Wiring Diagram
Model No. NM-EJM6D
NM-EJM6D-MA
NM-EJM6D-MD
NM-EJM6D-A
NM-EJM6D-D
Production Modula
r
NPM-D3
N7205A106B18
201801
Wiring diagram
D00ABE-00-602-01 Page 1
1.
How to order parts
1. Order details
Make sure to specify the product number, cable ordering part number, part name and quantity of a
part in your order.
2. Order to
Please place your order with your sales company /agent.
[NOTICE]
In the presence of
“Wiring diagram (Custom)
,
”
cables different from the ones listed in
“Wiring
diagram (Standard)”
may be used in the machine.
Therefore, if there is
“Wiring diagram (Custom)
,
”
please specify the cables listed in
“Wiring di-
agram (Custom)”
first and then those in
“Wiring diagram (Standard)
.
”
NM-EJM5D N61012345A
A
CABLE 1
Product
number
Cable ordering part
number
Part name
Quantity
