INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 7 User Manual 1.111
Board Stop X This parameter determines the distance from the centre line of the machine to
the board stop position.
NOTE
Not used while the remote board stop is fitted.
Board Stop Y This parameter determines the distance from the fixed rail to the board stop
position.
NOTE
Not used while the remote board stop is fitted.
Right Feed Delay This parameter sets a time delay on the board stop to allow for irregular shaped
boards when fed from the right.
NOTE
Not used while remote board stop is fitted.
Remote Board Stop
X
This parameter determines the displacement of the remote board stop from the
camera reference position.
NOTE
Only used while remote board stop is fitted.
Paste Start This parameter determines the start position of the paste dispense measured from
the centre line of the machine. The limits depend on the type of screen fitted.
Minimum Maximum Increment Default
0.0mm 255.0mm 0.1mm Half of the board length set in the board
file, (board located centrally)
Minimum Maximum Increment Default
20.0mm Board width - 15.0mm 0.1mm Two thirds of the board width
Minimum Maximum Increment
0 sec 3 secs 0.1 sec steps
Minimum Maximum Increment Default
Minimum board length
÷ 2 Board length 0.1mm Board length ÷ 2
Minimum Maximum
Adapter Start Position Adapter Start Position
No Adapter -255.0mm No Adapter +255.0mm
255 -230.0mm 255 +230.0mm
Sanyo -210.0mm Sanyo +210.0mm
Heraeus -172.0mm Heraeus +172.0mm
249 -215.0mm 249 +215.0mm
Default - half the board length Default + half the board length
INFINITY
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.112 User Manual Software Version 7
Paste Stop This parameter determines the stop position of the paste dispense measured from
the centre line of the machine. The maximum value depends on the type of
screen fitted.
SPC Configuration This preference allows the user to set up the Machines SPC operation. On
selecting the SPC Configuration by pressing the Incr. or Decr. buttons, a window
opens and the menu bar changes.
NOTE
See the SPC Configuration section in this chapter for further details.
Minimum Maximum
Adapter Start Position Adapter Start Position
No Adapter -255.0mm No Adapter +255.0mm
255 -230.0mm 255 +230.0mm
Sanyo -210.0mm Sanyo +210.0mm
Heraeus -172.0mm Heraeus +172.0mm
249 -215.0mm 249 +215.0mm
Default - half the board length Default + half the board length
INFINITY
0$&+,1(352*5$00,1*
63&&21),*85$7,21
Software Version 7 User Manual 1.113
SPC CONFIGURATION
When the cursor on the Edit Current Process Parameters page highlights the SPC
Configuration option and Incr. or Decr. are pressed an SPC Configuration
Window opens and two extra menu options become available:
Configuration
Window
The configuration window allows the user to setup the machines SPC operation.
Data Output Rate Two rates of data output are available as follows:
Every Cycle - Outputs SPC data every cycle except for the camera data, which
is output dependant upon the settings of the parameters start rate, sample rate
and start rate limit.
On Inspect - Outputs all SPC data at a rate dependant upon the settings of the
parameters start rate, sample rate and start rate limit.
Start Rate Limit Sets the amount of SPC output cycles at the start rate. When this limit is reached
the sample rate parameter becomes the active SPC output rate. The range is 0-
100, where 0 = continuous SPC output at the start rate.
NOTE
Setting both start rate limit and sample rate to zero causes continuous SPC
output at the start rate.
Start Rate Sets the initial SPC output rate, for setting up a line. If start rate is set to 10, SPC
data is output every 10 cycles until the start rate limit is reached, when the rate
becomes that set in the sample rate parameter. The range is 1-100.
Sample Rate Sets the rate of SPC output after the start rate limit has been reached. The range
is 0-100, where 0 = continuous SPC outputs at start rate. If sample rate is set to
15, SPC data is output every 15 cycles after the start rate limit is reached.
Edit
Outputs
Edit
Limits
Next Previous Incr. Decr. Exit
SPC Configuration Page
DATA OUTPUT RATE
START RATE
SAMPLE RATE
START RATE LIMIT
SPC DATA MODE
SPC FORMAT
UPDATE ON START-UP
ALIGN INSPECT MODE
EVERY CYCLE
1
10
10
NONE
WINDOWS
NO
PRE PRINT
cycles
cycles
cycles
