Recognition Error ID Description of Recognition Error
02400103 The Comp. recognition lighting of beam 3 did not light.
02400104 The Comp. recognition lighting of beam 4 did not light.
02400301 There is the dierence with settings for PEC Recognition Camera1.
02400302 There is the dierence with settings for PEC Recognition Camera2.
02400000 Others.
02900000 Others.
02900001 Image Acquiring in was interrupted.
02900002 The eye match was interrupted.
02900003 Failed in a division calculation of placement coordinate teaching.
02900101 Image data le can't be saved.
02900102 Image data le can't be saved.
02900103 Image data le can't be saved.
02900104 Image data le can't be saved.
02900105 Image data le can't be saved.
02900106 Data error.
02900107 Exception error.
02900108 There is no empty area enough for the disk.
02d00000 Error in Recognition internal.
02e00000 Error in Recognition internal.
12000000 Error in Recognition internal.
05000000 Others.
05000001 Component was not found.
05100001 Component was not detected.
05100101 The detection window of the length position of lead sequence can't be set up.
05100102 The length position of a lead sequence can't be detected.
05100103 Impossible to set the window for lead detection at the corner.
05100104 The lead edge of a corner can't be detected.
05100105 The lead of a corner can't be detected.(Cmpnt Angle inclined)
05100106 few lead numbers of the detected corner than the set-up.
05100107 The distance during the lead of the detected corner is poor.(Cmpnt Angle
inclined)
05100108 The angle during the lead of the detected corner is poor.
05100201 No Electrode(ball) Detected.
05100601 Shape (L type) cannot be detected.
05100602 Shape (U type) cannot be detected.
05100603 Shape (edge) cannot be detected.
05100604 Shape (rectangle) cannot be detected.
05100605 Shape (oval) cannot be detected.
05100000 Others.
05200101 More than two corners of a component are hidden by the protruded nozzle.
05200102 Corner not detected.
05200201 Some edges cannot be detected because they are hidden by the nozzle.
05200202 Edge not detected.
05200203 Some edges cannot be detected because they are hidden by the nozzle.
3. Recognition Error IDs and Remedial Procedures
4OM-1840
4-1-81604-001
Recognition Error ID Description of Recognition Error
05200204 Edge not detected.
05200301 Angle calculation impossible.
05200401 Impossible to set the window for lead detection.
05200402 The length position of a lead can't be set up.(Cmpnt Angle inclined)
05200403 The detected number of leads is smaller than the set value.
05200404 The detected number of leads is larger than the set value.
05200405 The lead length cannot be detected.
05200501 Electrode(ball) which is in agreement with data was undetectable.
05200502 Since a sucient number of Electrode(ball) were undetectable, it cannot position.
05200601 Shape (L type) cannot be detected.
05200602 Shape (U type) cannot be detected.
05200603 Shape (edge) cannot be detected.
05200604 Shape (rectangle) cannot be detected.
05200605 Shape (oval) cannot be detected.
05200606 There is shape that cannot be detected as in the shade of nozzle etc.
05200607 The Shape corresponding to data was not able to be detected.
05200000 Others.
05800001 The pick-up position has deviated greatly.
05800002 The pick-up position has deviated greatly in X direction.
05800003 The pick-up position has deviated greatly in Y direction.
05800004 The pick angular skew is big.
05800101 Component outward length X is incorrect.
05800102 Component outward length X is shorter than the tolerance.
05800103 Component outward length X is longer than the tolerance.
05800104 Component outward length Y is incorrect.
05800105 Component outward length Y is shorter than the tolerance.
05800106 Component outward length Y is longer than the tolerance.
05800107 Component outward length X or Y is incorrect.
05800108 Component outward length X or Y is shorter than the tolerance.
05800109 Component outward length X or Y is longer than the tolerance.
05800201 The number of leads is small.
05800202 The number of leads is large.
05800203 The lead width is shorter than the tolerance.
05800204 The lead width is longer than the tolerance.
05800205 Gap of the width direction of a lead is larger than a permissible value.(Cmpnt
Angle inclined)
05800206 Gap of the length direction of a lead is larger than a permissible value.
05800207 The detected lead length direction positions dier greatly.
05800208 The lead length is shorter than the tolerance.
05800209 The lead length is longer than the tolerance.
05800301 Electrode(ball) length is incorrect.
05800302 Electrode(ball) position is larger than a permissible value.
05800303 Electrode(ball) which must not exist existed.
05800401 A shape positional gap is larger than a permissible value.
3. Recognition Error IDs and Remedial Procedures
4OM-1840
4-1-91604-001
Recognition Error ID Description of Recognition Error
05800000 Others.
05900000 Others.
05900101 Error in Polarity Detection.
05900102 The polarity of components diers.
05900103 The polarity of components cannot be judged.
05900201 The component is reversed.
05900301 There is the electrode (lead) that must not exist
05900302 There is the electrode (ball) that must not exist
05900303 There is the shape that must not exist.
05900401 There is the ball which ux is not spread.
05900402 Flux spread is not conrmed because the component recognition was abnormal.
05a00101 The pick-up position has deviated greatly in X direction.
05a00102 The pick-up position has deviated greatly in Y direction.
05a00103 The pick angular skew is big.
05a00000 Others.
05b00001 The pick-up position has deviated greatly.
05b00002 The pick-up position has deviated greatly in X direction.
05b00003 The pick-up position has deviated greatly in Y direction.
05b00004 The pick angular skew is big.
05b00000 Others.
05e00000 Others.
15000000 Others.
06001001 Base mark not found in recognizable range.
06001002 The position of base mark slips o.
06001003 Base mark not found in recognizable range.
06001101 The Base mark is not found, because light turn o.
06001102 Base mark not Acquiring in recognizable range.
06001201 The Base mark is not found, because mark light too bright.
06001202 Base mark not Acquiring in recognizable range.
06000001 Specied mark not found in recognizable range.
06000101 The Base mark is not found, because mark light turn o.
06000102 The Base mark is not found, because too dark.
06000201 Base mark not found in recognizable range. Because mark light turn on.
06000202 The Base mark is not found, because too bright.
06000000 Others.
06101001 Base mark not found in recognizable range.
06100001 Specied mark not found in recognizable range.
06100000 Others.
06201001 Base mark not found in recognizable range.
06201100 Base mark edge not detected.
06201201 Base mark edge not detected.
06201401 Base mark corner not detected.
06201402 Base mark corner not detected.
06201403 Base mark corner not detected.
3. Recognition Error IDs and Remedial Procedures
4OM-1840
4-1-101604-001
