INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.100 User Manual Software Version 7
Vortex Cassette
Life (Vortex USC)
This parameter sets the number of cleaning strokes that are applied before a
cleaning cassette is replaced.
Vortex Clean Rate
(Vortex USC)
This parameter sets the frequency (in print cycles) at which screen cleaning
occurs.
Vortex Solvent
Rate (Vortex USC)
This parameter sets the frequency (in cleaning cycles) at which solvent is
dispensed.
Vortex Vacuum
Start (Vortex USC)
The distance, in from the front edge of the board, where vacuum is applied.
Vortex Vacuum
Stop (Vortex USC)
The distance, in from the front edge of the board, where vacuum application is
stopped.
Vortex Vacuum
Rate (Vortex USC)
This parameter sets the frequency (in cleaning cycles) at which vacuum is
applied.
Vortex Vacuum
Period (Vortex
USC)
This parameter sets the period for which vacuum is applied.
Minimum Maximum Increment Default
0.0 200.0 1.0 20.0
Minimum Maximum Increment Default
0.0 200.0 1.0 0.0
Minimum Maximum Increment Default
1.0 10.0 1.0 1.0
Minimum Maximum Increment Default
Vacuum Stop Board Width 1.0 0.0
Minimum Maximum Increment Default
-100.0mm Vacuum Stop 1.0mm 0.0mm
Minimum Maximum Increment Default
1.0 10.0 1.0 1.0
Minimum Maximum Increment Default
1.0 sec 10.0 secs 1.0 sec 5.0 secs
INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 7 User Manual 1.101
Clean After Knead This function is active if the machine is running in automatic mode. If this
option is enabled and a paste dispense has been performed (either MANUAL or
AUTOMATIC) a paste knead is performed as defined by the paste knead
parameters in the board file on the next board immediately following the paste
dispense. When selected this parameter opens a window that allows a clean after
knead option sequence to be chosen. The sequence includes six stages, each of
which may be one of the following cleaning operations:
Clean After
Downtime
This function provides the facility for the screen to be cleaned automatically
with a preprogrammed clean after a preprogrammed idle time. Clean After
Downtime only becomes active after the machine has performed at least one
print after it is powered up. When selected this parameter opens a window that
allows a clean after knead option sequence to be chosen. The sequence includes
six stages, each of which may be one of the following cleaning operations:
Clean After The Automatic screen clean after downtime process chosen in the above menu
parameter is carried out after a countdown of the number of minutes set in this
parameter.
Dry Clean Speed This parameter sets the speed of the screen clean dry wipe for optimization on
the Blue USC and the speed of the screen clean return stroke on the Vortex USC.
Wet Clean Speed This parameter sets the speed of the screen clean wet wipe for optimization.
Cleaning Operation Note
Wet A warning is given if the end stroke is wet.
Dry
Vac
None
Cleaning Operation Note
Wet A warning is given if the end stroke is wet.
Dry
Vac
None
Minimum Maximum Increment
5.0 mins 120.0 mins 1.0 min
Minimum Maximum Increment
10.0mm/sec 120.0mm/sec 1.0mm/sec steps
Minimum Maximum Increment
10.0mm/sec 100.0mm/sec 1.0mm/sec steps
INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.102 User Manual Software Version 7
Vac Clean Speed This parameter sets the speed of the screen clean vacuum for optimization.
Front Start Offset
(Blue USC)
This parameter determines the distance from the front edge of the board that the
cleaning stroke must start.
Front Start Offset
(Vortex USC)
This parameter determines the distance from the front edge of the board that the
cleaning stroke must finish.
Rear Start Offset
(Blue USC)
This parameter determines the distance from the rear edge of the board that
cleaning must complete.
Rear Start Offset
(Vortex USC)
This parameter determines the distance from the rear edge of the board that
cleaning must start.
Stop After Idle This parameter when enabled sets the time the product is held in contact with
the screen until both upline and downline systems are ready to transfer.
Paste Knead Period This parameter sets the time period between print cycles which, if exceeded,
initiates a paste knead sequence.
Knead Deposits This parameter sets the number of print strokes to be carried out on each of the
kneaded boards.
Minimum Maximum Increment
10.0mm/sec 100.0mm/sec 1.0mm/sec steps
Minimum Maximum Increment
0.0mm 60.0mm 1.0mm
Minimum Maximum Increment Default
-60.0mm 60.0mm 1.0mm 30.0mm
Minimum Maximum Increment
0.0mm 60.0mm 1.0mm
Minimum Maximum Increment Default
-60.0mm 60.0mm 1.0mm 30.0mm
Minimum Maximum Increment
0.0 mins 200.0 mins 1.0 min
Minimum Maximum Increment
0 (paste kneading switched off) 30 minutes 1 minute
Minimum Maximum Increment
