GEM for SIPLACE V7.01
Page 36 of 251 ©Siemens AG, all rights reserved
The SIPLACE supports the following Event Report message formats for non-GEM Host
implementations.
S6F3/S6F4
S6F9/S6F10
S6F13/S6F14
5HODWHG9DULDEOHV
The following table lists the variables (SV's, EC's, or DVVALS) which are relevant to data
collection setup and maintenance. This section does not list the variables which contain
equipment-specific information. For a more complete description of specific variables,
see "Appendix A -- Variables".
Variable Name VID
GEMLIMITSTIMER 1002050
GEMLIMITSVID 1002047
GEMEVENTLIMIT 1002048
GEMTRANSTYPE 1002049
ECIDCHANGE 1002036
5HODWHG(YHQWV
The following lists the collection events (CEIDs) which are relevant to data collection. In
addition to these, each variable which is eligible for limits monitoring must have a specific
collection event associated with it. For a more complete description of these events, see
"Appendix B -- Collection Events" or the description in this chapter.
Collection Event CEID
EqConstChange 1000001
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 37 of 251
$ODUP0DQDJHPHQW
The SIPLACE has a fixed set of alarm conditions which can occur. Each alarm is
identified by a unique Alarm ID (ALID), and has an associated severity code (ALCD) and
alarm text (ALTX). The possible alarms are shown in "Appendix C -- Alarms".
$ODUP6WDWHV
Each alarm (ALID) can be in either of two states: CLEAR (off) or SET (on). Several
alarms can be SET simultaneously. At power up, all Alarms are cleared.
5HSRUWLQJ
The SIPLACE reports alarms to the Host when they occur, without Host action, using the
alarm report message S5F1 or configurable option, depending on CONFIGALARMS (VID
1002018). The transition of an ALID from OFF to ON is referred to as "going on" or
"leading edge", and the transition from ON to OFF as "going off" or "trailing edge". The
Equipment reports both leading and trailing edge transitions.
The equipment has two CEIDs for each ALID, one for the "going on" transition and one for
the "going off" transition. In addition to the Alarm Report, the Equipment sends an Event
Report if the CEID associated with the alarm change is enabled. If the CEID is enabled
and no report is defined, a "null" Event Report is sent. The event report for an alarm
transition is sent if it is enabled, even if the reporting for the alarm is disabled.
(QDEOH'LVDEOH
The Host can use S5F3 (Enable/Disable Alarms) to control which alarms the SIPLACE
should report. Using S5F3, the Host can specify for each ALID whether the Equipment
should report that alarm when it occurs. When an alarm transition occurs, if that ALID is
enabled the Equipment will send an alarm report message to the Host. If the ALID is
disabled, the Equipment will not send the alarm message. The Host can use S2F37 to
enable or disable the CEIDs associated with these alarm transitions.
The SIPLACE saves Alarm Enable/Disable settings on a disk file. When the Equipment
powers up, it will restore Alarm Enable/Disable settings to the same condition they had at
power off.
+RVW5HTXHVWV$ODUP6WDWXV
The Host can use S5F5 to request the SIPLACE to report all alarms which exist and the
ON/OFF state for each.
The Host can use S5F7 which is similar, but which causes the Equipment to report only
those alarms (ALIDs) which are Enabled, regardless of whether the alarm is ON or OFF.
&RPSDWLELOLW\
The SIPLACE supports the following Alarm Report message formats for older host
implementations.
S5F71/S5F72
S5F73/S5F74
5HODWHG9DULDEOHV
The following table lists the variables (SV's, EC's, or DVVALS) which are relevant to alarm
management. For a more complete description of these variables, see "Appendix A --
Variables".
Variable Name VID
GEM for SIPLACE V7.01
Page 38 of 251 ©Siemens AG, all rights reserved
Variable Name VID
CONFIGALARMS 1002018
WBITS5 1002019
ALARMID 1002013
ALARMSERIAL 1002015
ALARMSENABLED 1002020
ALARMSSET 1002021
ALARMSTATE 1002014
5HODWHG&ROOHFWLRQ(YHQWV
Each alarm defined on the SIPLACE has two unique collection events associated with it, a
"Going-On" event, and a "Going-Off" event. The CEIDs are listed in "Appendix B --
Collection Events".
3URFHVV3URJUDP0DQDJHPHQW
Processing on the SIPLACE is controlled by Process Programs. The Equipment requires
selection of a Process Program for each process. The SIPLACE supports the use of
unformatted process programs.
Equipment Management of Process Programs
The SIPLACE provides a Process Program Library, implemented as a set of ASCII files
maintained on a hard disk. Each Process Program is identified by a unique Process
Program ID (PPID). A PPID consists of ASCII characters
The Equipment Operator may modify any one of the Process Programs stored on the
Equipment. The host will be notified via the GemPPChangeEvent (CEID 1000016)
Collection Event if the Operator creates, changes, or deletes a Process Program. The
Equipment Operator can also select a PPID to be uploaded to the Host (S7F3), or
download from the Host (S7F5).
Host Management of Process Programs
Process Programs are saved to disk on the equipment. Process Programs are typically
created and updated at the SIPLACE. However, the SIPLACE provides complete facilities
for the Host to manage the storage and use of Process Programs. This allows the
SIPLACE to operate cooperatively Host-implemented systems. The Host has the
following capabilities.
The Host can upload a Process Program from the SIPLACE Library by using S7F5
(Process Program Request). The equipment operator can also initiate a Process
Program Upload through the SIPLACE's user interface.
The Host can download a Process Program to the SIPLACE library by using S7F3
(Process Program Send). The Host may send S7F1 (Multi-block Inquire) to the
equipment before sending a multi-block Process Program. The equipment operator can
also initiate a Process Program Download through the SIPLACE's user interface.
The Host can delete one or more Process Programs from the SIPLACE library by using
S7F17 (Process Program Delete).
The Host can determine which Process Programs are currently stored in the SIPLACE
library by using S7F19 (Process Program Directory).
5HODWHG9DULDEOHV
The following table lists the variables (SV's, EC's, or DVVALS) which are relevant to
process program management. For a more complete description of these variables, see
"Appendix A -- Variables".
