MEMO
MODEL TCM-3700
9912-001
6- 4
PART No. PART NAME Q'ty REMARKS
51 630 064 6436 PULLEY,TIMING 1 739J--01H-133
52 630 008 1985 RING 1 739J--01H-150
53 411 141 4008 WASHER V 4X9X0.8 2 FW4
54 411 141 2905 WASHER SPR 4 2 SW4
55 630 000 7664 BOLT,HEX-SCT 2 M4X20
56 630 000 8883 SET SCREW 2 M3X4 SET
57 630 064 6153 SHAFT 4 739J--01B-093
58 630 001 1388 BEARING,RADIAL 8 739J--01H-042
59 411 141 4008 WASHER V 4X9X0.8 4 FW4
60 411 000 9809 RING E 3 4 739J--01H-049
61 630 064 6160 SHAFT 1 739J--01B-094
62 630 001 1388 BEARING,RADIAL 2 739J--01H-042
63 411 141 4008 WASHER V 4X9X0.8 1 FW4
64 411 000 9809 RING E 3 1 739J--01H-049
65 630 001 0213 WASHER 1 739J--01H-128
66 411 141 4008 WASHER V 4X9X0.8 1 FW4
67 411 141 2905 WASHER SPR 4 2 SW4
68 630 000 7633 BOLT,HEX-SCT 2 M4X12
69 630 064 6795 BELT,TIMING 1 739J--01H-136
120 630 076 1870 ASSY,CORD (C35-BPC-1) 1
121 630 076 1887 ASSY,CORD (C35-BPC-2) 1
Key No.
NOTE
MEMO
MODEL TCM-3700
9912-001
ＸＹテーブル部 XY TABLE SECTION
Fig. 6-5 シュート Chute
