GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 43 of 251
 0DWHULDO0RYHPHQW
Material movement on the SIPLACE consists of three components: 1) The input
conveyor 2) The center conveyor; and 3) The output conveyor. Every PCB enters the
SIPLACE at the input conveyor, is than transported to the center conveyor, where the
work is done. After finishing placement the PCB is send to the output conveyor, where the
operator can take it out of the machine.
 5HODWHG9DULDEOHV
The following table lists the which are relevant to material movement. For a more
complete description of these variables, see "Appendix A -- Variables".
Variable Name VID
InputConveyorState 612001
CenterConveyorState 612002
OutputConveyorState 612003
TWINInputConveyorState 612004
TWINCenterConveyorState 612005
TWINOutputConveyorState 612006
 5HODWHG&ROOHFWLRQ(YHQWV
There are 3 CEID related to then Material Movement Capability. For a more complete
listing of these collection events, please see "Appendix B -- Collection Events".
Collection Event CEID
PCBreachedInputConveyor 610031
PCBreachedCenterConveyor 610032
PCBreachedOutputConveyor 620033
PCBreachedInputConveyor2 611034
PCBreachedCenterConveyor2 610035
PCBreachedOutputConveyor2 610036
GEM for SIPLACE V7.01
Page 44 of 251 ©Siemens AG, all rights reserved
 (TXLSPHQW7HUPLQDO6HUYLFHV
The SIPLACE supports exchange of free text messages with the Host (SECS Stream 10).
This Equipment accepts the following messages from the Host, and responds accordingly
if the W-Bit is set to 1:
S10F3 /* Single Line Data */
S10F5 /* Multi-Line Data */
S10F9 /* Broadcast */
The message text will be displayed on the Equipment's CRT. Collection Event S10Ack
(CEID 1000002) occurs once the operator has acknowledged the message and an Event
Report will be sent to the Host (if enabled).
The S10F3 and S10F9 are restricted to a single TEXT data item, but S10F5 can contain
multiple TEXT data items. Each TEXT data item is limited to 160 characters. Each data
item in S10F5 will be displayed on a separate line at the equipment.
If the Operator has not acknowledged an existing message when the Host sends another
message, the new message will be displayed and the old one discarded.
The Host can send a message with a 0-length text to clear the Operator text display.
Also, the Equipment allows the operator to send a single block message to the Host via
S10F1. The maximum length of this text is 160 characters. The S10F2 response from
the Host is ignored.
 5HODWHG9DULDEOHV
There are no relevant variable for the Equipment Terminal Capability.
 5HODWHG&ROOHFWLRQ(YHQWV
There is one CEID related to the Equipment Terminal Capability. For a more complete
listing of these collection events, please see "Appendix B -- Collection Events".
Collection Event CEID
HostMsgAckr 1000002
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 45 of 251
 (UURU0HVVDJHV
The SIPLACE provides standard Stream 9 messages to report SECS-II errors. See 4.9
"SECS Message Detail" for detailed description of these messages:
S9F1 Unrecognized Device ID
S9F3 Unrecognized Stream
S9F5 Unrecognized Function
S9F7 Invalid Data
S9F9 Transaction Timeout
S9F11 Data Too Long
 5HODWHG9DULDEOHV
There are no Variables relevant for Error Messages.
 5HODWHG&ROOHFWLRQ(YHQWV
There are no CEID related to Error Messages.
