INFINITY
(55250(66$*(6
(55255(&29(5<
4.2 User Manual Software Version 7
ERROR RECOVERY
When an error message is displayed the following options maybe available to
recover the machine:
Abort Pressing this option re-initializes the entire printer, ejecting any product that may
be in the printer and returning to the main control page.
Retry Selecting this option re-checks the error condition and if clear continues the print
cycle.
Recover Pressing this option attempts to continue with any cycle that is in operation. This
function sets modules (paste dispenser, print carriage, etc.) to their home posi-
tion and ejects the board that is currently in the printer without re-initializing the
machine. This option should be the first to be operated if there is an error
reported.
Diagnostics This option enables the diagnostics to be entered immediately, normally by a
technician, for more in-depth investigation of the problem.
Head This option allows the operator to select ‘Head’ to gain access to the tooling area
of the machine.
Continue When this option is available, selecting the continue key clears the error message
and continue with the cycle that is in operation.
Fiducial Setup When this option is available, selecting the Fiducial Setup key allows the user
to relearn the reported ‘Not Found’ fiducial.
Auto Search When this option is available, selecting the Auto Search key instigates a search
within the selected window size to locate the ‘Not Found’ fiducial.
Search Step When this option is available, selecting the Search Step key moves the camera
the first step in a search procedure designed to locate the ‘Not Found’ fiducial.
Further selection of the key moves the camera to the second step etc. Once the
fiducial is visible in the region of interest, the Retry key can be selected to
capture the fiducial.
Search Reset When this option is available, selecting the Search Reset key returns the camera
to its original position, before the Search Step key was selected. This is the
position from which the ‘Not Found’ fiducial was reported.
INFINITY
(55250(66$*(6
(55250(66$*(/,67,1*
Software Version 7 User Manual 4.3
ERROR MESSAGE LISTING
Error Message Interpretation
Alignment Out of Range This indicates that the actuator positions required to achieve a satisfactory
alignment are not attainable.
Alignment Close to Limit/Out of Range Actuator limit exceeded.
AutoFlex Timed Out This error reports that with AutoFlex tooling on high power and the tooling
pins up, the process time of 5 minutes has been exceeded. When this
message is displayed the power is also switched to low.
Board Detected At Board Stop, Print
Terminated.
With the machine running in any mode, this error reports that the board
stop sensor has been activated out of sequence.
Possible causes are:
Board already loaded into the machine.
Sensor is detecting tooling.
Sensor is faulty.
Board Fiducial Not Found This error reports that the vision system has been unable to locate the
board fiducial.
Board Not Over Input Sensor This error reports a machine has started without a board on the rails. The
user has ignored the message to place a board on the rails and selects
continue on the machine.
Board On Rails, Remove and Continue This error reports that a board has been sensed on the rails during one of
the following operations:
Initialization
Loading a new board file
Entering the rail system in diagnostics.
Board Stop Not Lowered This error reports that the board stop is up and has not lowered within the
time-out period of 3 seconds. The possible causes are: Board stop sensor
- enter Diagnostics and check the sensor changes state.
Air pressure failure to the board stop.
Board Stop Not Retracted This error reports that the board stop is down and has not retracted within
the time-out period of 3 seconds. A possible cause is:
Board stop sensor - enter Diagnostics, Digital Inputs and check the sensor
changes state.
Board Stop Stuck This error reports that the board stop, which is housed in the camera
assembly has failed to lower or retract.
Board Stuck in Rails This error reports that the board has failed to either reach the board stop
or exit the machine after being printed.
Camera X Axis Error This error reports that the camera carriage has failed to reach its home
position in the X axis.
Camera Y Axis Error This error reports that the camera carriage has failed to reach its home
position in the Y axis.
Command Timed Out
(Belt Motors)
This error reports if a board on the belt fails to move over the board at left/
right sensor within the time period. Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
INFINITY
(55250(66$*(6
(55250(66$*(/,67,1*
4.4 User Manual Software Version 7
Command Timed Out
(Camera Axes)
This error reports that the camera has failed to move to the demanded
position within the time period. This error applies to both the X and Y
camera axis. Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed Out
(Paste Dispense Carriage)
This error reports that the paste dispense carriage has failed to move to the
demanded position within the time period. Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed out
(Print Carriage)
This error reports that the print carriage has failed to move to the
demanded position within the time period. Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed Out
(Print Head)
This error reports that the print head fails to move to the demanded
position within the time period. Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed Out
(ProFlow)
This error reports that the ProFlow unit has failed to move to the demanded
position within the time period. Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed Out
(Rail System)
This error reports that the moving rail has failed to move to the demanded
position within the time period. Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed Out
(Screen Actuators)
This error reports that the actuator has failed to move to the demanded
position within the time period. Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed Out
(Screen Change)
This error reports that the screen change has failed to move to the
demanded position within the time period. Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Error Message Interpretation
