MODEL TCM-3700 9912-001 3-20 PART No. PART NAME Q'ty REMARK S 1 630 038 8176 BRACKET 1 739B--01B-022 2 411 141 4305 W ASHER V 6X 12.5X1.6 2 FW 6 3 411 141 3001 W ASHER SPR 6 2 SW 6 4 630 000 7886 BOLT ,HEX-SCT 2 M6X…
MODEL TCM-3700
9912-001
ヘッド駆動部 HEAD DRIVING SECTION
Fig. 3-20 手回しハンドル、スポットライト Hand Wheel,Spotlight
MODEL TCM-3700
9912-001
3-20
PART No. PART NAME Q'ty REMARKS
1 630 038 8176 BRACKET 1 739B--01B-022
2 411 141 4305 WASHER V 6X12.5X1.6 2 FW6
3 411 141 3001 WASHER SPR 6 2 SW6
4 630 000 7886 BOLT,HEX-SCT 2 M6X16
5 630 000 3345 SWITCH,MICRO 1 739B--01H-028
6 630 000 0375 ACCESSORY,SW 1 739B--01H-029
7 411 119 2104 WASHER V 4X9X0.8 1 FW4 F
8 411 008 1706 WASHER SPR 4 1 SW4 F
9 630 000 8609 BOLT,HEX 1 M4X30 HEX
10 411 119 2104 WASHER V 4X9X0.8 1 FW4 F
11 630 000 8616 BOLT,HEX 1 M4X35 HEX
12 630 001 0213 WASHER 1 BW4
13 411 008 1706 WASHER SPR 4 1 SW4 F
14 411 054 8506 NUT HEX 4 1 M4 F
15 630 048 6612 SHAFT 1 739B--01B-023
16 630 048 6629 HANDLE 1 739B--01B-024
17 630 001 0381 SPRING PIN 1
21 630 003 6527 MECH PARTS(RUBBER DAMPER) 1 739L--01H-063
22 630 000 5271 LIGHTING UNIT 1 739L--01H-062
22 -1 630 005 4286 LAMP 1
23 411 141 4107 WASHER V 5X10X1 1 FW5
24 411 141 4008 WASHER V 4X9X0.8 1 FW4
25 411 141 2905 WASHER SPR 4 1 SW4
26 630 000 7633 BOLT,HEX-SCT 1 M4X12
27 411 141 4107 WASHER V 5X10X1 2 FW5
28 411 141 6705 WASHER SPR 5 2 SW5
29 630 000 7756 BOLT,HEX-SCT 2 M5X12
Key No.
NOTE
MODEL TCM-3700
9912-001
中間ベース部 MIDDLE BASE SECTION
Fig. 4-1 中間ベース Middle Base
