13.11.2018 Page 18
Calibration and Test Smart Pin Support
from software version 712.0
Combined Calibration steps include all Pin Picker calibrations:
Offset Pin picker -> PCB camera
Position check on the lifting table
Calibrate magazine position
New - Endurance for SPS
Pin Picker under
Maintenance
13.11.2018 Page 19
New Function with the Station Software 712.0
Note:
With the SW 712.0 it is possible to set more pins as place in the pin garage.
If you defined more pins in SIPLACE Pro as you can set up in the pin garage. It is
now possible to fill up the garage manual, if the pin garage empty. The station
software suppot this new workflow.
THANK YOU
Name: Mathias Michel
Department: ASM AS CRM CS PM&E
Address:
Phone:
Mail: mathias.michel@asmpt.com
