GEM for SIPLACE V7.01
Page 228 of 251 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
nozzle changer
1120074 GUIPickUpNoz Message from GUI: Pick-up Nozzle 1
1120075 GUIMeaVac Message from GUI: Measure vacuum 1
1120076 GUIReqNoz Message from GUI: Request nozzle
on IC-Head
1
1120077 GUINozChaConfIC Message from GUI: Request nozzle
changer configuration for IC-Head
1
1120078 GUIConNozChaConfIC Message from GUI: Confirm nozzle
changer configuration for IC-Head
1
1120079 GUIGanSerPos Message from GUI: Move gantry to
service position and
<GUIGANTRYNR> will be updated
1
1120080 GUIGanWaitPos Message from GUI: Move gantry to
waiting position and
<GUIGANTRYNR> will be updated
1
1120081 GUIGanToZero Message from GUI: Move gantry to
zero point and <GUIGANTRYNR> will
be updated
1
1120082 GUIGanRefRun Message from GUI: Gantry reference
run and <GUIGANTRYNR> will be
updated
1
1120083 GUIPCBtoCenter Message from GUI: Move PCB in the
center conveyor
1
1120084 GUIPCBtoOutput Message from GUI: Move PCB in the
output conveyor
1
1120085 GUIStopper Message from GUI: Actuate stopper 1
1120086 GUILiftingTable Message from GUI: Actuate lifting
table
1
1120087 GUITransSlow Message from GUI: Transport slow 1
1120088 GUITransFast Message from GUI: Transport fast 1
1120089 GUITransStop Message from GUI: Transport stop 1
1120090 GUIReqTransState Message from GUI: Request transport
state
1
1120091 GUITransWiderSlow Message from GUI: Transport wider
slow
1
1120092 GUITransWiderFast Message from GUI: Transport wider
fast
1
1120093 GUITransNarSlow Message from GUI: Transport
narrower slow
1
1120094 GUITransNarFast Message from GUI: Transport
narrower fast
1
1120095 GUIMeaTransWidth Message from GUI: Measure
transport width
1
1120096 ToGUInNewSetUo Message to GUI: NewSetUp 1
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 229 of 251
&(,' 1DPH 'HVFULSWLRQ
1120097 ToGUIPPname Message to GUI: Placement Program
Name
1
1120098 ToGUIActionText Message to GUI: Send
<GUIACTIONTEXT>
1
1120099 ToGUIClrActionText Message to GUI: Clear
<GUIACTIONTEXT>
1
1120100 ToGUIStateText Message to GUI: Send
<GUISTATETEXT>
1
1120101 ToGUIWaitMaData Message to GUI: Waiting for machine
data
1
1120102 ToGUIRefRunComplete Message to GUI: Reference run
completed
1
1120103 ToGUIMachineReady Message to GUI: Machine ready to
process
1
1120104 ToGUIStopButton Message to GUI: Stop button pressed 1
1120105 ToGUIEmergencyButton Message to GUI: Emergency button
pressed
1
1120106 ToGUIErrGantry1 Message to GUI: Fatal error gantry 1 1
1120107 ToGUIErrGantry2 Message to GUI: Fatal error gantry 2 1
1120108 ToGUITrackEmptyGantry1 Message to GUI: Track empty gantry
1
1
1120109 ToGUITrackEmptyGantry2 Message to GUI: Track empty gantry
2
1
1120110 ToGUINozzleConfGantry1 Message to GUI: Nozzle configuration
gantry 1
1
1120111 ToGUINozzleConfGantry2 Message to GUI: Nozzle configuration
gantry 2
1
1120112 ToGUITransportError Message to GUI: Transport error 1
1120113 ToGUIFiducialError Message to GUI: Fiducial error 1
1120114 ToGUISingleStep Message to GUI: Single step 1
1120115 ToGUIwithoutLCU Message to GUI: Running without
LCU
1
1120116 ToGUIwithLCU Message to GUI: Running with LCU 1
1120117 ToGUIBarcodeError Message to GUI: PCB-Barcode error 1
1120118 RepGUIStart Reply to GUI: Start 1
1120119 RepGUISTOP Reply to GUI: Stop 1
1120120 RepGUIContinue Reply to GUI: Continue 1
1120121 RepGUIAbort Reply to GUI: Abort 1
1120122 RepGUISingleFuncGan1 Reply to GUI: Entry single function
gantry 1
1
1120123 RepGUISingleFuncGan2 Reply to GUI: Entry single function
gantry 2
1
1120124 RepGUITransportFunc Reply to GUI: Entry transport function 1
GEM for SIPLACE V7.01
Page 230 of 251 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
1120125 RepGUIFiducialTeach Reply to GUI: Entry fiducial teaching 1
1120126 RepGUIPackageForm Reply to GUI: Entry package form
modification
1
1120127 RepGUIwithoutLCU Reply to GUI: Running without LCU 1
1120128 RepGUILoadPP Reply to GUI: Load Placement
Program
1
1120129 RepGUIPassThrough Reply to GUI: PCB-Barcode error
„pass through“
1
1120130 RepGUIRemovePCB Reply to GUI: PCB-Barcode error
„remove PCB“
1
1120131 RepGUIBCbyKeyboard Reply to GUI: PCB-Barcode entered
by keyboard
1
1120132 RepGUIReqMaOption Reply to GUI: Request machine
options
1
1120133 RepGUIReqMaConf Reply to GUI: Request machine
configuration
1
1120134 RepGUISetMaOption Reply to GUI: Set machine options 1
1120135 RepGUISingleStepOn Reply to GUI: Set single step mode
on
1
1120136 RepGUISingleStepOff Reply to GUI: Set single step mode
off
1
1120137 RepGUITableProgDownloa
d
Reply to GUI: Table program
download
1
1120138 RepGUIAllTrackRefill Reply to GUI: Set all tracks refilled 1
1120139 RepGUITrackRefill Reply to GUI: Set track refilled 1
1120140 RepGUIFeederBankRefill Reply to GUI: Set feeder bank refilled 1
1120141 RepGUILinearFeederOn Reply to GUI: Vibrate linear feeders
ON
1
1120142 RepGUILinearFeederOff Reply to GUI: Vibrate linear feeders
OFF
1
1120143 RepGUIReqInvenWPC Reply to GUI: Request WPC fill stand 1
1120144 RepGUIReqMaxWPC Reply to GUI: Request WPC
maximum fill stand
1
1120145 RepGUISetInvenWPC Reply to GUI: Set WPC fill stand 1
1120146 RepGUIReqConfWPC Reply to GUI: Request WPC
configuration
1
1120147 RepGUIRefillPosWPC Reply to GUI: WPC to refill position 1
1120148 RepGUIContinueWPC Reply to GUI: WPC continue (leave
refill position)
1
1120149 RepGUITransportWPC Reply to GUI: WPC to transport
position
1
1120150 RepGUIRefRunWPC Reply to GUI: WPC reference run 1
1120151 RepGUIImageGan1On Reply to GUI: Image from camera at 1
