
description see there.
/
/
8;SRVLWLRQ!>PP@
8<SRVLWLRQ!>PP@
)$QJOH!>GHJUHHV@
8)RUFH,QGH[!
$5HIHUHQFH'HVLJQDWRU!
$&RPSRQHQW1DPH!
83DFNDJH)RUP1XPEHU!
83ODFHPHQW5HVXOW!
,3ODFHPHQW9DFXXP!>PEDU@
8'DWD9DOLG!
,;GHYLDWLRQ!>PP@
,<GHYLDWLRQ!>PP@
)$QJOH!>GHJUHHV@
)0D[/HDG'HY!
)0D[%DOO'HY!
!

IRUHDFKVHJPHQW

!
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
in use in the last placement cycle the list for that
segment is left empty.
Revolver Head 2 (SIPLACE 80 S 20 only)
1412001 SV I4 HEIGHTREV2
Height of revolver head 2. Only valid after reference
run. Units are 1/1000 mm. Only valid for SIPLACE
