Siplace productivity lift single conveyor (base_ 00116310-03)_20211118_071734 - 第8页
Siplace productivity lift single conveyor (base: 00116310-03) Page 8 / 8 18.11.2021 Pos. Item no. Description Part marking 00354823-01 SPL CABLE SET WITH ENERGY CHAIN, XS3 Spare Part Powered by TCPDF (www.tcpdf.org)
Siplace productivity lift single conveyor (base: 00116310-03)
Page 6 / 8 18.11.2021
Pos. Item no. Description Part marking
00116326-01 SINGLE CONVEYOR (BASE:
00116310-03)
1 00347448-04 INTERFACE MODULE AMI 3.0 SPARE PART
2 00347449-01 RELAIS, PLUG-/PRINT- 5A SPARE
3 00347461-01 POWER PACK 15A 24V DC, PSU
500L24
Spare Part
4 00347475-02 OPTO-ELECTRONIC FOR STEP
MOTOR DKO, 24V
5 00347478-01 PROXIMITY SWITCH IQ10-03BPS-
KT1
Spare Part
6 00347478-01 PROXIMITY SWITCH IQ10-03BPS-
KT1
Spare Part
7 00347490-01 REFLECTION-LIGHT-SENSOR
WT4-2P330
Spare Part
8 00347490-01 REFLECTION-LIGHT-SENSOR
WT4-2P330
Spare Part
9 00348193-02 CONTROL UNIT CAN/MM101 SPARE PART
10 00348195-02 CONTROL PANEL CAN/P50 SPARE
11 00348197-01 PNEUMATIC CYL. UNIT
DNC-40-125-PPV-A
12 00348198-01 SOLENOID VALVE UNIT MYH-5/3G-
M5-L-LED
13 00349121-02 MICRO STEP POWER OUTPUT
K480216A-24
SPARE PART
14 00348192-02 SUPPLEMENT-CONTROL-MODUL,
CAN/MS1
Spare Part
15 00349541-01 CLAMPING CARTRIDGE UNIT
KP-12-600
SPARE PART
16 00352706-01 LAMP 36V 5W PRODUCTIVITY LIFT WEAR PART
17 00352857-01 DC-MOTOR WL 1 BG 62X60 SG80 Spare Part
18 00352858-01 MOTOR CONTROLLER SCA-B4-70-10 Spare Part
19 00352859-01 OPTO ELECTRONIC MAXI-MW-8-30 Spare Part
20 00352860-02 SAFETY RELAY SNE 4004 K-A SPARE
21 00352881-02 SAFETY RELAY SNO 4003 K-A SPARE
22 00352882-01 VALVE MYH-3-M5-L-LED SPARE
23 00352883-01 TOOTHED BELT 2000-5M-25 HDT Wear Part
24 00353549-01 DC-MOTOR GL42X40,PLG42K
32:1SCREENED SPL
SPARE PART
25 00353549-01 DC-MOTOR GL42X40,PLG42K
32:1SCREENED SPL
SPARE PART
Siplace productivity lift single conveyor (base: 00116310-03)
Page 7 / 8 18.11.2021
Pos. Item no. Description Part marking
26 00354351-02 STEPPING-MOTOR SPL
4T5718M3308
SPARE PART
27 00354352-01 CYLINDER SWITCH SME-8-K-LED-24
28 00354468-01 ELECTRICAL BUZZER
29 00354469-01 RELAY SOCKET
30 00354470-01 GAUGE SPL
31 00354481-01 SILENCER M5 WEAR
32 00354482-01 CABLE PROTECTION
33 00354483-01 SERVICING UNIT SPL Spare Part
34 00354752-01 SWITCH CABINET DOOR SPL SPARE
35 00354844-01 EDGE PROTECTION COVER
(3PARTS)
36 00347485-01 TOOTH-BELT 10 T5/200 WEAR PART
37 00347485-01 TOOTH-BELT 10 T5/200 WEAR PART
38 00349122-01 FLAT-TAPE 12/1143 TG20 WEAR PART
39 00349122-01 FLAT-TAPE 12/1143 TG20 WEAR PART
40 00353928-01 CAM RING COUPLER Spare Part
00354753-01 CONNECTING CABLE SPL-SPLC Spare Part
00352854-01 CONNECTING CABLE SPL
14/14POLE 3M
Spare Part
00352855-01 CONNECTING CABLE SPL
14/14POLE 4M HS50
Spare Part
00352856-02 INTERFACE CABLE SAG
20POL./STECKER 37POL
00353046-02 INTERFACE CABLE SPL SMEMA
16/16POL.
Spare Part
00353086-02 INTERFACE CABLE SPL SMEMA
16/14POLE
Spare Part
00353087-02 INTERFACE CABLE SPL SAG
20/20POLIG
Spare Part
00354817-01 SPL CABLE SET LIFTING AXIS
LIMIT,4B1-4B2
00354818-01 SPL CABLE SET LIFTING AXIS
RAMP,4B3-4B4
00354819-01 SPL CABLE CONVEYOR TOP SINGLE
TRACK XS2
00354820-01 SPL CABLE SHUTTLE CONVEYOR
5B1-5B6
00354821-01 SPL CABLE,CONVEYOR
TOP,SINGLETRACK XS2.1
