GEM for SIPLACE V7.01
Page 232 of 251 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
1120176 RepGUITurnDonIC Reply to GUI: Turn d-axis on IC-head 1
1120177 RepGUIZaxisOn Reply to GUI: Activate z-axis
clamping on IC-head
1
1120178 RepGUIZaxisOff Reply to GUI: Deactivate z-axis
clamping on IC-head
1
1120179 RepGUIComAirOn Reply to GUI: IC-Head Compressed
air ON
1
1120180 RepGUIComAirOff Reply to GUI: IC-Head Compressed
air OFF
1
1120181 RepGUIVacOn Reply to GUI: IC-Head Vacuum ON 1
1120182 RepGUIVacOff Reply to GUI: IC-Head Vacuum OFF 1
1120183 RepGUIStoreNozzle Reply to GUI: Store nozzle in nozzle
changer
1
1120184 RepGUIPickUpNoz Reply to GUI: Pick-up Nozzle 1
1120185 RepGUIMeaVac Reply to GUI: Measure vacuum 1
1120186 RepGUIReqNoz Reply to GUI: Request nozzle on IC-
Head
1
1120187 RepGUINozChaConfIC Reply to GUI: Request nozzle
changer configuration for IC-Head
1
1120188 RepGUIConNozChaConfIC Reply to GUI: Confirm nozzle changer
configuration for IC-Head
1
1120189 RepGUIGanSerPos Reply to GUI: Move gantry to service
position
1
1120190 RepGUIGanWaitPos Reply to GUI: Move gantry to waiting
position
1
1120191 RepGUIGanToZero Reply to GUI: Move gantry to zero
point
1
1120192 RepGUIGanRefRun Gantry reference run 1
1120193 RepGUIPCBtoCenter Reply to GUI: Move PCB in the center
conveyor
1
1120194 RepGUIPCBtoOutput Reply to GUI: Move PCB in the output
conveyor
1
1120195 RepGUIStopper Reply to GUI: Actuate stopper 1
1120196 RepGUILiftingTable Reply to GUI: Actuate lifting table 1
1120197 RepGUITransSlow Reply to GUI: Transport slow 1
1120198 RepGUITransFast Reply to GUI: Transport fast 1
1120199 RepGUITransStop Reply to GUI: Transport stop 1
1120200 RepGUIReqTransState Reply to GUI: Request transport state 1
1120201 RepGUITransWiderSlow Reply to GUI: Transport wider slow 1
1120202 RepGUITransWiderFast Reply to GUI: Transport wider fast 1
1120203 RepGUITransNarSlow Reply to GUI: Transport narrower
slow
1
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 233 of 251
&(,' 1DPH 'HVFULSWLRQ
1120204 RepGUITransNarFast Reply to GUI: Transport narrower fast 1
1120205 RepGUIMeaTransWidth Reply to GUI: Measure transport
width
1
1120206 RepGUIReqTrayWPC Reply to GUI: WPC request tray 1
1120207 GUIRetAllNoz Mesage from GUI: Return all nozzles
to the nozzle changer,
<GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1
1120208 GUIPickupAllNoz Mesage from GUI: Pick up all nozzles,
<GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1
1120209 GUIThrowAllNoz Mesage from GUI: Throw away all
nozzles, <GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1
1120210 GUIReplace1Noz Mesage from GUI: Replace one
nozzle, <GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1
1120211 RepGUIRetAllNoz Reply to GUI: Return all nozzles to the
nozzle chnager
1
1120212 RepGUIPickupAllNoz Reply to GUI: Pichk up all nozzles 1
1120213 RepGUIThrowAllNoz Reply to GUI: Throw away all nozzles 1
1120214 RepGUIReplace1Noz Reply to GUI: Replace one nozzle 1
1120215 ToGUICompBarcode The component barcode list is
transmitted to the GUI
1
1120216 ToGUICrtlModeChanged Control Mode change (Stand-alone,
GEM-Host or LCU) is completed.
1
1120217 ToGUIVSOpFinished Vision Operation is completed 1
1120218 GUIGetCrtlMode GUI asks for the current Control Mode
(Stand-alone, GEM-Host, LCU)
1
1120219 GUISetCrtlMode GUI transmits the new Control Mode
(OK-Button)
1
1120220 GUIVSSetText A text is inserted in the „vision screen“ 1
1120221 GUIGetFluxPF GUI asks for the package forms,
which should be dipped in flux
1
1120222 GUISetFluxPF GUI transmits the list of package
forms which should be dipped in flux
(OK-Button)
1
1120223 GUIGetFluxPara GUI asks for the current flux
parameters
1
1120224 GUISetFluxPara GUI set flux parameters (OK-Button) 1
1120225 GUISaveVSPicture Current image in the vision system
should be saved on floppy
1
1120226 GUIVSDoEval Start vision evaluation 1
1120227 RepGUIGetCrtlMode Reply to GUI: GUI asks for the current
Control Mode (Stand-alone, GEM-
1
GEM for SIPLACE V7.01
Page 234 of 251 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
Host, LCU)
1120228 RepGUISetCrtlMode Reply to GUI: GUI transmits the new
Control Mode (OK-Button)
1
1120229 RepGUIVSSetText Reply to GUI: A text is inserted in the
„vision screen“
1
1120230 RepGUIGetFluxPF Reply to GUI: GUI asks for the
package forms, which should be
dipped in flux
1
1120231 RepGUISetFluxPF Reply to GUI: GUI transmits the list of
package forms which should be
dipped in flux (OK-Button)
1
1120232 RepGUIGetFluxPara Reply to GUI: GUI is asking for the
current flux parameters
1
1120233 RepGUISetFluxPara Reply to GUI: GUI set flux parameters
(OK-Button)
1
1120234 RepGUISaveVSPicture Reply to GUI: Current image in the
vision system should be saved on
floppy
1
1120235 RepGUIVSDoEval Reply to GUI: Start vision evaluation 1
1120236 ToGUISkip PCB not fully populated
1120237 ToGUIMCready MC Announce
1120238 ToGUISitestStarted SITEST was started
1120239 ToGUISitestFinished SITEST finished
1120240 GUIReady Meassage „Ready“from GUI
1120241 GUIReturnOneNozzle Return one nozzle to the nozzle
changer, <GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1120242 GUIPickUpOneNozzle Pick Up a new nozzle,
<GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1120243 GUIRejectOneNozzle Throw away one nozzle,
<GUINOZZLETYPE> and
<GUIGANTRYNR> will be updated
1120244 GUIActuateNozzleChanger Actuate the clamping mechanism of
the nozzle changer
1120245 GUIAckNozzleChange Acknowledge nozzle change
1120246 GUISkipTrack Skip track
1120247 GUIEndSkip End track skipping
1120248 GUIReqSitestStart Request to start the SITEST software
1120249 RepGUIReady Reply to GUI: Meassage „Ready“from
GUI
1120250 RepGUIReturnOneNozzle Reply to GUI: Return one nozzle to the
nozzle changer
1120251 RepGUIPickUpOneNozzle Reply to GUI: Pick Up a new nozzle
