Section 1

Periodic Inspections

1-A

This section explains the periodic maintenance for the per-

son in charge of maintenance of this machine.

0305-001 Tg0860-PM-MM1-B

Tg0860-PM-MM

Power Breaker

Padlock (No. 2500 30mm)

1. Precautionary Items before Maintenance

0307-002 1-1

1. Precautionary Items before Maintenance

This session describes how to perform inspections, cleaning, lubrication, and

adjustment to keep the machine in good shape.

It is recommended that periodic maintenance of the machine should be en-

sured.

• Only qualified personnel should perform maintenance work carefully in

compliance with the specified procedures.

WARNING

Fig. 4A1

Fig. 4A2

• Before maintenance work, be sure to lock the power breaker

and the main valve section (air source) with padlocks.

Power Breaker : Set the power breaker to the “OFF” side and

lock it with a padlock.

Air Source : Set the main valve in the direction shown in the

figure and lock it with a padlock.

• Designate a person who can have charge of the padlock key.

• If the provided padlock is lost or damaged, purchase its sub-

stitute.

Power Supply Section

Air Source Section

WARNING

Padlock

(No. 2500 25mm)

Main Valve
