GEM for SIPLACE V7.01
Page 192 of 251 ©Siemens AG, all rights reserved
537,' 1DPH 9,'V
1412006 <VACUUMDATAREV2>
23 TableSW 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1002054< SOFTWAREREVTABLE>
24 Barcode 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
912002< BCININPUTCONVEYOR>,
912005<PCBSIDEININPUTCONVEYOR>
25 FidTaugh 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
412001< TAUGHTFIDUCIAL>
26 PFmodified 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
512001<MODIFIEDPACKAGEFORM>
27 BeBarcode 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
912003<COMPONENTBARCODE>,
912004<WAYOFINPUTCOMPONENTBARCODE>,
2012022<MACHINESIDE>,
2012023<TRACKNUMBER>, 2012024<DIVISION>,
2012025<LEVEL
>
28 PickupError 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
2012026<SEGMENT>,
2012027<COMPONENTNAME>,
2012022<MASCHINESIDE>,
2012023<TRACKNUMBER>, 2012024<DIVISION>,
2012025<LEVEL>, 2012028<GANTRYID>,
2012029<GANTRYGROUPID>,
2012030<HEADID>
29 PlaceError 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
2012026<SEGMENT>,
2012031<REFERENCEDESIGNATOR>,
2012028<GANTRYID>,
2012029<GANTRYGROUPID>,
2012030<HEADID>
2012032<PACKAGEFORMNUMBER>,
2012033<PLACEERRORDESCRIPTION>
30 BarcodeTwin 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
912012<BCINTWININPUTCONVEYOR>,
912015<PCBSIDEINTWININPUTCONVEYOR>
34 SegmentInfoRev1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312007<SEGMENTINFOREV1>
35 SegmentInfoRev2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412007<SEGMENTINFOREV2>
36 SegmentInfoIc 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1512016<SEGMENTINFOIC>
44 FM_GENERAL 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1002069< LASTERRORCODE>, 1002070 <
LASTFMTEXT >
46 TrackEmpty/
TrackFull*
1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2012027<COMPONENTNAME>,
2012022<MASCHINESIDE>,
2012023<TRACKNUMBER>, 2012024<DIVISION>,
2012025<LEVEL>, 2012028<GANTRYID>,
2012029<GANTRYGROUPID>,
2012030<HEADID>
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 193 of 251
537,' 1DPH 9,'V
47 Transport2 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
612008<TWINTRANSPORTWIDTH>
* In the case of user-initiated TrackFull- or TrackEmpty-Events the Data Variables
2012022 <MASCHINESIDE>, 2012028 <GANTRYID>, 2012029 <GANTRYGROUPID>
and 2012030 <HEADID> linked to TrackEmpty/ TrackFull – Report are not defined and
set to the value ‘9’.
GEM for SIPLACE V7.01
Page 194 of 251 ©Siemens AG, all rights reserved
&ROOHFWLRQ(YHQWV
6RIWZDUH
CEID Name Description
111001 FM_SC_RECV Error during RMOS System Call
RECV*
1
111002 FM_SC_DALOC Error during RMOS System Call
DALOC*
1
111003 FM_SC_ALOC Error during RMOS System Call
ALOC*
1
111004 FM_SC_LOOK Error during RMOS System Call
LOOK*
1
111005 FM_SC_RIO Error during RMOS System Call RIO* 1
111006 FM_DATEN_UNBEK_MELD Unknown data code in MC1 during
data exchange*
1
111007 FM_SC_CREATEDRIV Error during RMOS System Call
CREATEDRIV*
1
111008 FM_CRUN_MALLOC Error during RMOS System Call
MALLOC*
1
111009 FM_GLK_AUFRUF Communication between SR and MC
interrupted*
1
111010 FM_BA_ZAEHLER Incorrect value of state counter* 1
111011 FM_BA_UNBEK_MELD Unknown operating state message* 1
111012 FM_BA_UNBEK_ZUST Illegal operating state* 1
111013 FM_DV_DATCODE SV: Unknown data code* 1
111014 FM_DV_DATEN_LAENGE SV: Incorrect data length* 1
111015 FM_DV_MELDCODE_MC SV: Unknown message code from
other MC*
1
111016 FM_DV_MELDCODE_SR SV: Unknown message code from
station computer*
1
111017 FM_SWITCH_DEFAULT Error in default branch* 1
111018 FM_SW_FALSCHE_F_NR MC has received wrong error number* 1
111019 FM_PW_SP_ABLAUF_NOK Error during execution of revolver
head nozzle-head check*
1
111020 FM_OPT_INDEX Data error in MC: optical centering
indices incorrect*
1
111021 FM_EF_SW_FEHLER Software error in SGL Functions* 1
111022 FM_DAW_PROG Pulse is not okay* 1
121023 FM_HAND_SPURLEER Track put out of operation by
operator*
1
121024 FM_NF_SWF NF: software error* 1
121025 FM_NF_GLK_NOK NF: GLC NOK* 1
121026 FM_NF_ALOC_NOK NF: no memory available* 1
