GEM for SIPLACE V7.01

CEID Name Description

1611128 FM_HDA_AKTUELL_HST_HEADER HDP: Faulty header of

process program file*

1611129 FM_HDA_AKTUELL_HST_ALL HDP: Faulty process program

file*

1611130 FM_HDA_INAKTIV HDP: Inactive host data

preparation*

1611131 FM_HDA_PARSE HDP: Faulty placement

program*

1611132 FM_HDA_AKTUELL_DAT_READ HDP: Copy of MC data

structures cannot be sent to

GEM*

1611133 FM_HDA_GF_DATEI HDP: GF file cannot be read* 1

1611134 FM_HDA_MK_DATEI HDP: MK file cannot be read* 1

1611135 FM_MK_FELDGRENZE Field boundaries in fiducial

data were exceeded*

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these CAN-bus

collection events.

7UROOH\

CEID Name Description

1711001 FM_WAG_CODE_ERROR Check sum error in table program* 1

1711002 FM_WAG_UNBEK_TELE Unknown message to table* 1

1711003 FM_WAG_BE_ENTSORG_70 Caution: Filling level of rejected.

components receptacle 70%*

1711004 FM_WAG_BE_ENTSORG_VOLL Receptacle of rejected components

full*

1711005 FM_WAG_F_KOMM_UNTERBR Communication table-feeder

interrupted*

1711006 FM_WAG_F_KOMM_NOK Communication table-feeder

disturbed*

1711007 FM_WAG_47 Undefined error number of

component table (code 47) *

1711008 FM_WAG_48 Undefined error number of

component table (code 48) *

1711009 FM_WAG_49 Undefined error number of

component table (code 49) *

1711010 FM_WAG_50 Feeder rail of bulk case feeder not

installed*

1711011 FM_WAG_F_ABLAUF_NOK Software-Operation in feeder

disturbed*

1711012 FM_WAG_F_FOL_GERISSEN Foil torn* 1

1711013 FM_WAG_F_FOL_NICHT_AB Foil not removed* 1

GEM for SIPLACE V7.01

CEID Name Description

1711014 FM_WAG_F_TRANSPORT_NOK Transport in feeder disturbed* 1

1711015 FM_WAG_F_GURTENDE Caution: Belt end* 1

1711016 FM_WAG_KEIN_BE_ENTSORG No component disposal belt

available

1711026 FM_WAG_RIO Communication with table

interrupted

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these trolley

collection events.

0LVFHOODQHRXV

CEID Name Description

2010001 CoverOpen The protective covers was opened 1

2010002 CoverClosed The protective covers was closed 1

2010003 PCBready Placement is finished for the PCB in the

center conveyor. The PCB will now be

transported to the output conveyor.

<GANTRYINFOREV1> and

<GANTRYINFOREV2> or

<GANTRYINFOIC> will be updated.

34,

35,

2010004 TrackFull Track reset to full and

<COMPONENTNAME>,

<MASCHINESIDE>, <TRACKNUMBER>,

<DIVISION>, <LEVEL>, <GANTRYID>,

will be updated

2010005 TrackEmpty Track set to empty and

<COMPONENTNAME>,

<MASCHINESIDE>, <TRACKNUMBER>,

<DIVISION>, <LEVEL>, <GANTRYID>,

will be updated

2010006 RefRunGantry1 Reference run complete for the gantry 1

axis

2010007 RefRunGantry2 Reference run complete for the gantry 2

axis

2010008 TableDownload Software downloaded to the table and

<SOFTWAREREVTABLE> will be

updated.

2010009 SingleCircuitOmit The machine signals that it found a single

circuit to omit (Ink Punkt)

2010010 TapeCutLeft Tape cut on left side of machine 1

2010011 TapeCutRight Tape cut on right side of machine 1

2010013 PCBstartProcessing Start of the placement process for the 1

GEM for SIPLACE V7.01

PCB in the center conveyor

2010015 MachineReStarted SIPLACE station is re-booting 1

2010016 PickupError An Pickup-Error has occured and

<SEGMENT>, <COMPONENTNAME>,

<MASCHINESIDE>, <TRACKNUMBER>,

<DIVISION>, <LEVEL>, <GANTRYID>,

will be updated.

This event is triggered on every

movement of the z-axis in the pickup-

position without having picked up a

component.

2010017 PlaceError An Place-Error has occured and

<SEGMENT>,

<REFERENCEDESIGNATOR>,

<COMPONENTNAME>, <GANTRYID>,

<GANTRYGROUPID>, <HEADID>,

<PACKAGEFORMNUMBER> and

<PLACEERRORDESCRIPTION> will be

updated

)OX[

CEID Name Description

2111001 FM_FLUX_SYSFEHL Flux module: System error in SW

module*

2111002 FM_FLUX_WRITE_FLUXMA Flux module: Error writing FLUX.MA file* 1

2111003 FM_FLUX_READ_FLUXMA Flux module: Error reading FLUX.MA file* 1

2111004 FM_FLUX_NOT_INIT Flux pump not initialized* 1

2111005 FM_FLUX_INITIALISIEREN Error upon initialization of flux pump* 1

2111006 FM_FLUX_VALVE Faulty flux valve* 1

2111007 FM_FLUX_PLUNGER Faulty flux syringe* 1

2111008 FM_FLUX_TIMEOUT Timeout of flux pump* 1

2111009 FM_FLUX_COMMAND Incorrect command to flux pump* 1

2111010 FM_FLUX_CHECKSUMME Checksum error upon activation of flux

pump*

2111011 FM_FLUX_Z_OBEN Z-axis of flux nozzle not in raised

position*

2111012 FM_FLUX_Z_KLEMMT Z-axis of flux nozzle jammed* 1

2111013 FM_FLUX_LEER Flux tank empty* 1

2111014 FM_FLUX_NACHFUELLEN Warning: Replenish flux tank* 1

* Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these flux

collection events.
