Front Knead Speed This parameter sets the speed of kneading in the forward direction.
Rear Knead Speed This parameter sets the speed of kneading in the rearward direction.
Front Knead
Pressure
This parameter sets the pressure to be applied, while using squeegees, when
kneading in the forward direction.
Rear Knead
Pressure
This parameter sets the pressure to be applied, while using squeegees, when
kneading in the rearward direction.
Board 1 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Board 2 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 10.0mm/sec
Minimum Maximum Increment Default
2.0mm/sec 150.0mm/sec 1.0mm/sec 10.0mm/sec
Minimum Maximum Increment Default
0.0Kg 20.0Kg 0.2Kg 5.0Kg
Minimum Maximum Increment Default
0.0Kg 20.0Kg 0.2Kg 5.0Kg
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 7 User Manual 1.105
Board 3 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Select Mark Type This determines the type of model to be used on the board for the select mark.
Options are:
NOTE
Only used while Selective Print/Pass is enabled in Set preferences.
Screen 1 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.106 User Manual Software Version 7
Screen 2 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Screen 3 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Fiducial 1 X
Coordinate
Distance of first fiducial from the right or left hand edge of the board (configu-
ration dependent).
If the current product includes at least one inspection site, changing the value of
the parameter causes the following warning and menu bar to be displayed:
On selecting Apply the alterations to the fiducial positions become effective and
are applied to all inspection sites.
On selecting Abandon Changes the alterations to the fiducial positions are
discarded, the positions of the inspection sites remain unaltered and control is
returned to the initiating sequence.
On selecting Don’t Apply the alterations to the fiducial positions become
effective, but are not applied to the inspection sites.
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
Minimum Maximum Increment Default
1.0mm Board Length 0.1mm 1.0mm
Warning
From the changes made to fiducial positions
do you want a correction to be applied to
all inspection sites?
Apply
Abandon
Changes
Don’t
Apply
