GEM for SIPLACE V7.01 ©Siemens AG, all rights r eserved page 189 of 251 9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ / / ,+HDG,'! ,+($ '7<3(! ! ! ! ! ! HEADTYPE: 5 = Revolverhead with …
GEM for SIPLACE V7.01
Page 188 of 251 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
machine.
/
/
$&RPSRQHQW1DPH!
,7UDFN1XPEHU!
8)HHGHU7\SH!
,/HYHO!
,'LYLVLRQ!
80DFKLQH6LGH!
8)HHGHU$FFHVVHV3HU3&%!
83LFN8S(UURUV!
82SWLFDO(UURUV!
8&RSODQDULW\(UURUV!
!
!
FeederAccessesPerPCB will be reset when a PCB
reaches the center conveyor.
If the component was picked up from a feeder /HYHO
will contain -1. In the case that the component was
picked up from a tray in the waffle pack changer
7UDFN1XPEHU is set to -1. If both values are not equal
to -1 the component was picked up from a „manual
tray“.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012020 SV A PICKUPDATARESETPOINT
Date and time when the „Pick-Up Error“ data item was
reset.
An empty text indicates an error.
2012021 SV L GANTRYHEADCONFIG
/
/
,*DQWU\*URXS,'(not used)
/
/
,*DQWU\,'!
,7\SH2I*DQWU\!
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 189 of 251
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
/
/
,+HDG,'!
,+($'7<3(!
!
!
!
!
!
HEADTYPE:
5 = Revolverhead with 12 nozzles
6 = Revolverhead with 6 nozzles
7 = IC Head
On a SIPLACE S20 the first gantry in the list is the left
one in transport direction, the second is the right one.
The SIPLACE 80F4 has 2 Head mounted on gantry
one. Head 1 is the one on the left side.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012022 DV U1 MACHINESIDE
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012023 DV I2 TRACKNUMBER
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012024 DV I2 DIVISION
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012025 DV I2 LEVEL
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012026 DV U1 SEGMENT
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012027 DV A COMPONENTNAME
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012028 DV U2 GANTRYID
For a detailed description of the data item see „4.2
Data Item Dictionary“.
GEM for SIPLACE V7.01
Page 190 of 251 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
2012029 DV U2 GANTRYGROUPID
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012030 DV U2 HEADID
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012031 DV A REFERENCEDESIGNATOR
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012032 DV U2 PACKAGEFORMNUMBER
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012033 DV U2 PLACEERRORDESCRIPTION
For a detailed description of the data item see „4.2
Data Item Dictionary“.
