GEM for SIPLACE V7.01 ©Siemens AG, all rights r eserved page 217 of 251 CEID Name De scripti on <TRANSPORTW IDTH> 610038 StopperUp Stopper up 1 610039 StopperDown Stopper down 1 610040 LiftT ableUp Lifting table up…

GEM for SIPLACE V7.01

CEID Name Description

minimum width*

611025 FM_LSAUT_VERFAHRBER Conveyor belt target width outside

travel range*

611026 FM_LSAUT_TIMEOUT Conveyor belt target width cannot be

set (timeout) *

611027 FM_LSAUT_BEIDE_ENDS Both limit switches of width

adjustment actuated*

611028 FM_LSAUT_ENDSCHALT_ZU Limit switch of width adjustment for

minimum width actuated*

611029 FM_LSAUT_ENDSCHALT_AUS Limit switch of width adjustment for

maximum width actuated*

611030 FM_LSK_MAX_SCHRITT Proximity switch not found during

conveyor belt width check*

611031 FM_LSK_PROXIMITY

SWITCH_N_FREI

Proximity switch switched before

conveyor belt width check*

610031 PCBreachedInputConveyor The light barrier of the input conveyor

signals the arrival of a PCB and

<INPUTCONVEYORSTATE> will be

updated

610032 PCBreachedCenterConveyor The light barrier of the center

conveyor signals the arrival of a PCB

,<INPUTCONVEYORSTATE> and

<CENTERCONVEYORSTATE> will

be updated

610033 PCBreachedOutputConveyor The light barrier of the output

conveyor signals the arrival of a PCB,

<CENTERCONVEYORSTATE> and

<OUTPUTCONVEYORSTATE> will

be updated

610034 PCBreachedInputConveyor2 The light barrier of the input conveyor

on twin side signals the arrival of a

PCB and

will be updated

610035 PCBreachedCenterConveyor2 The light barrier of the center

conveyor on twin side signals the

arrival of a PCB,

and

will be updated

610036 PCBreachedOutputConveyor2 The light barrier of the output

conveyor on twin side signals the

arrival of a PCB,

and

will be updated

610037 TransportWidthMeasured The SIPLACE finished the

measurement of the

GEM for SIPLACE V7.01

CEID Name Description

610038 StopperUp Stopper up 1

610039 StopperDown Stopper down 1

610040 LiftTableUp Lifting table up 1

610041 LiftTableDown Lifting table down 1

610042 CerCenterUp Ceramic substrate centering up 1

610043 CerCenterDown Ceramic substrate centering down 1

610044 TransportWidthMeasured2 The SIPLACE finished the

measurement of the

<TWINTRANSPORTWIDTH>on twin

side

610045 StopperUp2 Stopper up on twin side 1

610046 StopperDown2 Stopper down on twin side 1

610047 LiftTableUp2 Lifting table up on twin side 1

610048 LiftTableDown2 Lifting table down on twin side 1

610049 CerCenterUp2 Ceramic substrate centering up on

twin side

610050 CerCenterDown2 Ceramic substrate centering down on

twin side

610051 TakeOutInConv A PCB was taken out of the input

conveyor and

<INPUTCONVEYORSTATE> will be

updated

610052 TakeOutOutConv A PCB was taken out of the output

conveyor and

<OUTPUTCONVEYORSTATE> will

be updated

610053 TakeOutInConv2 A PCB was taken out of the input

conveyor on twin side and

will be updated

610054 TakeOutOutConv2 A PCB was taken out of the output

conveyor on twin side and

will be updated

611055 FM_BRV_AUT_SYN Autom. width adjustment not possible

in SYNCHRONOUS transport mode

611056 FM_BRV_SUCH_VER Conveyor belt width out of travel range 1

611057 FM_TSP_ABLS_NFREI Sensor of the output conveyor not

released

611058 FM_TSP_ANGEKOMMEN next station can’t take over PCB 1

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these fiducials

collection events.

GEM for SIPLACE V7.01

&RSODQDULW\

CEID Name Description

711001 FM_CO_Z_KLEMMUNG Coplanarity: Clamping of Z-axis does

not work*

711002 FM_CO_INIT Coplanarity module cannot be

initialized*

711003 FM_CO_KOMM_TIMEOUT Timeout during reception from

coplanarity*

711004 FM_CO_KOMM_CHK_NOK Check sum error of answer from

coplanarity*

711005 FM_CO_KOMM_STX Answer from coplanarity has no STX* 1

711006 FM_CO_KOMM_OVERFLOW Coplan.: Communication buffer

overflow on MC*

711007 FM_CO_KOMM_RIO_FEHLER Coplan.: Software error during system

call RIO*

711008 FM_CO_BEFEHL_NAUSF Coplanarity cannot execute

command*

711009 FM_CO_BEFEHL_NVOLLST Command to coplanarity is not

complete*

711010 FM_CO_BE_DSC_NVOLLST Component description of coplanarity

is not complete*

711011 FM_CO_DATEN_WERT_UNG Coplan.: Data value outside of range* 1

711012 FM_CO_DATEN_FORMAT_UN

Command data format to coplanarity

is invalid*

711013 FM_CO_LOETPASTE_NULL Coplanarity tolerance is zero* 1

711014 FM_CO_KOMM_FEHLER Undefined error message* 1

711015 FM_CO_CHKSUM Check sum error of coplanarity* 1

711016 FM_CO_BREAK Coplanarity has received a hardware

break*

711017 FM_CO_KEIN_STX Message to coplanarity has no STX* 1

711018 FM_CO_ID_UNBEK Undefined error message* 1

711019 FM_CO_P_ID_UNBEK Coplan.: Parameter number unknown* 1

711020 FM_CO_READ_PARAM Coplan.: Attempt to modifify a Read

Only Para*

711021 FM_CO_ANZ_GRP_GROSS Coplan.: Component description has

too many groups*

711022 FM_CO_BE_ID_UNBEK Coplan.: Component number invalid* 1

711023 FM_CO_BE_NAKTUELL Coplan.: Component will not be

processed*

711024 FM_CO_BE_ID_NVORH Coplan.: Component not loaded* 1

711025 FM_CO_R_ID_UNBEK Coplan.: Row number invalid* 1
