73 MODEL FP-G300 R 1012-004 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE FK-1 1 6301449340 COVER 1 806FK-1 10-001 21 1AA587 2 6301449357 COVER 1 806FK-1 10-002 21 1AA588 3 6301449364 COVER 1 806FK-1 10-003 2…
72
MODEL FP-G300R
0702-002
カバー部
COVER SECTION
Fig. FK-1
カバー部
Cover Section
1
33
22
20
4
2
16
31
15
17
33
18
19
21
8
7
A
B
57
.
69
.
73
58
62
54
.
68
.
72
59
60
60
60
60
60
62
56
.
69
.
73
60
60
54
.
68
.
72
51
.
66
.
71
31
38
39
51
.
66
.
71
See Fig.FH-1
Key No.36
5
6
57
.
69
.
73
3
60
57
.
69
.
73
13
11
31
9
32
14
B
54
.
68
.
72
54
.
68
.
72
55
63
61
.
67
51
.
66
.
71
52
.
66
.
71
34
41
12
31
10
32
14
13
A
63
55
61
.
67
52
.
66
.
71
51
.
66
.
71
54
.
68
.
72
54
.
68
.
72
34
41
35
24
23
28
27
26
25
36
51
.
66
.
71
56
.
69
.
73
53
51
.
66
.
71
51
.
66
.
71
31
63
30
63
37
29
51
.
66
.
71
56
.
69
.
73
A
A
40
73
MODEL FP-G300R
1012-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
FK-1
1 6301449340 COVER 1 806FK-110-001 211AA587
2 6301449357 COVER 1 806FK-110-002 21
1AA588
3 6301449364 COVER 1 806FK-110-003 21
1AA589
4 6301422794 BRACKET 1 806FK-110-004 21
1FA380
5 6301448299 BRACKET 1 806FK-110-005 21
1FA701
6 6301424316 BRACKET 1 806FK-110-006 21
1FA388
7 6301443980 COVER 1 806FK-110-007 21
1AA532
8 6301423180 BRACKET 1 806FK-110-008 21
1FA384
9 6301457291 COVER 1 806FK-110-009 21
1AA719
10 6301457307 COVER 1 806FK-110-010 21
1AA720
11 6301393483 PLATE 1 806FK-110-011
211DA840
12 6301433745 PLATE 1 806FK-110-012 21
1DB397
13 6301393605 BRACKET 4 806FK-110-013 21
1FA022
14 6301393612 BRACKET 2 806FK-110-014 21
1FA023
15 6301405162 BRACKET 2 806FK-110-015 21
1FA171
16 6301442013 BRACKET 1 806FK-110-016 21
1FA618
17 6301442068 BRACKET 1 806FK-110-017 21
1FA619
18 6301469805 COVER 1 806FK-110-018 21
1AA880
19 6301443966 COVER 1 806FK-110-019 21
1AA530
20 6301432144 COVER 1 806FK-110-020 21
1AA415
21 6301442099 COVER 1 806FK-110-021 21
1AA509
22 6301444611 BRACKET 1 806FK-110-022 21
1FA647
23 6301443096 PLATE 2 806FK-110-023 21
1DB467
24 6301433639 PLATE 1 806FK-110-024 21
1DB395
25 6301424248 PLATE 1 806FK-110-025 21
1DB283
26 6301424255 PLATE 1 806FK-110-026 21
1DB284
27 6301433646 PLATE 1 806FK-110-027 21
1DB396
28 6301450261 COVER 1 806FK-110-028 21
1AA605
29 6301442761 PLATE 1 806FK-110-029 21
1DB465
30 6301442754 BRACKET 1 806FK-110-030 21
1FA630
31 6300036107 MECH PARTS(MAGNET CATCHE) 3 806FK-110-101 226J0001
32
6301289038 HANDLE 2 806FK-110-102 226C0204
33 6301256184 SWITCH,LIMIT 3 S501,S502,S503
806FK-110-103 4S1F0051
34 6300702323 SWITCH,LIMIT 2 806FK-110-104 4S1F0030
35 6301432519 ACCESSORY,SW 1 806FK-110-105 23H20072
36 6301432342 HANDLE 1 806FK-110-106 226C0216
37 6301442945 STAY 1 806FK-110-107 21
1J1364
38 6301449654 NAME PLATE,NOTICE 1 806FK-110-108 6P451977
39 6301449661 NAME PLATE,NOTICE 1 806FK-110-109 6P451978
40 6301468877 BOLT 1 906FK-110-110
221E0388
41 6301449692 BRACKET 2 806FK-110-031 21
1FA720
51 6300007503 BOLT,HEX-SCT 31 M3X6 221A0005
52
6300007510 BOLT,HEX-SCT 4 M3X8 221A0006
53
6300007534 BOLT,HEX-SCT 2 M3X12 221A0008
54
6300007626 BOLT,HEX-SCT 18 M4X10 221A0017
55
6300007633 BOLT,HEX-SCT 4 M4X12 221A0018
56
6300007749 BOLT,HEX-SCT 10 M5X10 221A0029
57
6300007756 BOLT,HEX-SCT 11 M5X12 221A0030
58 4110505004 SCR TRS 3X6 3 M3X6 TRS 221E0529
74
MODEL FP-G300R
1012-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
FK-1
59 4110511708 SCR TRS 4X6 4 M4X6 TRS 221E0532
60 4111408007 SCR TRS 5X6 24 M5X6 TRS 221E0536
61 4111131400 SCR PAN 4X6 4 M4X6 PAN 221E0509
62 4111619007 SCR PAN 4X35 9 M4X35 PAN 221E0507
63 4110022600 SCR FLT 3X6 8 M3X6 FLT
221D0216
66 4111412806 WASHER SPR 3 35 SW3 221H0281
67
4110081706 WASHER SPR 4 4 SW4 F 221H0283
68
4111412905 WASHER SPR 4 18 SW4 221H0284
69
4111416705 WASHER SPR 5 21 SW5 221H0287
71
4111413902 WASHER V 3X7X0.5 35 FW3 221H0312
72
4111414008 WASHER V 4X9X0.8 18 FW4 221H0315
73
4111414107 WASHER V 5X10X1 21 FW5 221H0318
