INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 7 User Manual 1.103
Knead Boards This parameter sets the number of boards to be printed using the knead sequence.
Knead After
Dispense
If this option is enabled and a paste dispense has been performed (either Manual
or Automatic) a paste knead is performed (as defined by the paste knead
parameters in the board file) on the next board immediately following the paste
dispense.
ProFlow Cassette This parameter sets the size of the transfer head used by the ProFlow unit. Size
may be one of the following:
NOTE
For 350mm and 450mm transfer heads, set to 400mm and 500mm respectively.
ProFlow System
Pressure
This is the amount of print pressure (downward force) applied onto the stencil
by the ProFlow unit.
ProFlow Paste
Pressure
This is the pressure applied to paste in the ProFlow unit while kneading and
printing.
NOTE
Only available if the Software Controlled Air Regulator (SCAR) is fitted.
ProFlow Idle
Pressure
This is the pressure applied to paste in the ProFlow unit between kneading and
printing and between print strokes.
NOTE
Only available if the Software Controlled Air Regulator (SCAR) is fitted.
Minimum Maximum Increment
1101
Options Available
Enabled
Disabled
Size
300.0mm
400.0mm
500.0mm
Minimum Maximum Increment Default
0.0Kg 20.0Kg 0.2Kg 0.0Kg
Minimum Maximum Increment Default
0.2 bar 4.0 bar 0.2 bar 2.0 bar
Minimum Maximum Increment Default
0.0 bar 4.0 bar 0.2 bar 0.4 bar
INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.104 User Manual Software Version 7
Front Knead Speed This parameter sets the speed of kneading in the forward direction.
Rear Knead Speed This parameter sets the speed of kneading in the rearward direction.
Front Knead
Pressure
This parameter sets the pressure to be applied, while using squeegees, when
kneading in the forward direction.
Rear Knead
Pressure
This parameter sets the pressure to be applied, while using squeegees, when
kneading in the rearward direction.
Board 1 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Board 2 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 10.0mm/sec
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 10.0mm/sec
Minimum Maximum Increment Default
0.0Kg 20.0Kg 0.2Kg 5.0Kg
Minimum Maximum Increment Default
0.0Kg 20.0Kg 0.2Kg 5.0Kg
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 7 User Manual 1.105
Board 3 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Select Mark Type This determines the type of model to be used on the board for the select mark.
Options are:
NOTE
Only used while Selective Print/Pass is enabled in Set preferences.
Screen 1 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
