GEM for SIPLACE V7.01
Page 198 of 251 ©Siemens AG, all rights reserved
CEID Name Description
211014 FM_PW_SP_KONF_NOK Nozzle type not available in changer
magazine SP*
1
211015 FM_PW_SP_ANZ_GAR_LEER Not enouph garages in changer
magazine for nozzle return. SP*
1
211016 FM_PW_SP_ANZ_GAR_VOLL Insuff. number of nozzles in changer
magazine SP to pick up*
1
211017 FM_PW_SP_KEIN_NUTZEN No cluster available for nozzle pick-up
SP*
1
211018 FM_PW_SP_MODUL_ENTR_N
OK
Nozzle-changer revolver head cannot
be unlocked*
1
211019 FM_PW_SP_MODUL_VERR_N
OK
Nozzle-changer revolver head cannot
be locked*
1
211020 FM_PW_SP_VISION_KOM_NO
K
Communication with Vision System
during nozzle check disturbed*
1
211030 FM_PW_SP_ABH_NOK Nozzle SP pick-up not completed* 1
211031 FM_PW_SP_ABW_NOK Nozzle return SP not completed* 1
211032 FM_PW_SP_Z_SOLLPO_UEB_
ABH
Required Z-axis position exceeded
during SP nozzle pick-up*
1
211033 FM_PW_SP_Z_SOLLPO_N_ER
_ABH
Required Z-axis position not reached
during SP nozzle pick-up*
1
211034 FM_PW_SP_Z_SOLLPO_UEB_
ABL
Required Z-axis position exceeded at
SP nozzle return*
1
211035 FM_PW_SP_Z_SOLLPO_N_ER
_ABL
Required Z-axis position not reached
at SP nozzle return*
1
211036 FM_PW_SP_Z_SOLLPO_UEB_
ABW
Required Z axis position exceeded at
SP nozzle ejection*
1
211037 FM_PW_SP_Z_SOLLPO_N_ER
_ABW
Required Z axis position not reached
at SP nozzle ejection*
1
211038 FM_PW_SP_ABL_NOK_ALLG_
F
Nozzle not returned to
<magazine/garage>:*
1
211039 FM_PW_SP_ABH_NOK_ALLG_
F
Nozzle not picked up from
<magazine/garage>:*
1
211040 FM_PW_SP_ANZ_GAR_VOLL_
ALLG_F
Nozzle type not available <type/for
segment>:*
1
211041 FM_PW_SP_ANZ_GAR_LEER_
ALLG_F
Nozzle type not returnable <type/from
segment>:*
1
211042 FM_HOEH_PIP_DL_ZU_GROS
S
Incorrect nozzle length* 1
211043 FM_PW_SP_PINOLE_GEZ segment removed. * 1
211044 FM_PW_STD_MA file PPW_STD.MA not found or
incorrect*
1
211045 FM_PW_VERM_MA file PPW_VERM.MA not found or
incorrect*
1
211046 FM_PW_AKT_MA file PPW_AKT.MA not found or
incorrect*
1
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 199 of 251
CEID Name Description
211047 FM_SCAN_PIP_VERSCHMUTZ
T
Nozzle contaminated or worn-out* 1
211048 FM_PIP_KONV_NOK New nozzle configuration is required 1
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these nozzle
changer collection events.
$[LV
CEID Name Description
311001 FM_ABH_PROXIMITY
SWITCH_OBEN
not defined 1
311002 FM_ABH_IC_PROXIMITY
SWITCH_OBEN
Undefined 1
311003 FM_Z_N_OBEN Z-axis cannot be moved upwards* 1
311004 FM_X_N_OBEN Undefined error message 1
311005 FM_Y_N_OBEN Undefined error message 1
311006 FM_S_N_OBEN Undefined error message 1
311007 FM_D_N_OBEN Undefined error message 1
311008 FM_DUMMY_ACHSE undefined 1
311009 FM_Z_IC_N_OBEN Z-axis on IC head cannot be moved
upwards*
1
311010 FM_D_IC_N_OBEN Undefined error message 1
311011 FM_X_PROG_FEHLER Programmed position of X-axis
outside travel range*
1
311012 FM_Y_PROG_FEHLER Programmed position of Y-axis
outside travel range*
1
311013 FM_D_PROG_FEHLER Programmed position of D1 axis
outside travel range*
1
311015 FM_S_PROG_FEHLER Programmed position of S-axis
outside travel range*
1
311016 FM_Z_PROG_FEHLER 75 Programmed position of Z-axis
outside travel range*
1
311017 FM_X_TOL_BIT Position control of X-axis does not
work*
1
311018 FM_Y_TOL_BIT Position control of Y-axis does not
work*
1
311019 FM_S_TOL_BIT Position control of S-axis does not
work*
1
311020 FM_Z_TOL_BIT Undefined error message 1
311021 FM_D_TOL_BIT Undefined error message 1
GEM for SIPLACE V7.01
Page 200 of 251 ©Siemens AG, all rights reserved
CEID Name Description
311022 FM_CRASH Gantry distance insufficient. Protective
system reacted*
1
311023 FM_X_TIMEOUT 59 X axis: does not reach required
position*
1
311024 FM_Y_TIMEOUT 60 Y axis: does not reach required
position*
1
311025 FM_S_TIMEOUT 38 S axis: does not reach required
position*
1
311026 FM_Z_SP_TIMEOUT 61 SP/Z axis: does not reach required
position*
1
311027 FM_D_TIMEOUT 8 SP/D axis: does not reach required
position*
1
311028 FM_Z_IC_TIMEOUT IC/Z axis: does not reach required
position*
1
311029 FM_D_IC_TIMEOUT IC/D axis: does not reach required
position*
1
311030 FM_X_TIMEOUT_PROXIMITY
SWITCH
Undefined 1
311031 FM_Y_TIMEOUT_PROXIMITY
SWITCH
Undefined 1
311032 FM_S_TIMEOUT_PROXIMITY
SWITCH
Undefined 1
311033 FM_Z_SP_TIMEOUT_PROXIMI
TY SWITCH
20 SP/Z axis: top Proximity switch
does not respond*
1
311034 FM_D_TIMEOUT_PROXIMITY
SWITCH
Undefined 1
311035 FM_Z_IC_TIMEOUT_PROXIMIT
Y SWITCH
IC/Z axis: top Proximity switch does
not respond*
1
311036 FM_D_IC_TIMEOUT_PROXIMIT
Y SWITCH
Undefined 1
311037 FM_X_PROXIMITY
SWITCH_NICHT_FREI
Undefined 1
311038 FM_Y_PROXIMITY
SWITCH_NICHT_FREI
Undefined 1
311039 FM_S_PROXIMITY
SWITCH_NICHT_FREI
Undefined 1
311040 FM_Z_SP_PROXIMITY
SWITCH_NICHT_FREI
SP/Z axis: top Proximity switch is not
released*
1
311041 FM_D_PROXIMITY
SWITCH_NICHT_FREI
Undefined 1
311042 FM_Z_IC_PROXIMITY
SWITCH_NICHT_FREI
IC/Z axis: top Proximity switch is not
released*
1
311043 FM_D_IC_PROXIMITY
SWITCH_NICHT_FREI
Undefined 1
311044 FM_X_POS_PROXIMITY X axis: Proximity switch for position 1
