23.3.DEVICE TABLE(SD)
23.3.デバイステーブル(SD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
102 H5271A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2.6X8L FE
103 H5273A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X5L FE
104 H5274A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X6L FE
105 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L FE
106 H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L FE
107 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
108 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L FE
109 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L FE
110 H5294A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X30L FE
111 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L FE
113 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
116 H5311A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X60L FE
118 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L FE
119 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L FE
120 H5323A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18L FE
121 H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L FE
123 H5330A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X40L FE
124 H5340A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X15L FE
125 H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L FE
127 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
128 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
129 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
130 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
131 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
132 W1026A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M FE
133 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
134 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
135 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
136 W1046A WASHER, FLAT ﾜｯｼｬ 平 4W-8 FE
137 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L FE
138 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L FE
139 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
140 W1014A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-8-H FE
141 W1040A WASHER, FLAT ﾜｯｼｬ 平 3M/MX0.5X7(1W-3) FE
142 W1041A WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4) FE
143 W1051A WASHER, FLAT ﾜｯｼｬ 平 6M/MX1.6X125(1W-6) FE
144 N4031A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X10L FE
CP-743E PARTS LIST
193
23.3.DEVICE TABLE(SD)
23.3.デバイステーブル(SD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
145 K5257A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X8L FE
146 N1080A NUT, HEX ﾅｯﾄ 六角 M4 P=0.7 FE
148 N1091T NUT, HEX ﾅｯﾄ 六角 M10 P=1.25 FE
149 H5277A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X12L FE
150 K5359E
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M4X8L FE
151 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L FE
152 WWM0152 6 SEAL ｼｰﾙ PL Ref.31.3
153 DGWM0100 1 SEAL ｼｰﾙ PL Ref.31.3
154 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L FE
155 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L FE
156 H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L FE
157 W1020T
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2.6M/M FE
158 H5293A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X25L FE
159 H5327A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X30L FE
160 N1076A NUT, HEX ﾅｯﾄ 六角 M3 P=0.5 FE
161 DGSD0990 2 SPACER ｽﾍﾟｰｻ AL
162
DGSD1000
1
SPACER
ｽﾍﾟｰｻ
AL
注1.(選択部品)DCSD0901(t=7.01),DCSD0911(t=7.02),DCSD0921(t=7.03),DCSD0931(t=6.99),DCSD0941(t=6.98),DCSD0951(t=6.97)
DCSD1040(t=6.95),DCSD1050(t=6.96),DCSD1060(t=7.04),DCSD1070(t=7.05)
Note.1:(Specified parts selection)DCSD0901(t=7.01),DCSD0911(t=7.02),DCSD0921(t=7.03),DCSD0931(t=6.99),DCSD0941(t=6.98),DCSD0951(t=6.97)
DCSD1040(t=6.95),DCSD1050(t=6.96),DCSD1060(t=7.04),DCSD1070(t=7.05)
注2.(選択部品)DCSD5620(t=7.01),DCSD5630(t=7.02),DCSD5640(t=7.03),DCSD5650(t=6.99),DCSD5660(t=6.98),DCSD5670(t=6.97)
DGSD5780(t=6.95),DGSD5790(t=6.96),DGSD5800(t=7.04),DGSD5810(t=7.05)
Note.2:(Specified parts selection)DCSD5620(t=7.01),DCSD5630(t=7.02),DCSD5640(t=7.03),DCSD5650(t=6.99),DCSD5660(t=6.98),DCSD5670(t=6.97)
DGSD5780(t=6.95),DGSD5790(t=6.96),DGSD5800(t=7.04),DGSD5810(t=7.05)
