83.MINI PAT & SOT CHECK TABLE COMPONENTS(1)
3
6
2
4
5
1
1
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 400-48055 MINI PATLITE ASM 2
2 PJ-3050400-01 TEE 1
3 BT-0400251-EA TUBE HOSE, BLUE 1
4 400-45984 SOT CHECK BASE 1
5 SM-1030601-SC SCREW M3 L=6 2
6 PJ-3010405-05 HALF UNION 1
- -
