INFINITY 0$&+,1( 352*5$ 00,1* 0(183$5$ 0(7(5 6 1.98 User Manual Software Versi on 7 Paste With Board This parameter gives the option to dispense paste with a board loaded and held at print height. This prevents pas…
INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 7 User Manual 1.97
Paste Ridge
Removal
This parameter enables the cleaning option Paste Ridge Removal. This option
removes the ridge of paste that can develop on the underside of the screen at the
end of the under screen cleaner stroke. Options are:
Print Deposits This parameter sets the number of consecutive print strokes carried out on one
substrate.
Print Vacuum
Mode
This parameter determines the state of the vacuum during the print and flood
stages of the cycle. The parameter is only available if Adhesive has been selected
in the Print Mode parameter.
Paste Dispense
Rate
This parameter sets the number of print cycles which occur between cycling of
the paste dispense system.
Paste Dispense
Speed
This parameter sets the speed at which the paste dispenser moves across the
screen thereby determining the amount of paste deposited on the screen.
Paste While Clean This parameter enables the machine to carry out a paste dispense while cleaning
the screen. Available modes are:
Option Default
Disabled Disabled
Enabled
Select Default
11
2
3
Mode
ON
OFF
Minimum Maximum Increment
0 (Dispenser switched off) 100 1
Minimum Maximum Increment
10.0mm/sec 100.0mm/sec 1.0mm/sec
Mode
Disabled
Mode 1
Mode 2
Both Modes
INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.98 User Manual Software Version 7
Paste With Board This parameter gives the option to dispense paste with a board loaded and held
at print height. This prevents paste dropping through the image on the screen.
Options are:
NOTE
With enabled selected the parameter Paste While Clean is removed.
Alternate Disp This parameter gives the option to dispense at either ENDS or CENTRE. ENDS
dispenses at the outer 25% of the squeegees. CENTRE dispenses along an area
of 25% either side of the centre line.
Alternate Disp
Rate
This parameter enables the user to select the ratio of alternate dispenses to
standard dispenses.
Paste Recovery
Rate
This parameter sets the frequency, measured in print strokes completed in either
direction, at which paste roll recovery occurs in both directions, when using
squeegees.
Front Paste
Recovery
This parameter sets the extent of paste roll recovery movement while beginning
the rearward print stroke. The movement is measured forward from the print
stroke start position.
Options Available
Enabled
Disabled
Options Available
Ends
Centre
No Alternate Dispense Every Dispense Every Second Dispense etc.
Minimum Maximum Increment Default
0
(This disables paste
roll recovery)
500 1 1
Minimum Maximum Increment Default
0.0mm 15.0mm
(Subject to front turn-
around envelope)
1.0mm 5.0mm
INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 7 User Manual 1.99
Rear Paste
Recovery
This parameter sets the extent of paste roll recovery movement while beginning
the forward print stroke. The movement is measured rearward from the print
stroke start position.
Screen Clean Mode
1 (including
Vacuum)
This parameter sets the mode of operation of the screen cleaner for the first clean
mode. When selected this parameter opens a window that allows a screen clean
option sequence to be chosen. The sequence includes six stages, each of which
may be one of the following cleaning operations:
Screen Clean
Rate 1
This parameter sets the number of print cycles between the cycling of the screen
cleaner for the first screen clean rate.
Screen Clean Mode
2 (including
Vacuum)
This parameter sets the mode of operation of the screen cleaner for the second
clean mode. When selected this parameter opens a window that allows a screen
clean option sequence to be chosen. The sequence includes six stages, each of
which may be one of the following cleaning operations:
Screen Clean
Rate 2
This parameter sets the number of print cycles between the cycling of the screen
cleaner for the second screen clean rate.
Minimum Maximum Increment Default
0.0mm 15.0mm
(Subject to rear turn-
around envelope)
1.0mm 5.0mm
Cleaning Operation Note
Wet A warning is given if the end stroke is wet.
Dry
Vac
None
Minimum Maximum Increment
0 (Screen cleaner off) 200 1
Cleaning Operation Note
Wet A warning is given if the end stroke is wet.
Dry
Vac
None
Minimum Maximum Increment
0 (Screen cleaner off) 200 1
