10.Y SLIDE(SY) 10.Y スライド(SY) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考 No. Drg.No. & Code No. QTY Description Rating Materials Remarks 83 H5265A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2X5L FE 84 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L F…
10.Y SLIDE(SY)
10.Y スライド(SY)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
38 N1126A 1 NUT, LOCK ﾅｯﾄ ﾛｯｸ MR20(M20 P=1.0) FE
39 H20742 2 PIN, TAPER ﾋﾟﾝ ﾃｰﾊﾟ φ6x25L ﾀｯﾌﾟﾄｵｼ(ﾒﾈｼﾞ) OT
40 H3145L 1
PLUG
ﾌﾟﾗｸﾞ KQ2P-06 OT
41 Y3079H 3
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-99 OT
42 Y3082C 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2VD06-01S OT
43 Y3066X 2
UNION
ﾕﾆｵﾝ KQ2E06-01 OT
44 K50764 1
CONNECTOR
ｺﾈｸﾀ KQ2U06-01S OT
45 K2010M 2 CAP ｷｬｯﾌﾟ C14 OT
46 S4045F 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX871A OT
51 K5170T
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M3X6L FE
52 K5256A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X8L FE
53 H5277A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X12L FE
54 K5257A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X8L FE
55 N4034T
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X18L FE
56 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X8L FE
58 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X10L FE
60 H5292A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X20L FE
61 K5261A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X10L FE
64 H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X15L FE
65 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X12L FE
66 H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X18L FE
67 H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X20L FE
68 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
69 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
70 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
71 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
72 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
73 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
74 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
75 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L FE
76 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L FE
77 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
78 N1080A
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7 FE
79 N1085A
NUT, HEX
ﾅｯﾄ 六角
M6 P=1.0 FE
80 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X20L FE
81 DGSY0210 2 BKT STOPPER BKT ｽﾄｯﾊﾟ FE
82 DGSY0220 2 BKT STOPPER BKT ｽﾄｯﾊﾟ FE
CP-743E PARTS LIST
106
10.Y SLIDE(SY)
10.Y スライド(SY)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
83 H5265A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M2X5L FE
84 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X12L FE
85 H5291A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X18L FE
86 H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L FE
87 H5326A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X25L FE
88
DGSY0420
1
SEET
ｼｰﾄ
PL
注1.(仕様選択部品)DGSD0780(t=0.95),DGSD0790(t=1.05),DGSD0810(t=0.975),DGSD0820(t=1.025)
Note.1:(Specified part selection)DGSD0780(t=0.95),DGSD0790(t=1.05),DGSD0810(t=0.975),DGSD0820(t=1.025)
