GEM for SIPLACE V7.01
Page 86 of 251 ©Siemens AG, all rights reserved
The Host can delete all report definitions and associated links in the Equipment by using
the following special format:
S2F33 W * H->E
<L [2]
<U4 DATAID> * DATAID
<L>
> .
 6)'HILQH5HSRUW$FNQRZOHGJH
S2F34 * H<-E
<B [1] DRACK> . * DRACK - Acknowledge Code
Normally, DRACK is zero. Any non-zero DRACK indicates the Equipment has rejected
the entire S2F33 message.
DRACK Description
0x00 OK
0x02 Denied. Invalid format.
0x03 Denied. At least one RPTID already defined.
0x04 Denied. At least one VID does not exist.
 6)/LQN(YHQW5HSRUW
S2F35 W * H->E, Multiblock
<L [2]
<U4 DATAID> * DATAID
<L
<L [2]
<U4 CEID> * Collection Event ID
<L
<U4 RPTID> * Report ID
...
>
>
...
>
> .
The Host links Report Ids to selected Collection Event Ids. The Specified CEIDs are
initialized to "disabled". See S2F37 for enabling CEIDs.
If S2F35 is multi-block, the Host may optionally send the S2F39/S2F40 Inquire/Grant
transaction before sending S2F35, but the SIPLACE does not require it.
The Equipment ignores DATAID.
The Host can eliminate all links for a CEID by sending the following format in S2F35 for
that CEID:
GEM for SIPLACE V7.01
©Siemens AG, all rights reserved page 87 of 251
...
<L [2]
<U4 CEID> * Collection Event ID
<L>
>
...
 6)/LQN(YHQW5HSRUW$FNQRZOHGJH
S2F36 * H<-E
<B [1] LRACK> . * LRACK - Acknowledge Code
Normally, LRACK is zero. Any non-zero LRACK indicates the Equipment has rejected the
entire S2F35 message.
LRACK Description
0x00 OK
0x02 Denied. Invalid format.
0x03 Denied. At least one CEID link already defined
0x04 Denied. At least one CEID does not exist.
0x05 Denied. At least one RPTID does not exist.
Other Equipment has rejected the S2F35 message
 6)(QDEOH'LVDEOH(YHQW5HSRUW
S2F37 W * H<-E
<L [2]
<BOOLEAN CEED> * Coll. Event Enable
<L
<U4 CEID> * Collection Event ID
...
>
> .
The Host enables reporting for a list of Collection Event IDs, or disables reporting for the
list.
CEED is "True" to indicate Enabling, or "False" to indicate Disabling reporting for the
specified CEIDs.
The Host can enable or disable all CEIDs by using the following special format:
GEM for SIPLACE V7.01
Page 88 of 251 ©Siemens AG, all rights reserved
S2F37 W * H->E
<L [2]
<BOOLEAN CEED> * Coll. Event Enable
<L>
> .
 6)(QDEOH'LVDEOH(YHQW5HSRUW$FNQRZOHGJH
S2F38 * H<-E
<B [1] ERACK> . * ERACK - Acknowledge Code
Normally, ERACK is zero. Any non-zero ERACK indicates the Equipment has rejected
the entire S2F37 message.
ERACK Description
0x00 OK
0x01 Denied. At least one CEID does not exist.
 6)0XOWL%ORFN
S2F39 W * H->E
<L [2]
<U4 DATAID> * DATAID
<U4 DATALENGTH>
> .
The Host may send this Inquire/Grant transaction preceding any multiblock S2F33 or
S2F35. For this Equipment, this Inquire/Grant is optional. The Equipment accepts it, but
ignores it, commits no resources, and initiates no Conversation Timeout. The Equipment
accepts multiblock S2F33 or S2F35 even if not preceded by the Inquire/Grant.
 6)0XOWL%ORFN*UDQW
S2F40 * H<-E
<B [1] 00> . * GRANT
The Equipment always sends GRANT value "0".
