00192402-01 - 第183页
GEM for SIPLACE V7.01 ©Siemens AG, all rights r eserved page 183 of 251 9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ Bit 2: If bit is set, the pr otective covers are open. Bit 3: If bit is set, the s tart button w…
GEM for SIPLACE V7.01
Page 182 of 251 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
to -1 the component was picked up from a „manual
tray“.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1512016 SV L SEGMENTINFOIC
/
,&RPS3LFNHG8S!
,3LFN(UURUV!
,&RPS3ODFHG!
,3ODFH(UURUV!
!
The variable can be linked e.g. to event PCBReady. It
is reseted when a PCB reaches the center conveyor.
Rejected components due to optical centering or
coplanarity are not counted in PickErrors.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
I / O Ports
2012001 SV U1 INPUTPORTBYTE1
Bit 0: If bit is set, the upper proximity switch of the
lifting table is not switched.
Bit 1: If bit is set, the lower proximity switch of the
lifting table is not switched.
Bit 2: If bit is set, the proximity switch of the
stopper of the parallel conveyer is switched.
Bit 3: If bit is set, the proximity switch of the
adjustment width is switched.
Bit 4: If bit is set, the adjustment width is at the
limit switch.
Bit 5: If bit is set, the proximity switch of the
stopper is switched.
Bit 6: If bit is set, the software switch high voltage
is off.
Bit 7: If bit is set, the ceramic substrate centering
is open.
A value of -1 indicates an error
2012002 SV U1 INPUTPORTBYTE2
Bit 0: If bit is set, high voltage is on.
Bit 1: If bit is set, the emergency stop button is
down.
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 183 of 251
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
Bit 2: If bit is set, the protective covers are open.
Bit 3: If bit is set, the start button was actuated.
Bit 4: If bit is set, the stop button was actuated.
Bit 5: If bit is set, the key switch is not set.
Bit 6: If bit is set, the compress air unit is active.
Bit 7: If bit is set, the axis operation voltage is
active.
A value of -1 indicates an error
2012003 SV U1 INPUTPORTBYTE3
Bit 0: If bit is set, the gantry crash sensor was set
Bit 1: If bit is set, the gantry proximity sensor was
set.
Bit 2: If bit is set, the open proximity switch of the
nozzle changer of gantry 1 is switched.
Bit 3: If bit is set, the close proximity switch of the
nozzle changer of gantry 1 is switched.
Bit 4: If bit is set, the open proximity switch of the
nozzle changer of gantry 2 is switched.
Bit 5: If bit is set, the close proximity switch of the
nozzle changer of gantry 2 is switched.
Bit 6: If bit is set, the center conveyer sensor is
covered.
Bit 7: If bit is set, the center conveyer sensor of
parallel conveyor is covered. A value of -1
indicates an error
2012004 SV U1 INPUTPORTBYTE4
Bit 0: If bit is set, the Interface signal "Request"
to the preceding station is active.
Bit 1: If bit is set, the Interface signal "Sent" to the
preceding station is active.
Bit 2: If bit is set, the Interface signal
"Permission" to the following station is
active.
Bit 3: If bit is set, the Interface signal "Received"
to the following station is active.
Bit 4: If bit is set, the input conveyor sensor is
covered.
Bit 5: If bit is set, the input conveyor sensor of the
parallel conveyer is covered.
Bit 6: If bit is set, the output conveyor sensor is
covered.
Bit 7: If bit is set, the output conveyor sensor of
the parallel conveyor is covered.
A value of -1 indicates an error
2012005 SV U1 INPUTPORTBYTE5
GEM for SIPLACE V7.01
Page 184 of 251 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
Bit 0: If bit is set, the upper proximity switch of the
lifting table of the second transport track is
not switched.
Bit 1: If bit is set, the lower proximity switch of the
lifting table of the second transport track is
not switched.
Bit 2: Not used.
Bit 3: If bit is set, the proximity switch of the
adjustment width of the second transport
track is switched.
Bit 4: If bit is set, the adjustment width of the
second transport track is at the limit switch.
Bit 5: Not used.
Bit 6: Not used.
Bit 7: If bit is set, the ceramic substrate centering
of the second transport track is open.
A value of -1 indicates an error
2012006 SV U1 INPUTPORTBYTE6
Bit 0: If bit is set, the Interface signal "Request"
to the preceding station of the second
transport track is active.
Bit 1: If bit is set, the Interface signal "Sent" to the
preceding station of the second transport
track is active.
Bit 2: If bit is set, the Interface signal
"Permission" to the following station is
active.
Bit 3: If bit is set, the Interface signal "Received"
to the following station of the second
transport track is active.
Bit 4: Not used.
Bit 5: Not used.
Bit 6: Not used.
Bit 7: Not used.
A value of -1 indicates an error
2012007 SV U4 OUTPUTPORTBYTE1
Bit 0: If bit is set, lifting table is moving up.
Bit 1: If bit is set, lifting table is moving down.
Bit 2: If bit is set, the nozzle changer of gantry 1
will be opened.
Bit 3: If bit is set, the nozzle changer of gantry 2
will be opened.
Bit 4: Bit to switch the compress air unit.
Bit 5: If bit is set, the stopper of the twin conveyer
will extend.
