Protection_20211124_073105 - 第13页
Protection Page 13 / 17 24.11.2021
Protection
Page 12 / 17 24.11.2021
Protection
Page 13 / 17 24.11.2021
Protection
Page 14 / 17 24.11.2021
Pos. Item no. Description Part marking
00357164-01 PROTECTION S27HM
1 00357196-02 SWIVEL DOOR 1 ASSYMETR. Spare Part
2 00354956-01 ESLON WINDOW W/ BARCODE
SWIVEL DOOR 1
SPARE PART
3 00319467-03 CLAMPING PROFILE 1
4 00319036-01 DIN EN ISO 7380-M5 X 20-12.9
5 00095565-01 HEXAGON NUT
6 00322793-01 FIXING
7 00845030-01 HEXAGON SOCKET HEAD CAP
SCREW
8 00304588-01 DIN EN ISO 7380-M5 X 16-10.9 STANDARD PARTS
9 00346038-02 PROTECTION CLIP LEFT(LONG) SPARE PART
10 00322795-01 SHIM SPARE PART
11 00357197-01 SWIVELING DOOR 2 ASYMMETR.
12 00354957-01 ESLON WINDOW W/ BARCODE
SWIVEL DOOR 2
SPARE PART
13 00319135-03 CLAMPING PROFILE 2
14 00319036-01 DIN EN ISO 7380-M5 X 20-12.9
15 00095565-01 HEXAGON NUT
16 00322793-01 FIXING
17 00845030-01 HEXAGON SOCKET HEAD CAP
SCREW
18 00304588-01 DIN EN ISO 7380-M5 X 16-10.9 STANDARD PARTS
19 00346045-01 PROTECTION CLIP RIGHT SPARE PART
21 00357199-02 SWIVEL DOOR 3 ASSYMETR. Spare Part
22 00354958-01 ESLON WINDOW W/ BARCODE
SWIVEL DOOR 3
SPARE PART
23 00321175-03 CLAMPING PROFILE 3 Spare Part
24 00319036-01 DIN EN ISO 7380-M5 X 20-12.9
25 00095565-01 HEXAGON NUT
26 00322793-01 FIXING
27 00845030-01 HEXAGON SOCKET HEAD CAP
SCREW
28 00304588-01 DIN EN ISO 7380-M5 X 16-10.9 STANDARD PARTS
29 00346038-02 PROTECTION CLIP LEFT(LONG) SPARE PART
30 00322795-01 SHIM SPARE PART
31 00357200-02 SWIVEL DOOR 4 ASSYMETR. Spare Part
