4OM-1840 1-2-4 1604-001 2.4 Quarterly Maintenance Grease Symbols MP1 : DAPHNE GREASE MP No. 1 NM1 : MOLYNOC GREASE AP1 Notice Lubrication must be made on the *-marked items after initial month and every 3 months for the …
4OM-1840
1-2-31604-001
2.3 Monthly Maintenance
Grease Symbols
MP1
: DAPHNE GREASE MP No. 1
Table 4A2-3
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
4.3 Component
Recognition
Camera Section
Teaching Plate
Cleaning
----- Rag
4.7 Head Section
Cleaning
----- Lens Cleaning Cloth
4.11 Nozzle Stocker
Section
Nozzle Storage Section
Cleaning
----- Vacuum Cleaner
2.3 Monthly Maintenance
4OM-1840
1-2-41604-001
2.4 Quarterly Maintenance
Grease Symbols
MP1
: DAPHNE GREASE MP No. 1
NM1
: MOLYNOC GREASE AP1
Notice
Lubrication must be made on the *-marked items after initial month and
every 3 months for the subsequent use.
Table 4A2-4
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
4.1 Air Source
Filter
Cleaning
----- Air Filter Case Jig
4.2 Vacuum System
Driving Section
Filter
Cleaning
-----
4.4 Feeder Base
Worm Gear
Lubrication
NM1
4.6 Feeder Cart
Section (Cutter)
OILES Guide
Lubrication
NM1
Cutter Unit Inside
Cleaning
NM1 Vacuum Cleaner
4.7 Head Section
Nozzle U/D Ball Screw
(NL Axis)
Cleaning,
Lubrication
MP1
Head U/D Ball Screw
(HL Axis)
Cleaning,
Lubrication
MP1
Head U/D Linear Guide
(HL Axis)
Cleaning,
Lubrication
MP1
Center Spline
Lubrication
MP1
Carn Follower
Cleaning,
Lubrication
MP1
Nozzle Change Carn
Face (Upper Side)
Cleaning,
Lubrication
MP1
Vacuum Filter
Replacement
-----
Vacuum Nozzle
Inspection
-----
Head U/D Ball Screw
(HL Axis)
Cleaning,
Lubrication
MP1
Head U/D Linear Guide
(HL Axis)
Cleaning,
Lubrication
MP1
4.8 X/Y Beam
Section
Cleaning,
Lubrication
MP1
* Y-Axis Linear Guide
Cleaning,
Lubrication
MP1
Cleaning
-----
Y-Axis Linear Scale
Cleaning
-----
4.9 PCB Positioning
Section
* Ball Screw
Cleaning,
Lubrication
MP1
4.10 Conveyor
Section
* Linear Guide
Cleaning,
Lubrication
MP1
Note
The head up/down ball screw (HL-axis) and the head up/down linear guide (HL-
axis) are applicable only to the SIGMA-F8S high-speed multi-purpose head.
2.4 Quarterly Maintenance
4OM-1840
1-2-51604-001
Table 4A2-5
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
4.11 Nozzle Stocker
Section
Nozzle Stocker Sliding
Area
Cleaning,
Lubrication
MP1 Oiled Rag
Shutter Flange Pin
Sliding Section
Cleaning,
Lubrication
NM1
4.12 Control Box
Section
Filter
Cleaning
-----
2.5 Half-Yearly Maintenance
Grease Symbols
MP1
: DAPHNE GREASE MP No. 1
IEL/V
: BARRIERTA IEL/V
Table 4A2-6
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
4.8 X/Y Beam
Section
Cleaning,
Lubrication
IEL/V Oiled Rag, Brush
Places
Inspection
----- -----
Cleaning
----- Rag
Y-Axis Cable Side Face
Cleaning,
Lubrication
IEL/V Oiled Rag, Brush
Y-Axis Cable Fixing
Places
Inspection
----- -----
Y-Axis Liner Scale
Cleaning
----- Rag
4.9 PCB Positionig
Section
Ball Screw Spline
Cleaning,
Lubrication
MP1 Oiled Rag, Hand Grease
Gun, Nozzle (SPK-3C)
Note
The item "Ball Screw Spline (4.9 PCB Positioning Unit)" is for the system
where the Y510mm Single Transfer Unit (Option) has been mounted.
2.6 Yearly Maintenance
Table 4A2-7
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
4.6 Feeder Cart
Section (Cutter)
Fluorine Sheet
Change
----- Screwdriver, Wrench
Urethane Clamp Assy
Change
----- Screwdriver, Wrench
Flat Ring
Change
----- Screwdriver, Wrench, Torque
driver
