INFINITY
6(735()(5(1&(6
35()(5(1&(6
Software Version 7 User Manual 2.11
Consumable
Action
Sets how the machine reacts to a cleaner paper low, cleaner solvent low, print
medium low or Vortex cleaning cassette expired, options are:
Vacuum Hold Time Used when Flexible Board Printing option is fitted, this parameter introduces a
time delay between raising the table to flex print height and initiating Flatten Vac
Delay, options are:
2D Inspection Sets whether the 2D inspection facility is to be used, options are:
2Di Movement
Tuning
Used to determine whether camera movement is to be tuneable. While the value
is other than zero; the camera, upon arrival at an inspection site, is allowed to
settle for the period set before proceeding with acquisition and inspection.
Image Recording Sets whether video images can be recorded, options are:
NOTE
PC disk requires the PC to have 8Mb ram and VP disk requires a SCSI disk to
be attached to the VP.
Parameter Definition
Warn A warning window is displayed, but printing proceeds without
interruption.
The tricoloured beacon shows amber/green.
Pause A pause on warning window is displayed and printing is delayed to enable
the user to either; replenish the consumable resource, or defer the replen-
ishment until later and continue printing.
The tricoloured beacon shows red.
Suspend A suspend on warning window is displayed and printing is suspended and
remains suspended, until the consumable resource has been replenished.
The tricoloured beacons shows red.
Before printing commences the consumable resources are checked for
availability, before allowing the print run to proceed.
Minimum Maximum Increment
0.000 secs 5.000 secs 0.100 secs
Options
Enabled
Disabled
Minimum Maximum Increment Default
0 milliseconds 250 milliseconds 50 milliseconds 250 milliseconds
Options Default
OFF OFF
PC Disk
VP Disk
INFINITY
6(735()(5(1&(6
35()(5(1&(6
2.12 User Manual Software Version 7
Under Screen
Cleaner
Sets whether or not the vacuum option is fitted to the machine, options are:
If standard is selected the vacuum options are removed from the screen clean
mode parameters. If Vortex under screen cleaner is fitted, vacuum is the only
option.
To disable the Vortex under screen cleaner carry out the following:
Blue Under Screen
Cleaner
To enable the blue under screen cleaner carry out the following:
1. Press the function key F10 on the keyboard, the following window is
displayed:
NOTE
If the Vortex under screen cleaner is currently enabled, carry out disabling
the Vortex under screen cleaner.
2. Type bluon using the keyboard.
3. Press Enter, the message ‘Blue Under-Screen Cleaner Enabled’ is
displayed in the message prompt bar.
4. Press Exit.
To disable the blue under screen cleaner carry out the following:
1. Press the function key F10 on the keyboard, a window of the following form
is displayed:
2. Type bluoff using the keyboard.
3. Press Enter, the message ‘Blue Under-Screen Cleaner Disabled’ is
displayed in the message prompt bar.
The silver under screen cleaner becomes the current cleaner and all cleaner
parameters revert to being appropriate to the previous cleaner.
The value of the configuration parameter cleaner type is set to silver and this
parameter is written to the configuration file.
4. Press Exit.
Options Default
Vacuum Standard
Standard
<Enter> to Close ...
Serial Number
Executable date
Executable time
Executable name
Software Version
Options Enabled
:
:
:
:
:
:
201305
March 19 2000
10:57:38
RR0400.EXE
05.00
SBNG
INFINITY
<Enter> to Close ...
Serial Number
Executable date
Executable time
Executable name
Software Version
Options Enabled
:
:
:
:
:
:
201305
March 19 2000
10:57:38
RR0400.EXE
05.00
SBNG
INFINITY
INFINITY
6(735()(5(1&(6
35()(5(1&(6
Software Version 7 User Manual 2.13
Vortex Under Screen
Cleaner
To enable the Vortex under screen cleaner carry out the following:
1. Press the function key F10 on the keyboard, a window of the following form
is displayed:
NOTE
If the blue under screen cleaner is currently enabled, carry out disabling the
blue under screen cleaner first.
2. Type vorton using the keyboard.
3. Press Enter, the message ‘Vortex Under-Screen Cleaner Enabled ’is
displayed in the message prompt bar.
The Vortex under screen cleaner becomes the current cleaner and all cleaner
parameters become appropriate to the Vortex cleaner.
The value of the configuration parameter cleaner type is set to Vortex and
this parameter is written to the configuration file.
4. Press Exit.
1. Press the function key F10 on the keyboard, a window of the following form
is displayed:
2. Type vortoff using the keyboard.
3. Press Enter, the message Vortex Under-Screen Cleaner Disabled is dis-
played in the message prompt bar.
The silver under screen cleaner becomes the current cleaner and all cleaner
parameters revert to being appropriate to the previous cleaner.
The value of the configuration parameter cleaner type is set to silver and this
parameter is written to the configuration file.
4. Press Exit.
<Enter> to Close ...
Serial Number
Executable date
Executable time
Executable name
Software Version
Options Enabled
:
:
:
:
:
:
201305
March 19 2000
10:57:38
RR0400.EXE
05.00
SBNG
INFINITY
<Enter> to Close ...
Serial Number
Executable date
Executable time
Executable name
Software Version
Options Enabled
:
:
:
:
:
:
201305
March 19 2000
10:57:38
RR0400.EXE
05.00
SBNG
INFINITY
