GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 201 of 251
CEID Name Description
SWITCH monitoring is off*
311045 FM_Y_POS_PROXIMITY
SWITCH
Y axis: Proximity switch for position
monitoring is off*
1
311046 FM_S_POS_PROXIMITY
SWITCH
S axis: Proximity switch for position
monitoring is off*
1
311047 FM_Z_SP_POS_PROXIMITY
SWITCH
SP/Z axis: Proximity switch for
position monitoring is off*
1
311048 FM_D_POS_PROXIMITY
SWITCH
SP/D axis: Proximity switch for
position monitoring is off*
1
311049 FM_Z_IC_POS_PROXIMITY
SWITCH
IC/Z axis: Proximity switch for position
monitoring is off*
1
311050 FM_D_IC_POS_PROXIMITY
SWITCH
IC/D axis: Proximity switch for position
monitoring is off*
1
311051 FM_X_ERROR_BIT X axis: Error bit set* 1
311052 FM_Y_ERROR_BIT Y axis: Error bit set* 1
311053 FM_S_ERROR_BIT S axis: Error bit set* 1
311054 FM_Z_SP_ERROR_BIT SP/Z axis: Error bit set* 1
311055 FM_D_ERROR_BIT SP/D axis: Error bit set* 1
311056 FM_Z_IC_ERROR_BIT IC/Z axis: Error bit set* 1
311057 FM_D_IC_ERROR_BIT IC/D axis: Error bit set* 1
311058 FM_X_WARTE_DAIN X axis: No DAIN acknowledgment* 1
311059 FM_Y_WARTE_DAIN Y axis: No DAIN acknowledgment* 1
311060 FM_S_WARTE_DAIN S axis: No DAIN acknowledgment* 1
311061 FM_Z_SP_WARTE_DAIN SP/Z axis: No DAIN acknowledgment* 1
311062 FM_D_WARTE_DAIN SP/D axis : No DAIN
acknowlegdment*
1
311063 FM_Z_IC_WARTE_DAIN IC/Z axis: No DAIN acknowledgment* 1
311064 FM_D_IC_WARTE_DAIN IC/D axis: No DAIN acknowledgment* 1
311086 FM_X_AK_UNG X axis: command currently invalid* 1
311087 FM_Y_AK_UNG Y axis: command currently invalid* 1
311088 FM_S_AK_UNG S axis: command currently invalid* 1
311089 FM_Z_SP_AK_UNG SP/Z axis: command currently invalid* 1
311090 FM_D_AK_UNG SP/D axis: command currently invalid* 1
311091 FM_Z_IC_AK_UNG IC/Z axis: command currently invalid* 1
311092 FM_D_IC_AK_UNG IC/D axis: command currently invalid* 1
311093 FM_X_AK_UNDEF X axis: command not defined* 1
311094 FM_Y_AK_UNDEF Y axis: command not defined* 1
311095 FM_S_AK_UNDEF S axis: command not defined* 1
311096 FM_Z_SP_AK_UNDEF SP/Z axis: command not defined* 1
311097 FM_D_AK_UNDEF SP/D axis: command not defined* 1
GEM for SIPLACE V7.01
Page 202 of 251 ©Siemens AG, all rights reserved
CEID Name Description
311098 FM_Z_IC_AK_UNDEF IC/Z axis: command not defined* 1
311099 FM_D_IC_AK_UNDEF IC/D axis: command not defined* 1
311100 FM_X_POSART_UNDEF X axis: positioning type not defined* 1
311101 FM_Y_POSART_UNDEF Y axis: positioning type not defined* 1
311102 FM_S_POSART_UNDEF S axis: positioning type not defined* 1
311103 FM_Z_SP_POSART_UNDEF SP/Z axis: positioning type not
defined*
1
311104 FM_D_POSART_UNDEF SP/D axis: positioning type not
defined*
1
311105 FM_Z_IC_POSART_UNDEF IC/Z axis: positioning type not defined* 1
311106 FM_D_IC_POSART_UNDEF IC/D axis: positioning type not
defined*
1
311107 FM_X_VERFAHRBEREICH X axis: destination position outside
travel range*
1
311108 FM_Y_VERFAHRBEREICH Y axis: destination position outside
travel range*
1
311109 FM_S_VERFAHRBEREICH S axis: destination position outside
travel range*
1
311110 FM_Z_SP_VERFAHRBEREICH SP/Z axis: destination position outside
travel range*
1
311111 FM_D_VERFAHRBEREICH SP/D axis: destination position outside
travel range*
1
311112 FM_Z_IC_VERFAHRBEREICH IC/Z axis: destination position outside
travel range*
1
311113 FM_D_IC_VERFAHRBEREICH IC/D axis: destination position outside
travel range*
1
311114 FM_X_REFMODE_UNDEF X axis: reference point type not
defined*
1
311115 FM_Y_REFMODE_UNDEF X axis: reference point type not
defined*
1
311116 FM_S_REFMODE_UNDEF S axis: reference point type not
defined*
1
311117 FM_Z_SP_REFMODE_UNDEF SP/Z axis: reference point type not
defined*
1
311118 FM_D_REFMODE_UNDEF SP/D axis: reference point type not
defined*
1
311119 FM_Z_IC_REFMODE_UNDEF IC/Z axis: reference point type not
defined*
1
311120 FM_D_IC_REFMODE_UNDEF IC/D axis: reference point type not
defined*
1
311121 FM_X_ZAEHLFEHLER X axis: counting error* 1
311122 FM_Y_ZAEHLFEHLER Y axis: counting error* 1
311123 FM_S_ZAEHLFEHLER S axis: counting error* 1
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 203 of 251
CEID Name Description
311124 FM_Z_SP_ZAEHLFEHLER SP/Z axis: counting error* 1
311125 FM_D_ZAEHLFEHLER SP/D axis: counting error* 1
311126 FM_Z_IC_ZAEHLFEHLER IC/Z axis: counting error* 1
311127 FM_D_IC_ZAEHLFEHLER IC/D axis: counting error* 1
311128 FM_X_REF_NICHT_GEF X axis: correct zero pulse not found* 1
311129 FM_Y_REF_NICHT_GEF Y axis: correct zero pulse not found* 1
311130 FM_S_REF_NICHT_GEF S axis: correct zero pulse not found* 1
311131 FM_Z_SP_REF_NICHT_GEF SP/Z axis: correct zero pulse not
found*
1
311132 FM_D_REF_NICHT_GEF SP/D axis: correct zero pulse not
found*
1
311133 FM_Z_IC_REF_NICHT_GEF IC/Z axis: correct zero pulse not
found*
1
311134 FM_D_IC_REF_NICHT_GEF IC/D axis: correct zero pulse not
found*
1
311135 FM_X_SERVO_FREI 63 X axis: disabled* 1
311136 FM_Y_SERVO_FREI 64 Y axis: disabled* 1
311137 FM_S_SERVO_FREI 67 S axis: disabled* 1
311138 FM_Z_SP_SERVO_FREI 68 SP/Z axis: disabled* 1
311139 FM_D_SERVO_FREI 66 SP/D axis: disabled* 1
311141 FM_X_DECODE X axis: error during command
decoding*
1
311142 FM_Y_DECODE Y axis: error during command
decoding*
1
311143 FM_S_DECODE S axis: error during command
decoding*
1
311144 FM_Z_SP_DECODE SP/Z axis: error during command
decoding*
1
311145 FM_D_DECODE SP/D axis: error during command
decoding*
1
311146 FM_Z_IC_DECODE IC/Z axis: error during command
decoding*
1
311147 FM_D_IC_DECODE IC/D axis: error during command
decoding*
1
311148 FM_X_KLEMMT_REF X axis: jamming during reference run* 1
311149 FM_Y_KLEMMT_REF Y axis: jamming during reference run* 1
311150 FM_S_KLEMMT_REF S axis: jamming during reference run* 1
311151 FM_Z_SP_KLEMMT_REF SP/Z axis: jamming during reference
run*
1
311152 FM_D_KLEMMT_REF SP/D axis: jamming during reference
run*
1
311153 FM_Z_IC_KLEMMT_REF IC/Z axis: jamming during reference 1
