7.2 List of Servicing Parts
7.2 List of Servicing Parts
The following list shows the components requiring maintenance in several years. Use the list as a
reference.
Regarding the maintenance for the following components, consult with our service personnel as
high skill is required for the maintenance.
Block Name Product Name Part No. Part Name Q'ty
Recommended
# of years
Note(a)
Remarks
Head Section Solenoid Valve KYB-M701U-00 ACCESSORY_SV 60 3
Nozzle Shaft Assembly KYA-M860C-00 SHAFT NOZZLE SET
60
Stes
-
Nozzle shaft
mounting bolt M2 X 4
90112- 02J004
BOLT, HEX.
SOCKET HEAD
60 -
For Nozzle
Shaft Setup
Note (b)
O-Ring for Seal Holder
KYB-M704F-00
KYB-M7028-00
SEAL
SEAL
60
180
2
Nozzle Shaft Spring KYB-M702F-00 HOLDER 120 2
Packing for Nozzle KYB-M704E-00 SEAL 120 -
DYR-2.5
Custom
O-Ring for Filter KYB-M702B-00 SEAL 120 2 SO-009-5A
Line Sensor
Linear Measure Light
Projector
KYA-M7017-00
KYA-M8603-00
SENSOR_PELEC
SENSOR, PELEC-T
4
4
2
2
Diffusion plate
mounting bolt M1.6 X 4
90990-01J117
BOLT, HEX.
SOCKET HEAD
28 -
For Diffusion
Plate Setup
Note (b)
Top Block KYA-M7027-00 BLOCK 60 -
Cam Follower (
φ
2.5) KYB-M704A-00 CAM_FOLLOWER 60 -
Hexagon Socket
Head Cap Screw M1.6×3
90990-01J114
BOLT, HEX.
SOCKET
HEAD
60 -
For Top Block
Setup Note (b)
Slip Ring
KYB-M7027-00
KYB-M7027-01
SLIP RING
SLIP RING
2 2
Previous type
New type
Coupling for NL KYX-M702C-000 COUPLING 2 -
3-piece set
replacement
Plate for NL KYX-M702C-200 PLATE 2 -
Bolt for NL motor 90112-2AJ012
BOLT HE X.
SOCKET HEAD
4 -
NL motor (for HH head) KYA-M701C-00
MOTOR_NL 4 - For HH head
NL motor (for HM head) KYF-M861N-00 MOTOR_NL 4 - For HM head
Note
4OM-1840
1-7-3
1604-001
7.2 List of Servicing Parts
Table 4A7-3
Block
Name
Product Name Part No. Part Name Q'ty
Recommended #
of years
Note(a)
Remarks
Main Unit Touch Panel Display KYB-M651V-00 OPERATION
PANEL
1 3
Vacuum Pump KYB-M861C-00 VACUUM_PUMP 1 2 22kg
UC18-Aggregate
board
KYB-M657N-00
PCB-MOUNT 2 6
UC16-High speed IO
board
KYA-M8625-00
ASSY,UC16 1 6
Camera scope
KYA-M7304-00
STD.CAMERA 4 6
Transfer
Unit
Flat Pulley KYA-M914U-00 PULLEY_FLAT 16 5
Timing Belt KYA-M9152-00 BELT_TIMING 4 1
Cylinder KYA-M912L-00 CYLINDER 3(4) 3 Note (d)
Cylinder KYA-M912P-00 CYLINDER 6 3
Cylinder KYA-M912S-00 CYLINDER 2 3
Timing Pulley KYB-M91AL-00 PULLEY_TIMING 16 5
UC16-High speed IO
board
KYB-M91AK-00 PCB-MOUNT
1
6
Cutter
Section
Movable blade KYA-M3T0M-00 MECH_PARTS 4 2
Fixed blade KYA-M3T0H-00 MECH_PARTS 4 2
Oilless guide KYA-M3T0A-00 GUIDE 8 3
UC24 Feeder cart IO
board
KYC-M185X-00 PCB-MOUNT 2 6
Note
(a) The recommended year of pieces is the value for reference only.
(b) Do not reuse any bolt removed during maintenance.
(c) The linear measure consists of the controller and head (light projector and
light receiver) as a set.
The head (light projector) of the linear measure can be replaced as a single
linear measure light projector.
Y510 mm Single Transfer Unit (Option).
