Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V2
Option Input Conveyor Extension 05/2017
1 Introduction
1.3 Other Instructions
49
1.3.3.3 Handling ESD Modules
Do not touch electronic modules unless it is absolutely essential to do so in order to carry out other
work. If it is necessary, make sure that you do not touch the pins or printed conductors when you
pick up flat modules.
Do not touch components unless
●
You are constantly earthed by an ESD wrist strap or
●
You are wearing ESD shoes or ESD shoe earthing strips on an ESD floor.
Always discharge yourself before you touch an electronic module. To do this, simply touch a con-
ductive and earthed object immediately before you touch the module (such as unpainted parts of a
switch cabinet, a water pipe, etc.).
Do not allow modules with chargeable and highly insulating materials to touch one another, e.g.
plastic films, insulating table surfaces or items of clothing made from synthetic fibers.
Always place the modules on a conductive surface (table with an ESD coating, conductive ESD
foam, ESD bag or container).
Do not bring modules near visual display units, monitors or televisions. Keep them at least 10cm
away from the screen.
1.3.3.4 Measurements and Modifications to ESD Modules
Measurements of the assemblies may only be taken if
●
The measuring device has been grounded (e.g. via protective conductor) or
●
you discharge the measuring head before taking measurements with a potential-free measur-
ing device (e.g. by touching an unpainted metal part of the controller casing).
► Always use an earthed soldering iron if you carry out any soldering work.
1.3.3.5 Dispatching ESD Modules
► Always store modules and components in conductive packaging (e.g. metalized plastic bags
or metal sleeves) and dispatch them in conductive packaging.
► If the packaging is not conductive, place the modules in a conductive envelope before pack-
aging. Use conductive expanded rubber, ESD bags, domestic aluminum foil or paper, for ex-
ample.
► If the module has integral batteries, ensure that the conductive packaging does not touch or
short-circuit the battery terminals and, if necessary, first cover the terminals with insulating
tape or material.
1.3.4 Validity of Document
This document is valid for the following machine types:
●
SIPLACE SX1 and SX2
The work described in this manual is divided into modules, and to a large extent, it is identical for
all machine types:
●
If the work required for specific machines differs from the standard procedure, this will be in-
dicated with reference to the machine number, series and delivery state.
●
Illustrations are only shown as examples, for example, the illustration of a specific machine
type or a machine with different paint finish does not imply that the information following the il-
lustration only applies to the shown machine type.
Please read the circuit diagram folder for any electrical checks.
●
Detailed circuit diagrams folder SIPLACE SX1/SX2 V2 (from Lxxxx) [DE+EN:00196979-xx]
●
Detailed circuit diagrams folder SIPLACE SX1/SX2 V2 (from Nxxxx onwards) [DE
+EN:00197899-xx]
1 Introduction
1.4 Staff Qualifications and Training
Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V2
Option Input Conveyor Extension 05/2017
50
1.3.5 Release History
Document
SIPLACE SX1/SX2 V2
Input conveyor extension option
Assembly Instructions
Edition Changes
05/2017 First edition
1.4 Staff Qualifications and Training
Qualified or adequately trained personnel means that these people are familiar with the setting up,
operation and maintenance of the machine and the add-on devices and are suitably qualified, e.g.:
●
Have been trained, instructed or authorized to switch on and off, isolate, earth and identify
electrical circuits and system components in accordance with normal safety standards.
●
Have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-
cordance with normal safety standards.
●
Have received first aid training.
Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V2
Option Input Conveyor Extension 05/2017
2 Brief description
2.1 Product description
51
2 Brief description
2.1 Product description
This input conveyor extension option allows you to extend the conveyor beyond the standard width
of the machine.
The input conveyor extension can be installed on any machine in the line. This improves access to
the machines.
In addition, the input conveyor extension is required to install the "SICK LECTOR620 PCB barcode
scanner" option.
NOTICE
PCB barcode scanner without input conveyor extension
However, it is possible to use the COGNEX DM100 or DM150, which do not require the in-
put conveyor extension. These barcode scanners can be installed behind the narrow cover
in the input area in front of the machine.
2.2 Prerequisites
The input conveyor extension can be installed on any SIPLACE SX1/SX2 V2 machine in the line.
The input conveyor extension is required to install the "PCB barcode scanner" option. For more in-
formation, see the "PCB Barcode" assembly instructions [DE+EN:00197088‑xx].
