Error ID Error Name, Description, Cause, and Remedy
405701 Shut-o safety relay of Elevator(Upper) (Block2)
Cut o safety relay of upper elevator (Block2).
Conrm the main circuit and safety door.
405801 Released Elevator unit clamp(Block2)
Released elevator unit clamp(Block2)[B15426, B15428]
Conrm the Elevator Unit Clamp Sensor(B15426, B15428).
405901 Detecting pickup miss cmpnt of Tray Feeder Cart (Block2)
Pickup miss components was detected(Block2). [B15412]
1.Open the cover.
2.Conrm suppressor, Disengaged Latch and remove the Pickup miss cmpnt.
3.Close the cover and then lock it.
405A01 Detecting Feeder Disengaged Latch of Tray Feeder Cart(Block2)
Feeder Disengaged Latch is detected (Block2).[B15412]
1.Open the cover.
2.Conrm suppressor, Disengaged Latch and remove the Pickup miss cmpnt.
3.Close the cover and then lock it.
406701 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Pick-up miss cmpnt is detected on Tray pallet (Block1)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406801 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Pick-up miss cmpnt is detected on Tray pallet (Block1)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406901 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Pick-up miss cmpnt is detected on Tray pallet (Block1)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406A01 Detecting pickup miss cmpnt on Tray Pallet (Block1)
Pick-up miss cmpnt is detected on Tray pallet (Block1)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406B01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pick-up miss cmpnt is detected on Tray pallet (Block2)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406C01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pick-up miss cmpnt is detected on Tray pallet (Block2)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406D01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pick-up miss cmpnt is detected on Tray pallet (Block2)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
406E01 Detecting pickup miss cmpnt on Tray Pallet (Block2)
Pick-up miss cmpnt is detected on Tray pallet (Block2)
Please open the main cover, and remove the pick-up miss cmpnt on Tray pallet.
407001 Detecting Head1 nozzle descending
Invalid detection of head1 nozzle descending
Please perform a zeroing.
3.1 Safety Device
4OM-1840
3-3-171604-001
Error ID Error Name, Description, Cause, and Remedy
407101 Detecting Head2 nozzle descending
Invalid detection of head2 nozzle descending
Please perform a zeroing.
407201 Pass Line detect(Head1)
Invalid detection of Pass line(Head1)
Please perform a zeroing.
407301 Pass Line detect(Head2)
Invalid detection of Pass line(Head2)
Please perform a zeroing.
408001 Nozzle interference detect adjacent to multi-functional head
Emergency stopped a head because a nozzle adjacent to it interfered.
Please perform a zeroing.
408301 Feeder opening sensor (Block 1) detect
The feeder opening sensor (Block 1) was shaded.
-----
408401 Feeder opening sensor (Block 2) detect
The feeder opening sensor (Block 2) was shaded.
-----
T4C3
3.1 Safety Device
4OM-1840
3-3-181604-001
3.2 Data
Error ID Error Name, Description, Cause, and Remedy
410301 Pattern Program Error
Steps in converted pattern program is more
-----
410302 Pattern Program Error
There are Errors in converted pattern program(PCB recog steps Error.)
-----
410303 Pattern Program Error
The converted pattern program is not exist, the data is damaged.
-----
410304 Pattern Program Error
The error is found in the adsorption nozzle number of the conversion pattern
program.
-----
410305 Pattern Program Error
The error is found in the order of adsorption of the conversion system pattern
program.
-----
410306 Pattern Program Error
The error is found in the nozzle candidate number of the conversion pattern
program.
-----
410307 Pattern Program Error
The error is found in the adsorption lane number of the conversion pattern
program.
-----
410401 Data Error
The components library does not exist. Or, data is in loss.
-----
410402 Data Error
Data relating to nozzle does not exist. Or, data is in loss.
-----
410701 Program Error
It was a error setting of the sequence data.
-----
410801 2D bar code data Error
It was a error setting of the sequence data.
-----
410802 2D bar code data Error
Failed in start-up Sequence
-----
410803 2D bar code data Error
The error is found in coordinates calculation.
-----
3.2 Data
4OM-1840
3-3-191604-001
