- - 30. PW B C ONVE YO R CO MPO NE NTS( 3) 2 7 2 3 4 5 6 7 8 9 1 0 1 1 1 1 1 1 2 1 3 1 4 1 5 1 6 1 6 5 1 1 6 1 7 1 7 1 8 1 9 1 9 3 3 2 1 2 0 2 2 2 9 2 3 2 3 2 3 2 4 2 5 2 5 2 6 2 6 2 6 2 6 2 6 2 6 2 7 2 8 2 8 3 0 3 0 3…
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 401-28560 CONVEYOR_RAIL_R_ASM 1
2 401-22966 PWB_INNER_J_A (2)
3 401-22967 PWB_INNER_J_B (2)
4 401-28438 RAIL_GUIDE_SHAFT (4)
5 401-28442 PWB_GUIDE_S (12)
6 401-28444 CONVEYOR_RAIL_S (2)
7 401-28459 CONVEYOR_RAIL_COVER (2)
8 401-28520 NEEDLE_ROLLER (4)
9 E2111-715-0A0 CONVEYOR PULLEY ASM. (8)
10 SL-4030891-SC SCREW M3 L=8 (8)
11 SL-6030642-TN SCREW M3 L=6 (24)
12 SM-1030501-SC SCREW M3 L=5 (16)
13 SM-4040855-SC SCREW (8)
14 SM-8040402-TP SCREW M4X0.7 L=4 (4)
15 SM-8040502-TP SCREW M4X0.7 L=5 (4)
16 WP-0430800-SC WASHER M4 (8)
17 401-28443 SHAFT_SUPPORT_J (4)
18 401-28454 PWB_GUIDE_PLATE (6)
19 401-28455 RAIL_GUIDE_PLATE_A (1)
20 401-28457 RAIL_GUIDE_PLATE_C (1)
21 SB-7050004-00 MINIATURE LINEAR BUSHING (4)
22 HX-0029400-00 FIXED BASE (4)
23 SL-6030642-TN SCREW M3 L=6 (12)
24 SL-6041292-TN SCREW M4 L=12 (8)
25 SM-4040801-SC SCREW M4X0.7 L=8 (4)
26 401-28605 GUIDE_SUPPORT_R_A (1)
27 SL-6040892-TN SCREW M4 L=8 (13)
28 401-28606 GUIDE_SUPPORT_R_B (1)
29 SM-6030602-TN SCREW M3X6 (3)
30 HX-0034400-00 FIXED BASE (1)
31 SL-4030691-SC SCREW M3 L=6 (1)
32 401-28580 DRIVE_PULLEY_ASM (2)
33 401-28435 DRIVE_PULLEY (1)
34 E2160-721-000 PULLEY FLANGE (1)
35 E3931-750-000 PULLEY WASHER (2)
36 SL-6030892-TN SCREW M3 L=8 (3)
37 401-28579 DRIVE_SUPPORT_ASM (2)
38 401-28433 DRIVE_SUPPORT_SHAFT (1)
39 401-28434 SUPPORT_BOSS (1)
40 401-28439 DRIVE_SUPPORT_SPRING (1)
41 NM-6040001-SC NUT M4X0.7 TYPE1 (2)
42 RE-0300000-K0 E-RING 3 (1)
43 SB-1040001-00 BEARING (1)
44 401-34150 DRIVE_SUPPORT_BRACKET (1)
45 SL-6042092-TN SCREW M4 L=20 (2)
46 400-94541 CONVEYOR_BELT_EX150 (2)
47 401-22966 PWB_INNER_J_A (2)
48 401-22967 PWB_INNER_J_B (2)
49 401-28445 CONVEYOR_RAIL_B (2)
50 401-28452 GUIDE_STAND_R (1)
51 401-28453 PWB_GUIDE_B (2)
52 401-28461 RAIL_PLATE_RF (1)
53 401-28467 BU_PIN_SENSOR_BRACKET (1)
54 401-29057 SEPARATE SENSOR RECEIVER ASM (1)
55 401-28479 CONVEYOR_RAIL_COVER_B (2)
56 E2089-721-0A0 CONVEYOR PULLEY B ASM. (10)
57 E2111-715-0A0 CONVEYOR PULLEY ASM. (4)
58 HX-0034400-00 FIXED BASE (2)
59 NM-6040001-SC NUT M4X0.7 TYPE1 (2)
60 SL-4030691-SC SCREW M3 L=6 (2)
61 SL-4031291-SC SCREW M3 L=12 (4)
62 SL-6030692-TN SCREW M3 L=6 (12)
63 SL-6030892-TN SCREW M3 L=8 (16)
64 SL-6031692-TN SCREW M3 L=16 (8)
65 SL-6041092-TN SCREW M4 L=10 (8)
66 SL-6041292-TN SCREW M4 L=12 (4)
67 SM-1030501-SC SCREW M3 L=5 (8)
68 SM-4040855-SC SCREW (4)
69 SM-4041255-SN SCREW M4 L=12 (8)
70 SM-4042501-SC SCREW M4X0.7 L=25 (2)
71 WP-0430800-SC WASHER M4 (13)
72 WP-0430801-SC WASHER M4 (2)
73 WS-0410002-KN SPRING WASHER M4 (2)
74 SL-6041492-TN SCREW M4 L=14 (8)
75 401-28451 GUIDE_STAND_L (1)
76 401-28460 RAIL_PLATE_LF (1)
77 401-29058 SEPARATE SENSOR EMISSION ASM (1)
78 401-28565 R_SENSOR_ASM (2)
79 401-28470 FIBER_BRACKET_R (1)
80 SL-6030592-TN SCREW M3 L=5 (1)
81 SL-6030892-TN SCREW M3 L=8 (2)
82 HD-0010700-30 SENSOR (1)
83 EA-9500B00-00 CABLE BAND (26)
84 401-55824 STOPPER_BU_PIN_SENSOR_BRACKET (1)
- -
30.PWB CONVEYOR COMPONENTS(3)
2 7
2
3
4
5
6
7
8
9
1 0
1 1
1 1
1
1 2
1 3
1 4
1 5
1 6
1 6
5 1
1 6
1 7
1 7
1 8
1 9
1 9
3 3
2 1
2 0
2 2
2 9
2 3
2 3
2 3
2 4
2 5
2 5
2 6
2 6
2 6
2 6
2 6
2 6
2 7
2 8
2 8
3 0
3 0
3 0
3 0
3 1
3 1
3 1
3 2
3 2
3 4
A
A
3 5
B
B
E
E
3 5
F
F
3 6
4 0
3 6
4 0
3 7
3 7
3 7
3 8
3 8
3 8
4 1
4 6
4 6
4 6
4 6
4 3
3 9
4 2
4 3
4 2
3 9
4 1
4 1
3 8
4 4
4 4
4 5
4 8
4 5
4 8
4 9
5 0
4 7
4 9
4 7
5 0
C
C
D
D
6 1
5 9
8 6
8 5
7 0
7 0
8 4
5 5
5 4
5 6
5 7
6 2
5 6
5 8
9 0
6 7
7 0
6 8
7 5
8 0
7 9
7 9
7 9
7 3
7 9
7 7
7 4
7 9
7 5
7 9
8 3
7 6
6 4
7 9
7 2
6 6
6 5
9 0
8 9
9 0
8 2
8 2
8 1
8 7
6 9
7 1
7 8
8 8
6 3
5 3
6 0
5 2
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 401-28537 F_RAIL_SUPPORT_S_ASM 1
2 401-32757 CONVEYOR_SUPPORT_S (1)
3 SL-6041492-TN SCREW M4 L=14 (6)
4 SL-6053092-TN SCREW M5 L=30 (2)
5 401-29062 PHOTOMICRO SENSOR ASM (1)
6 SM-4030501-SC SCREW M3X0.5 L=5 (2)
7 HX-0034400-00 FIXED BASE (1)
8 SL-4030891-SC SCREW M3 L=8 (1)
9 401-32759 SENSOR_DOG_R (1)
10 401-32760 SENSOR_DOG_L (1)
11 SL-6030592-TN SCREW M3 L=5 (1)
12 401-28424 RAIL_STAND_LF 1
13 401-28425 RAIL_STAND_LR 1
14 401-28426 RAIL_STAND_RF 1
15 401-28427 RAIL_STAND_RR 1
16 401-28448 STAND_FIX_BRACKET 3
17 401-28449 GUIDE_BAR_S 2
18 401-28477 CABLE_GUIDE_BAR_S 1
19 401-28516 LINEAR_WAY_S 2
20 E2017-715-000 M LINER BUSH 2
21 E2018-715-000 PULLEY SLEEVE 1
22 E4563-729-000 WIDTH ADJUST IDLER PULLEY (30) 1
23 HX-0029400-00 FIXED BASE 8
24 HX-0067100-0A GROMMET 0.195
25 SL-6030692-TN SCREW M3 L=6 22
26 SL-6040892-TN SCREW M4 L=8 10
27 SL-6041092-TN SCREW M4 L=10 2
28 SL-6042092-TN SCREW M4 L=20 8
29 SL-6052592-TN SCREW M5 L=25 1
30 SL-6061292-TN SCREW M6 L=12 4
31 SM-4040601-SC SCREW M4X0.7 L=6 8
32 WP-0430801-SC WASHER M4 2
33 WP-0531001-SC WASHER M5 1
34 EA-9500B02-00 CABLE BAND 7
35 401-28518 SCREW_SHAFT_S 2
36 E2141-721-000 STOPPER COLLAR 2
37 E4561-729-000 TIMING PULLEY A (30) 3
38 SB-1080002-00 BEARING 4
39 SM-6030602-TN SCREW M3X6 4
40 SM-8040402-TP SCREW M4X0.7 L=4 4
41 SM-8040602-TP SCREW M4X0.7 L=6 6
42 WP-0320500-SF WASHER 3.2X7X0.5 8
43 WP-0330516-SC WASHER 3.3X8X0.5 4
44 401-28436 DRIVE_SHAFT_S 2
45 E2141-721-000 STOPPER COLLAR 2
46 SB-1080002-00 BEARING 4
47 SM-6030602-TN SCREW M3X6 4
48 SM-8040402-TP SCREW M4X0.7 L=4 4
49 WP-0320500-SF WASHER 3.2X7X0.5 8
50 WP-0330516-SC WASHER 3.3X8X0.5 4
51 401-34160 STAND_FIX_BRACKET_RR 1
52 401-65222 STOPPER_ST_ASM 1
53 401-65226 STOPPER_BASE_L_ASM (1)
54 401-56849 STOPPER_BASE_PLATE_L (1)
55 401-56850 POSITIONING_PLATE_L (1)
56 SM-1031201-SC SCREW M3X0.5 L=12 (7)
57 401-56583 HOLD_PLATE (1)
58 SL-6041092-TN SCREW M4 L=10 (2)
59 401-65229 SENSOR_DOG_PLATE_ST_STOPPER_L (1)
60 SL-6030692-TN SCREW M3 L=6 (2)
61 401-65230 HOLD_PLATE_MIN (1)
62 401-56848 STOPPER_BASE_L (1)
63
#01
401-65225 STOPPER_UPPER_R_ASM (1)
64 SM-1031201-SC SCREW M3X0.5 L=12 (7)
65 401-56583 HOLD_PLATE (1)
66 SL-6041092-TN SCREW M4 L=10 (2)
67 401-56857 STOPPER_R (1)
68 401-55822 STOPPER_CHIP_ST (1)
69 401-55823 STOPPER_CHIP_XL (1)
70 SM-3030552-TN SCREW M3 L=5 (2)
71 401-56856 STOPPER_BRACKET_R (1)
72 401-56586 STOPPER_PIN (1)
73 401-56584 STOPPER_COLLOR (1)
74 NM-6030001-SC NUT M3X0.5 TYPE1 (1)
75 WP-0330516-SC WASHER 3.3X8X0.5 (6)
76 SL-6031092-TN SCREW M3 L=10 (2)
77 E2038-721-000 STOPPER COLLAR (1)
78 L175E-421-000 STOPPER CREVICE (1)
79 E2039-721-000 WASHER A (7)
80 RE-0200000-K0 E-RING 2 (1)
81 401-56585 AIR_CYRINDER (1)
82 PC-0105080-00 SPEED CONTROLLER (2)
83 401-56968 STOPPER SENSOR ASM (1)
84 EA-9500B02-00 CABLE BAND (17)
85 401-62654 STOPPER_BRACKET_RIB_R (1)
86 401-65227 STOPPER_BASE_R_ASM (1)
87 401-56853 STOPPER_BASE_R (1)
88 401-56854 STOPPER_BASE_PLATE_R (1)
89 401-56855 POSITIONING_PLATE_R (1)
90 SM-1031201-SC SCREW M3X0.5 L=12 (6)
