2.PLACING HEAD(PH) 2.プレーシングヘッド(PH) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考 No. Drg.No. & Code No. QTY Description Rating Materials Remarks 78 W1025A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE 79 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE 8…
2.PLACING HEAD(PH)
2.プレーシングヘッド(PH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
39 DCPH3681 1 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ FE
40 DCPH3662 1 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ FE
41 DGPH0040 1 SLIDER ｽﾗｲﾀﾞ FE
42 DCPH3690 1 JOINT ｼﾞｮｲﾝﾄ FE
43 ADGPH4306 16 SHAFT ｼｬﾌﾄASSY OT
44 DCPH3671 2 HOLDER ﾎﾙﾀﾞ FE
45 WPH0870 16 BKT BKT FE
46 DCPH0601 16 SPRING ｽﾌﾟﾘﾝｸﾞ FE
47 WPH2120 16 PIN ﾋﾟﾝ FE
48 H4272B 2 BEARING ﾍﾞｱﾘﾝｸﾞ MBWT10 FE
49 WPA5160 1
PLATE, END
ﾌﾟﾚｰﾄ ｴﾝﾄﾞ OT
50 S1021A 16
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-3 FE
51 W1019T 48 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ BBY0062611AO FE
52 H4451A 16
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1680ZZ FE
53 H4407T 16 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ TLA10105Z FE
54 H1163A 32 PACKING ﾊﾟｯｷﾝ MY-8 OT
55 A5054Y 32 O RING Oﾘﾝｸﾞ 4-1W OT
56 A5129T 16
O RING
Oﾘﾝｸﾞ S5 OT
57 ADCPH3266 16 HOLDER ﾎﾙﾀﾞ OT
58 DCPQ0260 1 DOG ﾄﾞｯｸﾞ OT
61 H52681 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2.5X18L FE
62 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L FE
63 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L FE
64 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L FE
65 H5278A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X15L FE
66 H5285A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X5L FE
67 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L FE
68 K52565
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X6L FE
69 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L FE
70 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
71 DCPH3630
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ FE
72 H5343A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X30L FE
73 H5195A
BOLT, HEX
ﾎﾞﾙﾄ 六角
M8X25L FE
74 W1020H
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2.5M/M FE
75 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
76 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
77 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
CP-743E PARTS LIST
10
2.PLACING HEAD(PH)
2.プレーシングヘッド(PH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
78 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
79 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
80 N1086A 2
NUT, HEX
ﾅｯﾄ 六角
M6 P=1.0 FE
81 N1024A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
82 N1089A
NUT, HEX
ﾅｯﾄ 六角
M8 P=1.25 FE
83 H5165A
BOLT, HEX
ﾎﾞﾙﾄ 六角
M3X10BL FE
84 DCPH3791 2 NUT, LOCK ﾅｯﾄ ﾛｯｸ FE
85 W1010A WASHER, CONICAL ﾜｯｼｬ 皿 M-3-L FE
86 H2040A 16 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ φ2X5 FE
87 DCPH0721 16 COLLAR ｶﾗｰ PL
88 DCPH1140 2 SEAL ｼｰﾙ OT
89 DCWM0040 3 SEAL ｼｰﾙ OT
90 DCPH3700 2 WASHER ﾜｯｼｬ FE
91 ADCPH3412 1 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ OT
92 ADCPH3452 1 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ OT
93 ADGPH3201 1 DRUM ﾄﾞﾗﾑ OT
94 ADGPH3301 16 SHAFT ｼｬﾌﾄ OT
95 ADGPH3401 1 CAM, CYLINDRICAL ｶﾑ 円筒 OT
96 ADGPH3501 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ OT
97 DCPH0040 1 GEAR, HELICAL ｷﾞﾔ ﾍﾘｶﾙ FE
98 W1014A WASHER, CONICAL ﾜｯｼｬ 皿 M-8-H FE
99 H5286A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X6L FE
100 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X20L FE
101 W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L FE
102 W1052A WASHER, FLAT ﾜｯｼｬ 平 8M/MX1.6X17(1W-8) FE
103
DCPA7050
1
NUT, LOCK
ﾅｯﾄ ﾛｯｸ
FE
注1.(仕様選択部品)DGPH3023(φ10.048),DGPH3033(φ10.043),DGPH3043(φ10.038),DGPH(φ10.033)
Note.1:(Specified part selection)DGPH3023(φ10.048),DGPH3033(φ10.043),DGPH3043(φ10.038)
