Page SAMSUNG TECHWIN 178 SM482 Articles of Consumption NO. Lev . P ART NO. P ART NAME Q'TY Old No. Supply Supply L T Reference A-1 J9055354A NOZZLE ASSY[J9055354A] 1 1 J9055134C NOZZLE CN040 ASSY[J9055134C] 6 Only I…
Page
SAMSUNG TECHWIN
177
SM482
Articles of Consumption
Page
SAMSUNG TECHWIN
178
SM482
Articles of Consumption
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
A-1 J9055354A NOZZLE ASSY[J9055354A]
1
1
J9055134C NOZZLE CN040 ASSY[J9055134C]
6
Only Indication
2
J9055136C NOZZLE CN065 ASSY[J9055136C]
6
Only Indication
3
J9055256A NOZZLE CN140 ASSY[J9055256A]
2
Only Indication
4
J9055351A NOZZLE CN220 ASSY(CERAMIC)[J9055351A]
2
J9055257A Only Indication
5
J9068024A CALIBRATION PLATE[J9068024A]
1
Only Indication
A-2
J90641038A SM421_PACKING_BOX_ASSY J90641038A
1
Only Indication
6 J3601018A FUSE[250V 5A] 2
Only Indication
7 J3601019A FUSE[250V 10A] 2
Only Indication
8 J7055140A STEEL BALL [DIA2, SUS304] 20
Only Indication
9 J72550021C SILICON TUBE(BLACK) J72550021C 6 J7255076A /J7255021B
Consumables (Replacement: 6 months)
10 J67081017A SUCTION_FILTER VYF44-M-50M 6
Only Indication
11 J7500003B BACK UP PIN[J7500003B] 6
Only Indication
12 J8001072A STICKER REMOVER SPRAY [450ML] 1
Only Indication
13 J8001073A TRI-FLOW [59ML] 1
Only Indication
14 J81000118C CLEANING KIT 1
Only Indication
15 J9064035B TOOL SET [J9064035B] 1
Only Indication
16 J8001065A DRIVER (+,-) [KL 207(6), 150mm] 1
Only Indication
17 J5104001A CD-R (RECORDABLE) [MMI BACKUP CD] 1
Only Indication
18 J9055249A LIGHT MAPPING TOOL ASSY[J9055249A] 1
Only Indication
19 J9055250A LIGHT MAPPING TOOL ASSY[J9055250A] 1
Only Indication
20 J67020048B SOLENOID VALVE VA01PEP34A-1U-F 6 J6702048A
Consumables (Replacement: 2 years)
21 J6702049A SOLENOID VALVE[RCS242-M3-D24NP] 1
Consumables (Replacement: 2 years)
22 J7459062A CALIBRATION NOZZLE[J7459062A]
