24.2.CAM BOX(PA)
24.2.カムボックス(PA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
124 DCPA0650 1 BKT BKT FE
125 DCPA0670 1 BKT BKT FE
126 DCPA0680 1 BKT BKT FE
127 DCPA6000 1 LEVER ﾚﾊﾞｰ FE
128 DCPA0120 1 LEVER ﾚﾊﾞｰ FE
129 DCPA0130 1 LEVER ﾚﾊﾞｰ FE
130 DCPA0140 1 LEVER ﾚﾊﾞｰ FE
131 DCPA0090 1 LEVER ﾚﾊﾞｰ FE
132 DCPA0150 1 LEVER ﾚﾊﾞｰ AL
133 DCPA0160 1 LEVER ﾚﾊﾞｰ FE
134 DCPA0721 1 SHAFT ｼｬﾌﾄ FE
135 DCPA0701 1 SHAFT ｼｬﾌﾄ FE
136 DCPA0770 1 COLLAR ｶﾗｰ FE
137 DCPA0780 1 COLLAR ｶﾗｰ FE
151 R50011 1 ROLLER ﾛｰﾗ NSAT8ZZ OT
152 N1085A 4 NUT, HEX ﾅｯﾄ 六角 M6 P=1.0 FE
155 H4402D 12
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA79Z FE
156 S40443 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX770A OT
163 W1066A 4
WASHER, A
ﾜｯｼｬ A AW04 FE
164 S31207 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX771A OT
166 DCPA1240 5 BOLT ﾎﾞﾙﾄ FE
167 R5024D 6 ROLLER, NEEDLE ﾛｰﾗ ﾆｰﾄﾞﾙ φ4X19.8 OT
171 S3021M 3 SPRING, SQUARE ｽﾌﾟﾘﾝｸﾞ 角 TF20X50(ｷｲﾛ) FE
172 S3022Y 1 SPRING, SQUARE ｽﾌﾟﾘﾝｸﾞ 角 TM22X80(ｱｶｲﾛ) FE
173 H4395A 3
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TA2020Z FE
174 H4394T 3 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TA2025Z FE
175 H4395D 2 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TA2015Z FE
176 H4301F 16 BEARING, THRUST ﾍﾞｱﾘﾝｸﾞ ｽﾗｽﾄ NTB2035 FE
177 H4297F 31 BEARING, THRUST ﾍﾞｱﾘﾝｸﾞ ｽﾗｽﾄ AS2035 FE
178 H4130E 14
BEARING
ﾍﾞｱﾘﾝｸﾞ 608ZZ FE
179 S1001A 14 CIR-CLIP ｻｰｸﾘｯﾌﾟ RTW22 FE
180 S1005T 2
CIR-CLIP
ｻｰｸﾘｯﾌﾟ RTW28 FE
181 H4157R 2 BEARING ﾍﾞｱﾘﾝｸﾞ 16001 FE
184 DCPA4801 1 SHAFT ｼｬﾌﾄ FE
185 DCPA0740 1 COLLAR ｶﾗｰ FE
186 WPA5160 6 PLATE, END ﾌﾟﾚｰﾄ ｴﾝﾄﾞ FE
203 DCPA0750 1 COLLAR ｶﾗｰ FE
CP-743E PARTS LIST
212
24.2.CAM BOX(PA)
24.2.カムボックス(PA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
204 DCPA0760 1 COLLAR ｶﾗｰ FE
206 DCPA0831 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ OT
207 DCPA0100 1 LEVER ﾚﾊﾞｰ FE
208 DCPA1001 1 DOG ﾄﾞｯｸﾞ FE
215 GPH4491 7 ROLLER ﾛｰﾗ FE
217 DCPA0610 1 BKT BKT FE
218 DCPA0620 2 BKT BKT FE
228 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L FE
230 H5277A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X12L FE
232 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
233 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L FE
234 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L FE
236 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L FE
238 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L HRC34-44 FE
240 H5307A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X40L FE
241 H5320A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X10L FE
243 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L FE
245 H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L ｾﾞﾝﾈｼﾞ FE
246 H5340A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X15L FE
247 H5341A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X20L FE
248 H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L FE
255 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
256 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
257 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
258 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
259 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
263 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
266 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L FE
268 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
269 W1014A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-8-H FE
270 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
273 N4024A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M3X12L FE
276 N4041A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M5X15L FE
277 N1082A
NUT, HEX
ﾅｯﾄ 六角
M5 P=0.8 FE
278 N1076A NUT, HEX ﾅｯﾄ 六角 M3 P=0.5 FE
280 N1090A NUT, HEX ﾅｯﾄ 六角 M8 3ｼｭ FE
281 N1092A NUT, HEX ﾅｯﾄ 六角 M10 P=1.5 FE
CP-743E PARTS LIST
213
24.2.CAM BOX(PA)
24.2.カムボックス(PA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 材質 備考
No. Drg.No. & Code No. QTY Description Rating Materials Remarks
283 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
284 N1089A NUT, HEX ﾅｯﾄ 六角 M8 P=1.25 FE
292 N1045A 4 NUT A ﾅｯﾄ A AN04(Aﾅｯﾄ) FE
303 WPI0020 1 TERMINAL ﾀｰﾐﾅﾙ AL
304 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L FE
313 DCWM0240 1 SEAL ｼｰﾙ PL Japanese(Ref.31.4)
314 DCWM0440 1 SEAL ｼｰﾙ PL English(Ref.31.5)
315 DCWM0640 1 SEAL ｼｰﾙ PL French(Ref.31.6)
316 DCWM0250 1 SEAL ｼｰﾙ PL Japanese(Ref.31.4)
317 DCWM0450 1 SEAL ｼｰﾙ PL English(Ref.31.5)
318 DCWM0650 1 SEAL ｼｰﾙ PL French(Ref.31.6)
319 H5327A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X30L HRC34-44 FE
320 DCPA4810 1 BUSH ﾌﾞｯｼｭ FE
321 Y3049W 3 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KJL06-01S(ｼﾛ) OT
