Splice Detection Basic Package HS-50 2 Assembly inst ructions Splice Detection Basic Package SIPLACE HS-50 03/2008 Edition 19 2.3 T ools – Metric hex ball end wrench set (also called “Allen” wren ch) – Diagonal cutters –…

2 Assembly instructions Splice Detection Basic Package SIPLACE HS-50 Splice Detection Basic Package HS-50

03/2008 Edition

2.2 Safety Instructions

DANGER

All the work described below must only be carried out by Siemens service engineers. 2

The safety instructions from the “Operational safety” chapter of the user manual or the ervice ma-

nual take precedence over these instructions. 2

SIPLACE placement machines are supplied main power voltage. Consequently parts of these sy-

stems carry dangerous voltages inside the machine frame, even when switched off at the main

switch. 2

Before starting any work switch the machine off at the main switch and disconnect it from the main

power supply. 2

Always follow the accident prevention regulations, DIN or other standards and special safety rules

applicable in your country. Always follow DIN EN 60204 and DIN VDE 105-100 when working in-

side the machine frame. 2

Pay attention to the information concerning residual voltages and electrostatic discharge (ESD) in

the Operating safety chapter. 2

During the retrofit, always secure the machine to prevent access by other people and to prevent

it being switched on again. 2

If the component cart is out of the machine or is not correctly coupled to the machine, do not con-

nect it electrically to the machine frame. 2

2.2.1 Definitions

DANGER

in terms of these instructions means that death, severe bodily injury or considerable material

damage WILL occur if the instructions about danger are not followed. 2

NOTE 2

Splice Detection Basic Package HS-50 2 Assembly instructions Splice Detection Basic Package SIPLACE HS-50

03/2008 Edition

2.3 Tools

– Metric hex ball end wrench set (also called “Allen” wrench)

– Diagonal cutters

– Cross point screwdriver (also called a “Phillips Head” screwdriver)

– A small flat bladed screwdriver

2.4 Parts

2.4.1 Contents HS50 Splice Detection Basic Package (item no.: 00116936-xx)

Number Description Item no.:

- 1 Retrofitting Instructions 00193363-01

- Various installation material

- 1 HUB Unit 00366091-02

- 1 COM Interface for SC 00368432-01

- 1 Adapter for COM Interface 00368552-01

- 1 Serial cable HUB - SR 00368431-01

- 1 Cable power supply HUB 00368322-01

- 2 Cables HUB – TC long 00368249-01

- 2 Cables HUB – TC short 00368250-01

- 2Covers left side 00368325-01

- 2 Covers right side 00368326-01

- 1 Retrofitting instructions table controller 00193364-01

- 1 Retrofitting Instr. Splice Sensor 2x8mm 00193365-01

2 Assembly instructions Splice Detection Basic Package SIPLACE HS-50 Splice Detection Basic Package HS-50

03/2008 Edition

2.5 Preparation

: Pull out all feeder tables

: Switch the machine off at the main switch.

: Interrupt the power supply to the machine to prevent the risk of electric shock.

DANGER

Before restarting the placement machine connect and bolt the HUB electrical conducting with the

machine frame! 2

: Read the installation instructions carefully.

2.6 Additional COM port for station computers

The splice detector is linked to the station computer via one of the COM ports. Please check whe-

ther the station computer has a free COM port (9 pins). 2

HS50 machines with a UPS (uninterruptible power supply) generally have a free COM port. If this

is the case, no further components have to be installed. Use COM port 4. 2

HS50 machines without a UPS generally do not have a free COM port, so you will have to install

the COM card supplied. 2

Before assembling the card note type/identification of the card to install later the adequate driver.2

: Switch the station computer off. Disconnect the computer from the power supply.

: Pull out the computer - you may have to disconnect other connecting cables to do this.

: Remove the cover from the station computer.

: Find a free slot for your COM card.

: Remove the blanking plate over the card slot in the computer.
