INFINITY
6(735()(5(1&(6
35()(5(1&(6
2.12 User Manual Software Version 7
Under Screen
Cleaner
Sets whether or not the vacuum option is fitted to the machine, options are:
If standard is selected the vacuum options are removed from the screen clean
mode parameters. If Vortex under screen cleaner is fitted, vacuum is the only
option.
To disable the Vortex under screen cleaner carry out the following:
Blue Under Screen
Cleaner
To enable the blue under screen cleaner carry out the following:
1. Press the function key F10 on the keyboard, the following window is
displayed:
NOTE
If the Vortex under screen cleaner is currently enabled, carry out disabling
the Vortex under screen cleaner.
2. Type bluon using the keyboard.
3. Press Enter, the message ‘Blue Under-Screen Cleaner Enabled’ is
displayed in the message prompt bar.
4. Press Exit.
To disable the blue under screen cleaner carry out the following:
1. Press the function key F10 on the keyboard, a window of the following form
is displayed:
2. Type bluoff using the keyboard.
3. Press Enter, the message ‘Blue Under-Screen Cleaner Disabled’ is
displayed in the message prompt bar.
The silver under screen cleaner becomes the current cleaner and all cleaner
parameters revert to being appropriate to the previous cleaner.
The value of the configuration parameter cleaner type is set to silver and this
parameter is written to the configuration file.
4. Press Exit.
Options Default
Vacuum Standard
Standard
<Enter> to Close ...
Serial Number
Executable date
Executable time
Executable name
Software Version
Options Enabled
:
:
:
:
:
:
201305
March 19 2000
10:57:38
RR0400.EXE
05.00
SBNG
INFINITY
<Enter> to Close ...
Serial Number
Executable date
Executable time
Executable name
Software Version
Options Enabled
:
:
:
:
:
:
201305
March 19 2000
10:57:38
RR0400.EXE
05.00
SBNG
INFINITY
INFINITY
6(735()(5(1&(6
35()(5(1&(6
Software Version 7 User Manual 2.13
Vortex Under Screen
Cleaner
To enable the Vortex under screen cleaner carry out the following:
1. Press the function key F10 on the keyboard, a window of the following form
is displayed:
NOTE
If the blue under screen cleaner is currently enabled, carry out disabling the
blue under screen cleaner first.
2. Type vorton using the keyboard.
3. Press Enter, the message ‘Vortex Under-Screen Cleaner Enabled ’is
displayed in the message prompt bar.
The Vortex under screen cleaner becomes the current cleaner and all cleaner
parameters become appropriate to the Vortex cleaner.
The value of the configuration parameter cleaner type is set to Vortex and
this parameter is written to the configuration file.
4. Press Exit.
1. Press the function key F10 on the keyboard, a window of the following form
is displayed:
2. Type vortoff using the keyboard.
3. Press Enter, the message Vortex Under-Screen Cleaner Disabled is dis-
played in the message prompt bar.
The silver under screen cleaner becomes the current cleaner and all cleaner
parameters revert to being appropriate to the previous cleaner.
The value of the configuration parameter cleaner type is set to silver and this
parameter is written to the configuration file.
4. Press Exit.
<Enter> to Close ...
Serial Number
Executable date
Executable time
Executable name
Software Version
Options Enabled
:
:
:
:
:
:
201305
March 19 2000
10:57:38
RR0400.EXE
05.00
SBNG
INFINITY
<Enter> to Close ...
Serial Number
Executable date
Executable time
Executable name
Software Version
Options Enabled
:
:
:
:
:
:
201305
March 19 2000
10:57:38
RR0400.EXE
05.00
SBNG
INFINITY
INFINITY
6(735()(5(1&(6
35()(5(1&(6
2.14 User Manual Software Version 7
Paste Trails Provides the capability to reduce solder paste trails from squeegees automati-
cally, options are:
If mode 1 is selected, any paste that has dripped from the squeegee is scooped
up, by the squeegee back to the paste roll. This process occurs at the start of
every stroke, with the print mode set to print/print and at the start of only the
print stroke, when the print mode is set to flood/print or print/flood.
Transport Wait
Mode
This option enables the product to be held in contact with the screen until both
upline and downline systems are ready to transfer, options are:
Clamp Type Sets the type of board clamp used, options are:
To eliminate vacuum seal loss during alignment, if the Snuggers option is
selected and the tooling type is Vacuum, the rails do not dip when the camera is
traversing.
On the Fly Sets whether the camera captures fiducials whilst moving over them (on the fly),
or whether the camera stops over the fiducial first, options are:
Snugger Thickness This parameter is only available if snuggers has been selected from the Clamp
Type preference, the options are:
Options
Disabled
Mode 1
Options Default
Standard Standard
Hold_at_Print
Options
Board Clamp
Snuggers
Options Default
Enabled Disabled
Disabled
Minimum Maximum Increment Default
0.8mm 2.0mm 0.1mm 1.6mm
